Single Vane Pumps
Yuken
[Yuken] — 150T Single Vane Pump (fixed displacement, 7 MPa)
Family ID: YKN-150T-VANE
Single Vane Pumps (150T series). Stable performance over a wide flow range, widely used as a hydraulic power source. Max working pressure 7 MPa. Foot and flange mounting types. Detailed configuration by separate inquiry (RFQ).
5 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| 150T-48 | 150T single vane pump, 47.7 cm3/rev, 7 MPa | Yuken | Series: 150T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 47.7 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1200-1500 / min 600 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 26 kg (foot) / 25 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| 150T-61 | 150T single vane pump, 61.1 cm3/rev, 7 MPa | Yuken | Series: 150T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 61.1 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1200-1500 / min 600 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 26 kg (foot) / 25 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| 150T-75 | 150T single vane pump, 74.9 cm3/rev, 7 MPa | Yuken | Series: 150T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 74.9 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1200-1500 / min 600 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 26 kg (foot) / 25 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| 150T-94 | 150T single vane pump, 93.6 cm3/rev, 7 MPa | Yuken | Series: 150T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 93.6 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1200-1500 / min 600 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 26 kg (foot) / 25 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| 150T-116 | 150T single vane pump, 115.6 cm3/rev, 7 MPa | Yuken | Series: 150T | Type: Single Vane Pump (fixed displacement) | Theoretical Displacement: 115.6 cm3/rev | Max Working Pressure: 7 MPa (mineral / general / phosphate-ester) | Permissible Speed: max 1200-1500 / min 600 r/min (phosphate-ester limited to 1200 r/min) | Mounting: Foot or Flange type | Mass (approx): 26 kg (foot) / 25 kg (flange) | Note: Detailed specification / configuration: RFQ | Fluid Option: Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) |
