[Tsubaki] — Powerlock EL Series Shaft Locking Element (Simple Type, Small (Ø10~25 mm))

Family ID: TSB-PL-EL-S

Tsubaki Powerlock EL Series — simple locking element type for straightforward shaft-to-hub connection. Compact and easy to install. Non-backlash friction connection; no keyway required. Standard grade. RoHS compliant.

14 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code	Description	Brand	Spec
PL010X013E	Shaft Ø10 mm × Outer Ø13 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 10 mm \| Outer Diameter: 13 mm
PL011X014E	Shaft Ø11 mm × Outer Ø14 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 11 mm \| Outer Diameter: 14 mm
PL012X015E	Shaft Ø12 mm × Outer Ø15 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 12 mm \| Outer Diameter: 15 mm
PL013X016E	Shaft Ø13 mm × Outer Ø16 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 13 mm \| Outer Diameter: 16 mm
PL014X018E	Shaft Ø14 mm × Outer Ø18 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 14 mm \| Outer Diameter: 18 mm
PL015X019E	Shaft Ø15 mm × Outer Ø19 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 15 mm \| Outer Diameter: 19 mm
PL016X020E	Shaft Ø16 mm × Outer Ø20 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 16 mm \| Outer Diameter: 20 mm
PL017X021E	Shaft Ø17 mm × Outer Ø21 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 17 mm \| Outer Diameter: 21 mm
PL018X022E	Shaft Ø18 mm × Outer Ø22 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 18 mm \| Outer Diameter: 22 mm
PL019X024E	Shaft Ø19 mm × Outer Ø24 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 19 mm \| Outer Diameter: 24 mm
PL020X025E	Shaft Ø20 mm × Outer Ø25 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 20 mm \| Outer Diameter: 25 mm
PL022X026E	Shaft Ø22 mm × Outer Ø26 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 22 mm \| Outer Diameter: 26 mm
PL024X028E	Shaft Ø24 mm × Outer Ø28 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 24 mm \| Outer Diameter: 28 mm
PL025X030E	Shaft Ø25 mm × Outer Ø30 mm	Tsubaki	Series: Powerlock EL \| Grade: Standard \| Size Range: Small (Ø10~25 mm) \| Type: Simple Locking Element \| Feature: Compact, easy installation \| Keyway: Not Required \| RoHS: Compliant \| Application: General industrial shaft-to-hub connections \| Shaft Diameter: 25 mm \| Outer Diameter: 30 mm
