[YUKEN] - CJT210 21MPa Hydraulic Cylinder (LA Foot Mount)
Family ID: YK-CJT210-LA
YUKEN CJT210 Series 21 MPa standard hydraulic cylinder. Used for a wide range of applications including machine tools and general industrial machinery, realizing high-pressure operation at a nominal pressure of 21 MPa. Bore sizes 40-160 mm, B-series rod. LA Foot Mount support. Conforms to former JIS B8354. Stroke is made-to-order - specify the required stroke.
8 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| CJT210-LA-40-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 40mm bore, B-rod d22mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 40 mm | Rod: B-series d22 mm | Design No.: 30 | Max Stroke: 1600 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-40B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-50-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 50mm bore, B-rod d28mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 50 mm | Rod: B-series d28 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-50B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-63-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 63mm bore, B-rod d36mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 63 mm | Rod: B-series d36 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-63B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-80-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 80mm bore, B-rod d45mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 80 mm | Rod: B-series d45 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-80B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-100-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 100mm bore, B-rod d56mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 100 mm | Rod: B-series d56 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-100B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-125-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 125mm bore, B-rod d70mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 125 mm | Rod: B-series d70 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-125B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-140-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 140mm bore, B-rod d80mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 140 mm | Rod: B-series d80 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-140B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 | ||
| CJT210-LA-160-B-30 | CJT210 21MPa Hydraulic Cylinder, LA support, 160mm bore, B-rod d90mm, design 30 | YUKEN | Series: CJT210 (21 MPa standard hydraulic cylinder) | Nominal Pressure: 21 MPa | Max Allowable Pressure: Cap side 24.5 MPa / Rod side 26.5 MPa | Proof Pressure: 31.5 MPa | Support: LA - Foot type (axial right-angle) | Bore: 160 mm | Rod: B-series d90 mm | Design No.: 30 | Max Stroke: 2000 mm | Stroke: Made-to-order (specify required stroke) | Cushion: B: both ends / R: rod side / H: cap side / N: none | Port Direction: A: top (std) / B: right / C: bottom / D: left (viewed from rod side) | Cushion Valve Direction: B: right (std) / A: top / C: bottom / D: left / N: none | Air Bleed Direction: D: left (std) / A: top / B: right / C: bottom | Option: E: rod-end male thread / F,G,H: dust cover (nylon-tarpaulin 80C / chloroprene 130C / connex 200C) / K: lock screw (with E) / L: 1-piece rod-end metal / M: 2-piece rod-end metal | Packing: no symbol: NBR (std) / F: FKM / 6: HNBR | Standard: former JIS B8354 | Full Code: [F/6]CJT210-LA-160B-[stroke]-[B/R/H/N]-[port][valve][bleed]-[E/F/G/H/K/L/M]-30 |
