Switches
Omron
[OMRON] — M22 Indicator (22/25-dia., Square Projection, LED, IP65)
Family ID: OMRON-M22
Round Indicator Series with 22 dia. and 25 dia. (when using a ring)
25 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| M22-CY-6A | M22 Indicator Set 6 VAC/VDC | OMRON | Type: Indicator Set (Square/Projection) | Voltage: 6 VAC/VDC | Lighting: LED direct | Available Colors: R (red) / Y (yellow) / G (green) / W (white) / A (blue) | Note: Replace [] with color code R/Y/G/W/A. | ||
| M22-C[]-12A | M22 Indicator Set 12 VAC/VDC | OMRON | Type: Indicator Set (Square/Projection) | Voltage: 12 VAC/VDC | Lighting: LED direct | Available Colors: R (red) / Y (yellow) / G (green) / W (white) / A (blue) | Note: Replace [] with color code R/Y/G/W/A. | ||
| M22-C[]-24A | M22 Indicator Set 24 VAC/VDC | OMRON | Type: Indicator Set (Square/Projection) | Voltage: 24 VAC/VDC | Lighting: LED direct | Available Colors: R (red) / Y (yellow) / G (green) / W (white) / A (blue) | Note: Replace [] with color code R/Y/G/W/A. | ||
| M22-C[]-T1 | M22 Indicator Set 100 VAC | OMRON | Type: Indicator Set (Square/Projection) | Voltage: 100 VAC | Lighting: LED with VR | Available Colors: R (red) / Y (yellow) / G (green) / W (white) / A (blue) | Note: Replace [] with color code R/Y/G/W/A. VR models use A22-24A[] LED only (24V) | ||
| M22-C[]-T2 | M22 Indicator Set 200 VAC | OMRON | Type: Indicator Set (Square/Projection) | Voltage: 200 VAC | Lighting: LED with VR | Available Colors: R (red) / Y (yellow) / G (green) / W (white) / A (blue) | Note: Replace [] with color code R/Y/G/W/A. VR models use A22-24A[] LED only (24V) | ||
| M22-CR | M22 Display Red | OMRON | Type: M22 Display (Square/Projection, IP65) | Color: Red | ||
| M22-CG | M22 Display Green | OMRON | Type: M22 Display (Square/Projection, IP65) | Color: Green | ||
| M22-CY | M22 Display Yellow | OMRON | Type: M22 Display (Square/Projection, IP65) | Color: Yellow | ||
| M22-CW | M22 Display White | OMRON | Type: M22 Display (Square/Projection, IP65) | Color: White | ||
| M22-CA | M22 Display Blue | OMRON | Type: M22 Display (Square/Projection, IP65) | Color: Blue | ||
| A22-6AR | M22 LED Lamp 6V Red | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 6V | Color: Red | ||
| A22-6AG | M22 LED Lamp 6V Green | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 6V | Color: Green | ||
| A22-6AY | M22 LED Lamp 6V Yellow | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 6V | Color: Yellow | ||
| A22-6AA | M22 LED Lamp 6V Blue | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 6V | Color: Blue | ||
| A22-12AR | M22 LED Lamp 12V Red | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 12V | Color: Red | ||
| A22-12AG | M22 LED Lamp 12V Green | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 12V | Color: Green | ||
| A22-12AY | M22 LED Lamp 12V Yellow | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 12V | Color: Yellow | ||
| A22-12AA | M22 LED Lamp 12V Blue | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 12V | Color: Blue | ||
| A22-24AR | M22 LED Lamp 24V Red | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 24V | Color: Red | ||
| A22-24AG | M22 LED Lamp 24V Green | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 24V | Color: Green | ||
| A22-24AY | M22 LED Lamp 24V Yellow | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 24V | Color: Yellow | ||
| A22-24AA | M22 LED Lamp 24V Blue | OMRON | Type: M22 LED Lamp (A22 series) | Voltage: 24V | Color: Blue | ||
| M22-00 | M22 Socket Unit Without VR | OMRON | Type: M22 Socket Unit | Description: Without VR | Note: | ||
| M22-00-T1 | M22 Socket Unit VR 110VAC | OMRON | Type: M22 Socket Unit | Description: VR 110VAC | Note: VR models use A22-24A[] LED only (24V) | ||
| M22-00-T2 | M22 Socket Unit VR 220VAC | OMRON | Type: M22 Socket Unit | Description: VR 220VAC | Note: VR models use A22-24A[] LED only (24V) |
