Magnetic Starters
MITSUBISHI ELECTRIC
[MITSUBISHI ELECTRIC] — MS-T/N Series MS-T80KP Enclosed Magnetic Starter (80A AC-3, T80 Frame, TH-T100KP 3-Element Thermal)
Family ID: MEL-MSE-KP-T80
Mitsubishi Electric MS-T/N series T80-frame non-reversing enclosed-type magnetic starter MS-T80KP with TH-T100KP 3-element (2E) thermal overload relay providing combined overload and open-phase (single-phasing) protection. AC-operated, rated 19kW / 80A (AC-3) at 200-220V and 37kW / 80A at 380-440V, Ith 120A. Heater designations 67A to 67A (1 steps). Compliant with JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4. Auxiliary contact option units cannot be added to enclosed types.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MS-T80KP 67A AC24V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC24V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC24V (24V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 | ||
| MS-T80KP 67A AC48V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC48V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC48V (48-50V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 | ||
| MS-T80KP 67A AC100V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC100V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC100V (100-127V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 | ||
| MS-T80KP 67A AC200V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC200V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC200V (200-240V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 | ||
| MS-T80KP 67A AC300V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC300V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC300V (260-350V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 | ||
| MS-T80KP 67A AC400V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC400V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC400V (380-440V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 | ||
| MS-T80KP 67A AC500V | MS-T80KP non-reversing starter with 2E thermal, T80 frame, 67A heater, AC500V coil | Mitsubishi Electric | Frame: T80 · Type: Non-Reversing Magnetic Starter (Enclosed Type) · Poles: 3 · Operation: AC operated · Coil: AC500V (460-550V 50/60Hz) · Thermal Relay: TH-T100KP (3-element 2E, manual reset) · Protection: Overload + Open-phase · Heater: 67A (adjustable 54-80A) · AC-3 Capacity: 19kW@200-220V / 37kW@380-440V / 45kW@500-550V · AC-3 Current: 80A@200-220V / 80A@380-440V / 75A@500-550V · AC-1 Current: 120A@200-220V / 120A@380-440V · Thermal Current Ith: 120A · Aux Contact: 2a2b · Standards: JIS C8201-4-1, IEC 60947-4-1, EN 60947-4-1, GB 14048.4 |
