Temperature Controller
Omron
[OMRON] — NX-TC 2Ch Temperature Control Unit (NX Series, Multi-input TC/RTD, Voltage/Current Output, Standard/H&C Control)
Family ID: OMRON-NX-TC-2CH
Optimize Control by Detecting Status Changes. Easily Satisfy Both Productivity and Quality. NX Series Temperature Control Unit 2Ch type. Multi-input (Thermocouple and Resistance thermometer). 50ms conversion time. Free-Run refreshing.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| NX-TC2405 | 2Ch, Voltage output ×2 (SSR), CT input ×2, Standard Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Voltage (for driving SSR) | Output Points: 2 | CT Input: 2 | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2406 | 2Ch, Voltage output ×2 (SSR), no CT input, Standard Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Voltage (for driving SSR) | Output Points: 2 | CT Input: None | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2407 | 2Ch, Voltage output ×4 (SSR), no CT input, Heating and Cooling Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Voltage (for driving SSR) | Output Points: 4 | CT Input: None | Control Type: Heating and Cooling Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2408 | 2Ch, Linear current output ×2, no CT input, Standard Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Linear current | Output Points: 2 | CT Input: None | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2405 | 2Ch, Voltage output ×2 (SSR), CT input ×2, Standard Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Voltage (for driving SSR) | Output Points: 2 | CT Input: 2 | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2406 | 2Ch, Voltage output ×2 (SSR), no CT input, Standard Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Voltage (for driving SSR) | Output Points: 2 | CT Input: None | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2407 | 2Ch, Voltage output ×4 (SSR), no CT input, Heating and Cooling Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Voltage (for driving SSR) | Output Points: 4 | CT Input: None | Control Type: Heating and Cooling Control | Conversion Time: 50ms | I/O Refresh: Free-Run | ||
| NX-TC2408 | 2Ch, Linear current output ×2, no CT input, Standard Control | OMRON | Type: Temperature Control Unit | Channels: 2 | Input: Multi-input (TC/RTD) | Output: Linear current | Output Points: 2 | CT Input: None | Control Type: Standard Control | Conversion Time: 50ms | I/O Refresh: Free-Run |
