[OMRON] — S8VS Switch Mode Power Supply (Standard, No Monitor, 15~480W, 5V/12V/24VDC)
Power Supplies Omron

[OMRON] — S8VS Switch Mode Power Supply (Standard, No Monitor, 15~480W, 5V/12V/24VDC)

Family ID: OMRON-S8VS-STD

Indication Monitor for Visualization of Operating Status. Standard models without monitor. 15~480W. 5V/12V/24VDC output. Screw terminal and Screwless terminal variants. Input: 100~240VAC.

20 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
S8VS-01505 15W, 100~240VAC, 5VDC 2A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 15W | Input: 100~240VAC (85~264VAC) | Output: 5VDC 2A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-01512 15W, 100~240VAC, 12VDC 1.2A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 15W | Input: 100~240VAC (85~264VAC) | Output: 12VDC 1.2A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-01524 15W, 100~240VAC, 24VDC 0.65A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 15W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 0.65A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-03005 30W, 100~240VAC, 5VDC 4A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 30W | Input: 100~240VAC (85~264VAC) | Output: 5VDC 4A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-03012 30W, 100~240VAC, 12VDC 2.5A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 30W | Input: 100~240VAC (85~264VAC) | Output: 12VDC 2.5A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-03024 30W, 100~240VAC, 24VDC 1.3A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 30W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 1.3A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-06024 60W, 100~240VAC, 24VDC 2.5A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 60W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 2.5A | Monitor: No Monitor | Terminal: Screw | UL Class 2: Yes
S8VS-09024 90W, 100~240VAC, 24VDC 3.75A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 90W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 3.75A | Monitor: No Monitor | Terminal: Screw | UL Class 2: No
S8VS-09024S 90W, 100~240VAC, 24VDC 3.75A, No Monitor, Screw (UL Class 2 S) OMRON Type: Switch Mode Power Supply | Capacity: 90W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 3.75A | Monitor: No Monitor | Terminal: Screw (UL Class 2 S) | UL Class 2: Yes
S8VS-12024 120W, 100~240VAC, 24VDC 5A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 120W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 5A | Monitor: No Monitor | Terminal: Screw | UL Class 2: No
S8VS-18024 180W, 100~240VAC, 24VDC 7.5A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 180W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 7.5A | Monitor: No Monitor | Terminal: Screw | UL Class 2: No
S8VS-24024 240W, 100~240VAC, 24VDC 10A, No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 240W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 10A | Monitor: No Monitor | Terminal: Screw | UL Class 2: No
S8VS-48024 480W, 100~240VAC, 24VDC 20A (peak 30A), No Monitor, Screw OMRON Type: Switch Mode Power Supply | Capacity: 480W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 20A (peak 30A) | Monitor: No Monitor | Terminal: Screw | UL Class 2: No
S8VS-06024-F 60W, 100~240VAC, 24VDC 2.5A, No Monitor, Screwless OMRON Type: Switch Mode Power Supply | Capacity: 60W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 2.5A | Monitor: No Monitor | Terminal: Screwless | UL Class 2: Yes
S8VS-09024-F 90W, 100~240VAC, 24VDC 3.75A, No Monitor, Screwless OMRON Type: Switch Mode Power Supply | Capacity: 90W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 3.75A | Monitor: No Monitor | Terminal: Screwless | UL Class 2: No
S8VS-09024S-F 90W, 100~240VAC, 24VDC 3.75A, No Monitor, Screwless (UL Class 2 S) OMRON Type: Switch Mode Power Supply | Capacity: 90W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 3.75A | Monitor: No Monitor | Terminal: Screwless (UL Class 2 S) | UL Class 2: Yes
S8VS-12024-F 120W, 100~240VAC, 24VDC 5A, No Monitor, Screwless OMRON Type: Switch Mode Power Supply | Capacity: 120W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 5A | Monitor: No Monitor | Terminal: Screwless | UL Class 2: No
S8VS-18024-F 180W, 100~240VAC, 24VDC 7.5A, No Monitor, Screwless OMRON Type: Switch Mode Power Supply | Capacity: 180W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 7.5A | Monitor: No Monitor | Terminal: Screwless | UL Class 2: No
S8VS-24024-F 240W, 100~240VAC, 24VDC 10A, No Monitor, Screwless OMRON Type: Switch Mode Power Supply | Capacity: 240W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 10A | Monitor: No Monitor | Terminal: Screwless | UL Class 2: No
S8VS-48024-F 480W, 100~240VAC, 24VDC 20A (peak 30A), No Monitor, Screwless OMRON Type: Switch Mode Power Supply | Capacity: 480W | Input: 100~240VAC (85~264VAC) | Output: 24VDC 20A (peak 30A) | Monitor: No Monitor | Terminal: Screwless | UL Class 2: No
