Yuken — 10 Series Modular Mounting Bolt Kit
Family ID: YUK-FMOD-10-BOLTKIT
10 (1¼) Series Mounting Bolt Kits For Modular Valves. M20 stud bolts ×6 + nuts per set. Bolt code 01–04 by stack height.
4 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| MBK-10-01-10 | Mounting bolt kit, code 01 | Yuken | Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Mounting bolt kit (M20 stud ×6 + nuts / set) | Bolt Code: 01: 217 mm (1 valve stack) | ||
| MBK-10-02-10 | Mounting bolt kit, code 02 | Yuken | Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Mounting bolt kit (M20 stud ×6 + nuts / set) | Bolt Code: 02: 337 mm (2) | ||
| MBK-10-03-10 | Mounting bolt kit, code 03 | Yuken | Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Mounting bolt kit (M20 stud ×6 + nuts / set) | Bolt Code: 03: 457 mm (3) | ||
| MBK-10-04-10 | Mounting bolt kit, code 04 | Yuken | Series: 10 (1¼) Modular | Mounting: Sandwich/stack (ISO 4401) | Function: Mounting bolt kit (M20 stud ×6 + nuts / set) | Bolt Code: 04: 577 mm (4) |
