[THK] — SKR26 LM Guide Actuator, Motor Parallel (With Cover, φ26)
Family ID: THK-SKR26P-C
THK SKR26 Series LM Guide Actuator with parallel motor mount (with cover). LM block and ball screw nut integrated for compact design. 4-direction equal load capacity. A-type: 1 long block; B-type: 2 long blocks. Stroke range 60~210mm.
7 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| SKR26PA-0060 | THK SKR26, With Cover, 1 Long Block, Stroke 60mm | THK | Stroke: 60mm | Mech Stopper Stroke: 68.4mm | Outer Rail Length: 150mm | Total Length L: 201.8mm | G: 35mm | Block Type: A-type (1 Long Block) | Cover: With Cover | Mass: 1.39kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) | ||
| SKR26PA-0110 | THK SKR26, With Cover, 1 Long Block, Stroke 110mm | THK | Stroke: 110mm | Mech Stopper Stroke: 118.4mm | Outer Rail Length: 200mm | Total Length L: 251.8mm | G: 20mm | Block Type: A-type (1 Long Block) | Cover: With Cover | Mass: 1.61kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) | ||
| SKR26PA-0160 | THK SKR26, With Cover, 1 Long Block, Stroke 160mm | THK | Stroke: 160mm | Mech Stopper Stroke: 168.4mm | Outer Rail Length: 250mm | Total Length L: 301.8mm | G: 45mm | Block Type: A-type (1 Long Block) | Cover: With Cover | Mass: 1.84kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) | ||
| SKR26PA-0210 | THK SKR26, With Cover, 1 Long Block, Stroke 210mm | THK | Stroke: 210mm | Mech Stopper Stroke: 218.4mm | Outer Rail Length: 300mm | Total Length L: 351.8mm | G: 30mm | Block Type: A-type (1 Long Block) | Cover: With Cover | Mass: 2.06kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) | ||
| SKR26PB-0045 | THK SKR26, With Cover, 2 Long Blocks, Stroke 45mm | THK | Stroke: 45mm | Mech Stopper Stroke: 54.2mm | Outer Rail Length: 200mm | Total Length L: 251.8mm | G: 20mm | Block Type: B-type (2 Long Blocks) | Cover: With Cover | Mass: 1.86kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) | ||
| SKR26PB-0095 | THK SKR26, With Cover, 2 Long Blocks, Stroke 95mm | THK | Stroke: 95mm | Mech Stopper Stroke: 104.2mm | Outer Rail Length: 250mm | Total Length L: 301.8mm | G: 45mm | Block Type: B-type (2 Long Blocks) | Cover: With Cover | Mass: 2.09kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) | ||
| SKR26PB-0145 | THK SKR26, With Cover, 2 Long Blocks, Stroke 145mm | THK | Stroke: 145mm | Mech Stopper Stroke: 154.2mm | Outer Rail Length: 300mm | Total Length L: 351.8mm | G: 30mm | Block Type: B-type (2 Long Blocks) | Cover: With Cover | Mass: 2.31kg | Motor Mount: Parallel | Rail Width: 26mm | Type: LM Guide Actuator (SKR26) |
