Power Supplies
Omron
[OMRON] — S8JX-P Switch Mode Power Supply (300/600 W, Front-mount, Built-in Fan)
Family ID: OMRON-S8JX-P-FRONT-FAN
S8JX-P Series with EMI Class B and Power Factor Correction is newly added to S8JX Series. 300 W and 600 W models. Input: 100 to 240 VAC free voltage (80 to 370 VDC). Output: 5/12/24/48 VDC. Compliant with EC Directives and safety standards (UL, EN).
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| S8JX-P30005C | S8JX-P 300 W, 5 VDC / 60 A, Front-mounting, Built-in Fan | OMRON | Power Rating: 300 W | Output Voltage: 5 VDC | Output Current: 60 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P30012C | S8JX-P 300 W, 12 VDC / 27 A, Front-mounting, Built-in Fan | OMRON | Power Rating: 300 W | Output Voltage: 12 VDC | Output Current: 27 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P30024C | S8JX-P 300 W, 24 VDC / 14 A peak / 16.5 A (200 VAC), Front-mounting, Built-in Fan | OMRON | Power Rating: 300 W | Output Voltage: 24 VDC | Output Current: 14 A peak / 16.5 A (200 VAC) | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P30048C | S8JX-P 300 W, 48 VDC / 7 A, Front-mounting, Built-in Fan | OMRON | Power Rating: 300 W | Output Voltage: 48 VDC | Output Current: 7 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P60005C | S8JX-P 600 W, 5 VDC / 120 A, Front-mounting, Built-in Fan | OMRON | Power Rating: 600 W | Output Voltage: 5 VDC | Output Current: 120 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P60012C | S8JX-P 600 W, 12 VDC / 53 A, Front-mounting, Built-in Fan | OMRON | Power Rating: 600 W | Output Voltage: 12 VDC | Output Current: 53 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P60024C | S8JX-P 600 W, 24 VDC / 27 A peak / 31 A (200 VAC), Front-mounting, Built-in Fan | OMRON | Power Rating: 600 W | Output Voltage: 24 VDC | Output Current: 27 A peak / 31 A (200 VAC) | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes | ||
| S8JX-P60048C | S8JX-P 600 W, 48 VDC / 13 A, Front-mounting, Built-in Fan | OMRON | Power Rating: 600 W | Output Voltage: 48 VDC | Output Current: 13 A | Input Voltage: 100 to 240 VAC free (80 to 370 VDC) | Built-in Fan: Yes | Mounting: Front-mounting (bracket provided) | EMI: Class B | Power Factor Correction: Yes |
