![[UDT] — 520-8272 Shackle Eye Bolt](https://img.prosourcemro.com/2026/05/3424750-1-2.jpg)
Chains & Wires
UDT
[UDT] — 520-8272 Shackle Eye Bolt
Family ID: 520-8272
UDT 520-8272 Shackle Eye Bolt is a rigging connector designed to join lifting chains, wire ropes, and load-bearing assemblies, sourced direct from Korea. Commonly used in industrial lifting, marine, and construction applications, this type of hardware provides a secure anchor point for attaching hooks, slings, or shackles to fixed structures or machinery. Request a quote today for export-ready supply at competitive pricing through a KITA-registered Korean exporter.
11 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 520-8272 | — | UDT | 6mm | Spec: 6 | Weight: 0.03 | Safe Working Load: 0.06 | A: 25 | C: 5 | Shape: mm | D: 13 | I: 14 | h: 27 | T: 6 | H: 27 | B: 15 | ||
| 520-8281 | — | UDT | 8mm | Spec: 8 | Weight: 0.03 | Safe Working Load: 0.08 | A: 33 | C: 6 | Shape: mm | D: 16 | I: 15 | h: 17 | T: 6 | H: 33 | B: 20 | ||
| 520-8290 | — | UDT | 10mm | Spec: 10 | Weight: 0.06 | Safe Working Load: 0.15 | A: 41 | C: 8 | Shape: mm | D: 20 | I: 18 | h: 21 | T: 7 | H: 42 | B: 25 | ||
| 520-8306 | — | UDT | 12mm | Spec: 12 | Weight: 0.13 | Safe Working Load: 0.22 | A: 50 | C: 10 | Shape: mm | D: 25 | I: 22 | h: 26 | T: 9 | H: 51 | B: 30 | ||
| 520-8315 | — | UDT | 14mm | Spec: 14 | Weight: 0.22 | Safe Working Load: 0.33 | A: 60 | C: 12 | Shape: mm | D: 30 | I: 26 | h: 30 | T: 11 | H: 60 | B: 35 | ||
| 520-8324 | — | UDT | 16mm | Spec: 16 | Weight: 0.24 | Safe Working Load: 0.45 | A: 63 | C: 14 | Shape: mm | D: 35 | I: 27 | h: 30 | T: 12 | H: 60 | B: 35 | ||
| 520-8333 | — | UDT | 18mm | Spec: 18 | Weight: 0.39 | Safe Working Load: 0.54 | A: 72 | C: 16 | Shape: mm | D: 30 | I: 30 | h: 35 | T: 13 | H: 71 | B: 40 | ||
| 520-8342 | — | UDT | 20mm | Spec: 20 | Weight: 0.39 | Safe Working Load: 0.63 | A: 72 | C: 16 | Shape: mm | D: 30 | I: 30 | h: 35 | T: 13 | H: 71 | B: 40 | ||
| 520-8351 | — | UDT | 22mm | Spec: 22 | Weight: 0.44 | Safe Working Load: 0.88 | A: 81 | C: 18 | Shape: mm | D: 45 | I: 35 | h: 40 | T: 14 | H: 90 | B: 45 | ||
| 520-8360 | — | UDT | 24mm | Spec: 24 | Weight: 0.78 | Safe Working Load: 0.95 | A: 90 | C: 20 | Shape: mm | D: 50 | I: 38 | h: 45 | T: 16 | H: 90 | B: 50 | ||
| 520-8379 | — | UDT | 30mm | Spec: 30 | Weight: 1.40 | Safe Working Load: 1.50 | A: 110 | C: 25 | Shape: mm | D: 60 | I: 45 | h: 55 | T: 18 | H: 110 | B: 60 |
