[Yuken] — A7H Series High Pressure Variable Displacement Piston Pump (Constant Power Control, 180-270 cm3/rev)
Piston Pumps Yuken

[Yuken] — A7H Series High Pressure Variable Displacement Piston Pump (Constant Power Control, 180-270 cm3/rev)

Family ID: YUKEN-A7H-09

"A7H" Series Variable Displacement Piston Pumps - Single Pump, Constant Power Control Type.

8 product codes available in this family

RFQ Cart (0)

Product Codes & Specifications

Product Code Description Brand Spec
A7H180-FR09S-11 Yuken A7H180 (180 cm3/rev) constant power without external pilot, Flange mount Yuken Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: No | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H180-FR09RS-11 Yuken A7H180 (180 cm3/rev) constant power with external pilot, Flange mount Yuken Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: Yes (R) | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H180-LR09S-11 Yuken A7H180 (180 cm3/rev) constant power without external pilot, Foot mount Yuken Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: No | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H180-LR09RS-11 Yuken A7H180 (180 cm3/rev) constant power with external pilot, Foot mount Yuken Series: A7H | Frame: A7H180 | Geometric Displacement: 180 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: Yes (R) | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1800 r/min rated, 1900 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-FR09S-11 Yuken A7H265 (270 cm3/rev) constant power without external pilot, Flange mount Yuken Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: No | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-FR09RS-11 Yuken A7H265 (270 cm3/rev) constant power with external pilot, Flange mount Yuken Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Flange | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: Yes (R) | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-LR09S-11 Yuken A7H265 (270 cm3/rev) constant power without external pilot, Foot mount Yuken Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: No | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
A7H265-LR09RS-11 Yuken A7H265 (270 cm3/rev) constant power with external pilot, Foot mount Yuken Series: A7H | Frame: A7H265 | Geometric Displacement: 270 cm3/rev | Mounting: Foot | Direction of Rotation: Clockwise (viewed from shaft end) | Control Type: Constant Power Control (09) | External Pilot: Yes (R) | Min. Flow Adjustment: Provided | Port Position: Side port | Power Control Code: Specify at order (-M1 etc., RFQ) | Rated Pressure: 35 MPa | Max. Working Pressure: 40 MPa | Allowable Speed: 1200 r/min rated, 1600 r/min max (self-priming) | Configuration: Port flange (included / N=none), 2nd-pump SAE mount (A/B/C/CC/D or end-cover), 09 power code (-M1) - specify at order (RFQ) | Design Number: 11
