![[OMRON] — X General-purpose Basic Switch (DC, Built-in Magnetic Blowout, Pin/Lever/Roller)](https://img.prosourcemro.com/2026/05/001-463-1024x786.png)
Switches
Omron
[OMRON] — X General-purpose Basic Switch (DC, Built-in Magnetic Blowout, Pin/Lever/Roller)
Family ID: OMRON-X-BASIC
Direct Current Switch with Built-in Magnetic Blowout
30 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| X-10G | X Pin plunger Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Pin plunger | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10G-B | X Pin plunger Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Pin plunger | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GS | X Slim spring plunger Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Slim spring plunger | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GS-B | X Slim spring plunger Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Slim spring plunger | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GD | X Short spring plunger Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Short spring plunger | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GD-B | X Short spring plunger Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Short spring plunger | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GQ | X Panel mount plunger Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Panel mount plunger | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GQ-B | X Panel mount plunger Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Panel mount plunger | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GQ22 | X Panel mount roller plunger Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Panel mount roller plunger | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GQ22-B | X Panel mount roller plunger Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Panel mount roller plunger | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GQ21 | X Panel mount cross roller plunger Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Panel mount cross roller plunger | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GQ21-B | X Panel mount cross roller plunger Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Panel mount cross roller plunger | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GL | X Leaf spring Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Leaf spring | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GL-B | X Leaf spring Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Leaf spring | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW21 | X Short hinge lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Short hinge lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW21-B | X Short hinge lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Short hinge lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW | X Hinge lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Hinge lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW-B | X Hinge lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Hinge lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW4 | X Low-force hinge lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Low-force hinge lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW4-B | X Low-force hinge lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Low-force hinge lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW22 | X Short hinge roller lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Short hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW22-B | X Short hinge roller lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Short hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW2 | X Hinge roller lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GW2-B | X Hinge roller lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GM | X Reverse hinge lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Reverse hinge lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GM-B | X Reverse hinge lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Reverse hinge lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GM22 | X Reverse short hinge roller lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Reverse short hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GM22-B | X Reverse short hinge roller lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Reverse short hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching | ||
| X-10GM2 | X Reverse hinge roller lever Solder | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Reverse hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Solder | Note: Built-in magnetic blowout for DC switching | ||
| X-10GM2-B | X Reverse hinge roller lever Screw | OMRON | Type: Basic Switch (DC, Magnetic Blowout) | Actuator: Reverse hinge roller lever | Contact Gap: G (0.5mm) | Terminal: Screw | Note: Built-in magnetic blowout for DC switching |
