Single Vane Pumps
Yuken
[Yuken] — PV2R4A Series Single Vane Pump (high-pressure/high-performance, 17.2 MPa)
Family ID: YKN-PV2R4A-VANE
PV2R4A Series Single Vane Pumps. A high-pressure, high-performance pump; a greatly compacted version of the well-regarded PV2R4 low-noise vane pump. Max working pressure 17.2 MPa. Foot and flange mounting types. Clockwise rotation standard; top discharge/suction ports standard.
6 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| PV2R4A-138-L-RAA-10 | PV2R4A single vane pump, 138 cm3/rev, Foot mount, 17.2 MPa | Yuken | Series: PV2R4A | Type: Single Vane Pump | Theoretical Displacement: 138 cm3/rev | Max Working Pressure: 17.2 MPa | Mounting: L = Foot type | Rotation: R = Clockwise (standard, viewed from shaft end) | Discharge Port: A = Top (standard) | Suction Port: A = Top (standard) | Design No: 10 | Options: Counter-clockwise (reverse) rotation available to order (RFQ); Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| PV2R4A-138-F-RAA-10 | PV2R4A single vane pump, 138 cm3/rev, Flange mount, 17.2 MPa | Yuken | Series: PV2R4A | Type: Single Vane Pump | Theoretical Displacement: 138 cm3/rev | Max Working Pressure: 17.2 MPa | Mounting: F = Flange type | Rotation: R = Clockwise (standard, viewed from shaft end) | Discharge Port: A = Top (standard) | Suction Port: A = Top (standard) | Design No: 10 | Options: Counter-clockwise (reverse) rotation available to order (RFQ); Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| PV2R4A-162-L-RAA-10 | PV2R4A single vane pump, 162 cm3/rev, Foot mount, 17.2 MPa | Yuken | Series: PV2R4A | Type: Single Vane Pump | Theoretical Displacement: 162 cm3/rev | Max Working Pressure: 17.2 MPa | Mounting: L = Foot type | Rotation: R = Clockwise (standard, viewed from shaft end) | Discharge Port: A = Top (standard) | Suction Port: A = Top (standard) | Design No: 10 | Options: Counter-clockwise (reverse) rotation available to order (RFQ); Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| PV2R4A-162-F-RAA-10 | PV2R4A single vane pump, 162 cm3/rev, Flange mount, 17.2 MPa | Yuken | Series: PV2R4A | Type: Single Vane Pump | Theoretical Displacement: 162 cm3/rev | Max Working Pressure: 17.2 MPa | Mounting: F = Flange type | Rotation: R = Clockwise (standard, viewed from shaft end) | Discharge Port: A = Top (standard) | Suction Port: A = Top (standard) | Design No: 10 | Options: Counter-clockwise (reverse) rotation available to order (RFQ); Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| PV2R4A-193-L-RAA-10 | PV2R4A single vane pump, 193 cm3/rev, Foot mount, 17.2 MPa | Yuken | Series: PV2R4A | Type: Single Vane Pump | Theoretical Displacement: 193 cm3/rev | Max Working Pressure: 17.2 MPa | Mounting: L = Foot type | Rotation: R = Clockwise (standard, viewed from shaft end) | Discharge Port: A = Top (standard) | Suction Port: A = Top (standard) | Design No: 10 | Options: Counter-clockwise (reverse) rotation available to order (RFQ); Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) | ||
| PV2R4A-193-F-RAA-10 | PV2R4A single vane pump, 193 cm3/rev, Flange mount, 17.2 MPa | Yuken | Series: PV2R4A | Type: Single Vane Pump | Theoretical Displacement: 193 cm3/rev | Max Working Pressure: 17.2 MPa | Mounting: F = Flange type | Rotation: R = Clockwise (standard, viewed from shaft end) | Discharge Port: A = Top (standard) | Suction Port: A = Top (standard) | Design No: 10 | Options: Counter-clockwise (reverse) rotation available to order (RFQ); Phosphate-ester fluid version available: prefix model code with 'F-' (fluoro-rubber seals) |
