[YG-1] — EQ406020K End Mill HSS Long End Mill (Coated)
End Mills YG-1

[YG-1] — EQ406020K End Mill HSS Long End Mill (Coated)

Family ID: 301-5438

HSS Long End Mill (Coated) from YG-1, sourced from Korea.

33 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
301-5438 EQ406020K YG-1 2F-2*6*10*60MM TIALN (EQ406020K) | Spec: 2 | Flute Length: 10 | Overall Length: 60 | Shank Diameter: 6
301-5447 EQ406030K YG-1 2F-3*6*15*60MM TIALN (EQ406030K) | Spec: 3 | Flute Length: 15 | Overall Length: 60 | Shank d: 6
301-5456 EQ406040K YG-1 2F-4*8*20*70MM TIALN (EQ406040K) | Spec: 4 | Flute Length: 20 | Overall Length: 70 | Shank Diameter: 8
301-5465 EQ406050K YG-1 2F-5*8*25*75MM TIALN (EQ406050K) | Spec: 5 | Flute Length: 25 | Overall Length: 75 | Shank Diameter: 8
301-5474 EQ406060K YG-1 2F-6*8*25*75MM TIALN (EQ406060K) | Spec: 6 | Flute Length: 25 | Overall Length: 75 | Shank Diameter: 8
301-5483 EQ406070K YG-1 2F-7*10*35*90MM TIALN (EQ406070K) | Spec: 7 | Flute Length: 35 | Overall Length: 90 | Shank d: 10
301-5492 EQ406080K YG-1 2F-8*10*35*90MM TIALN (EQ406080K) | Spec: 8 | Flute Length: 35 | Overall Length: 90 | Shank Diameter: 10
301-5508 EQ406090K YG-1 2F-9*10*45*100MM TIALN (EQ406090K) | Spec: 9 | Flute Length: 45 | Overall Length: 100 | Shank Diameter: 10
301-5517 EQ406100K YG-1 2F-10*10*45*100MM TIALN (EQ406100K) | Spec: 10 | Flute Length: 45 | Overall Length: 100 | Shank Diameter: 10
301-5526 EQ406110K YG-1 2F-11*12*55*115MM TIALN (EQ406110K) | Spec: 11 | Flute Length: 55 | Overall Length: 115 | Shank Diameter: 12
301-5535 EQ406120K YG-1 2F-12*12*55*115MM TIALN (EQ406120K) | Spec: 12 | Flute Length: 55 | Overall Length: 115 | Shank Diameter: 12
301-5544 EQ406130K YG-1 2F-13*12*55*115MM TIALN (EQ406130K) | Spec: 13 | Flute Length: 55 | Overall Length: 115 | Product Name: Coated 2F | Shank Diameter: 12
301-5553 EQ406140K YG-1 2F-14*16*55*120MM TIALN (EQ406140K) | Spec: 14 | Flute Length: 55 | Overall Length: 120 | Product Name: Coated 2F | Shank Diameter: 16
301-5562 EQ406150K YG-1 2F-15*16*65*130MM TIALN (EQ406150K) | Spec: 15 | Flute Length: 65 | Overall Length: 130 | Shank D: 16
301-5571 EQ406160K YG-1 2F-16*16*65*130MM TIALN (EQ406160K) | Spec: 16 | Flute Length: 65 | Overall Length: 130 | Shank Diameter: 16
301-5580 EQ406170K YG-1 2F-17*16*65*130MM TIALN (EQ406170K) | Spec: 17 | Flute Length: 65 | Overall Length: 130 | Shank Diameter: 16
301-5599 EQ406180K YG-1 2F-18*16*65*130MM TIALN (EQ406180K) | Spec: 18 | Flute Length: 65 | Overall Length: 130 | Shank D: 16
301-5605 EQ406190K YG-1 2F-19*20*75*145MM TIALN (EQ406190K) | Spec: 19 | Flute Length: 75 | Overall Length: 145 | Shank Diameter: 20
301-5614 EQ406200K YG-1 2F-20*20*75*145MM TIALN (EQ406200K) | Spec: 20 | Flute Length: 75 | Overall Length: 145 | Shank Diameter: 20
301-5623 EQ406210K YG-1 2F-21*20*75*145MM TIALN (EQ406210K) | Spec: 21 | Flute Length: 75 | Overall Length: 145 | Shank d: 20
301-5632 EQ406220K YG-1 2F-22*20*75*145MM TIALN (EQ406220K) | Spec: 22 | Flute Length: 75 | Overall Length: 145 | Shank d: 20
301-5641 EQ406230K YG-1 2F-23*25*90*165MM TIALN (EQ406230K) | Spec: 23 | Flute Length: 90 | Overall Length: 165 | Shank Diameter: 25
301-5650 EQ406240K YG-1 2F-24*25*90*165MM TIALN (EQ406240K) | Spec: 24 | Flute Length: 90 | Overall Length: 165 | Shank Diameter: 25
301-5669 EQ406250K YG-1 2F-25*25*90*165MM TIALN (EQ406250K) | Spec: 25 | Flute Length: 90 | Overall Length: 165 | Shank d: 25
301-5678 EQ406260K YG-1 2F-26*25*90*165MM TIALN (EQ406260K) | Spec: 26 | Flute Length: 90 | Overall Length: 165 | Shank Dia: 25
301-5687 EQ406270K YG-1 2F-27*25*90*165MM TIALN (EQ406270K) | Spec: 27 | Flute Length: 90 | Overall Length: 165 | Shank Diameter: 25
301-5696 EQ406280K YG-1 2F-28*25*90*165MM TIALN (EQ406280K) | Spec: 28 | Flute Length: 90 | Overall Length: 165 | Shank Diameter: 25
301-5702 EQ406290K YG-1 2F-29*25*90*165MM TIALN (EQ406290K) | Spec: 29 | Flute Length: 90 | Overall Length: 165 | Shank Diameter: 25
301-5711 EQ406300K YG-1 2F-30*25*90*165MM TIALN (EQ406300K) | Spec: 30 | Flute Length: 90 | Overall Length: 165 | Shank d: 25
301-5739 EQ406320K YG-1 2F-32*32*95*180MM TIALN (EQ406320K) | Spec: 32 | Flute Length: 95 | Overall Length: 180 | Shank D: 32
301-5766 EQ406350K YG-1 2F-35*32*100*185MM TIALN (EQ406350K) | Spec: 35 | Flute Length: 100 | Overall Length: 185 | Shank Diameter: 32
301-5809 EQ406390K YG-1 2F-39*32*110*195MM TIALN (EQ406390K) | Spec: 39 | Flute Length: 110 | Overall Length: 195 | Shank Diameter: 32
301-5818 EQ406400K YG-1 2F-40*32*110*195MM TIALN (EQ406400K) | Spec: 40 | Flute Length: 110 | Overall Length: 195 | Shank d: 32
