![[Mitutoyo] — 111-115 Spline Micrometer](https://img.prosourcemro.com/2026/05/1203537-1.jpg)
Measuring Instruments
Mitutoyo
[Mitutoyo] — 111-115 Spline Micrometer
Family ID: 402-1551
Mitutoyo 111-115 Spline Micrometer is a precision measuring instrument designed to accurately measure the dimensions of spline shafts and narrow grooves, sourced direct from Korea. Machinists and quality control technicians in gear manufacturing, automotive drivetrain production, and precision machining rely on spline micrometers to obtain reliable measurements in areas that standard micrometers cannot reach. Request a quote today to access export-ready supply, competitive pricing, and the confidence of purchasing through a KITA-registered Korean exporter.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 402-1551 | 111-115 | Mitutoyo | 111-115 (0-25/0.01) Type A | Measurement Range: 0~25 | Minimum Division: 0.01 | Anvil-Spindle: TYPE A | ||
| 402-1560 | 111-215 | Mitutoyo | 111-215 (0-25/0.01) Type B | Measurement Range: 0~25 | Minimum Graduation: 0.01 | Anvil-Spindle: TYPE B | ||
| 402-1579 | 111-116 | Mitutoyo | 111-116 (25-50/0.01) Type A | Measurement Range: 25~50 | Minimum Division: 0.01 | Anvil-Spindle: TYPE A |
