[THK] — FF Support Unit (Support Side, Circular Type, for Ball Screw)

Family ID: THK-FF

THK FF-type Ball Screw Support Unit (support side, circular housing). Deep groove ball bearing with snap ring for simple support-side mounting. Compact and simple installation. Shaft diameter range φ6~30mm.

7 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code	Description	Brand	Spec
FF6	THK FF6, Support Side Unit, φ6mm	THK	Shaft Diameter: φ6mm \| Housing Length L: 10mm \| H: 6mm \| F: 4mm \| Housing OD D: 22mm \| Inner Dia A: 36mm \| PCD: 28mm \| Width B: 28mm \| Bearing: 606ZZ \| Snap Ring: C6 \| Mass: 0.04kg \| Type: Support Side, Circular Housing (FF)
FF10	THK FF10, Support Side Unit, φ8mm	THK	Shaft Diameter: φ8mm \| Housing Length L: 12mm \| H: 7mm \| F: 5mm \| Housing OD D: 28mm \| Inner Dia A: 43mm \| PCD: 35mm \| Width B: 35mm \| Bearing: 608ZZ \| Snap Ring: C8 \| Mass: 0.07kg \| Type: Support Side, Circular Housing (FF)
FF12	THK FF12, Support Side Unit, φ10mm	THK	Shaft Diameter: φ10mm \| Housing Length L: 15mm \| H: 7mm \| F: 8mm \| Housing OD D: 34mm \| Inner Dia A: 52mm \| PCD: 42mm \| Width B: 42mm \| Bearing: 6000ZZ \| Snap Ring: C10 \| Mass: 0.11kg \| Type: Support Side, Circular Housing (FF)
FF15	THK FF15, Support Side Unit, φ15mm	THK	Shaft Diameter: φ15mm \| Housing Length L: 17mm \| H: 9mm \| F: 8mm \| Housing OD D: 40mm \| Inner Dia A: 63mm \| PCD: 50mm \| Width B: 52mm \| Bearing: 6002ZZ \| Snap Ring: C15 \| Mass: 0.2kg \| Type: Support Side, Circular Housing (FF)
FF20	THK FF20, Support Side Unit, φ20mm	THK	Shaft Diameter: φ20mm \| Housing Length L: 20mm \| H: 11mm \| F: 9mm \| Housing OD D: 57mm \| Inner Dia A: 85mm \| PCD: 70mm \| Width B: 68mm \| Bearing: 6204ZZ \| Snap Ring: C20 \| Mass: 0.27kg \| Type: Support Side, Circular Housing (FF)
FF25	THK FF25, Support Side Unit, φ25mm	THK	Shaft Diameter: φ25mm \| Housing Length L: 24mm \| H: 14mm \| F: 10mm \| Housing OD D: 63mm \| Inner Dia A: 98mm \| PCD: 80mm \| Width B: 79mm \| Bearing: 6205ZZ \| Snap Ring: C25 \| Mass: 0.67kg \| Type: Support Side, Circular Housing (FF)
FF30	THK FF30, Support Side Unit, φ30mm	THK	Shaft Diameter: φ30mm \| Housing Length L: 27mm \| H: 18mm \| F: 9mm \| Housing OD D: 75mm \| Inner Dia A: 117mm \| PCD: 95mm \| Width B: 93mm \| Bearing: 6206ZZ \| Snap Ring: C30 \| Mass: 1.07kg \| Type: Support Side, Circular Housing (FF)
