[OMRON] — G3PJ SSR for Heaters (Single-phase, 15/25A, 24-480VAC, Screw+Push-In, 12-24VDC)
Family ID: OMRON-G3PJ
Single-phase SSR for low heat generation enables carrying 25 A even for close mounting of three SSRs.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| G3PJ-215B DC12-24 | G3PJ Screw 24-240 VAC 15A close / 18A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 15A close / 18A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-225B DC12-24 | G3PJ Screw 24-240 VAC 25A close / 27A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-515B DC12-24 | G3PJ Screw 100-480 VAC 15A close / 23A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 15A close / 23A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-525B DC12-24 | G3PJ Screw 100-480 VAC 25A close / 27A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Screw | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-215B-PU DC12-24 | G3PJ Push-In Plus 24-240 VAC 15A close / 18A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 15A close / 18A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-225B-PU DC12-24 | G3PJ Push-In Plus 24-240 VAC 25A close / 27A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 24-240 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-515B-PU DC12-24 | G3PJ Push-In Plus 100-480 VAC 15A close / 23A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 15A close / 23A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible | ||
| G3PJ-525B-PU DC12-24 | G3PJ Push-In Plus 100-480 VAC 25A close / 27A separate | OMRON | Type: G3PJ SSR for Heaters (Single-phase) | Input Terminal: Push-In Plus | Input Voltage: 12-24 VDC | Load Voltage: 100-480 VAC | Load Current at 40°C: 25A close / 27A separate | Insulation: Phototriac coupler | Zero Cross: Yes | Indicator: Yes (orange) | Note: Load current varies with ambient temp; close-mount 3 SSRs possible |
