[YUKEN] - Mini Series KM Hydraulic Cylinder (made-to-order / RFQ)
Family ID: YK-MINI-KM
YUKEN Mini Series hydraulic cylinder (KM). A compact hydraulic cylinder developed for space-saving applications such as small machine tools and medical devices, where miniaturization is required. Offers a rich selection of support styles, and can be combined with other Mini Series components such as solenoid valves to build a mini hydraulic system. Detailed specifications are made-to-order - please consult Yuken.
3 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| KM-20 | Mini Series KM hydraulic cylinder, 20mm bore, made-to-order (RFQ) | YUKEN | Series: Mini Series KM (compact hydraulic cylinder, made-to-order) | Bore: 20 mm | Max Operating Pressure: 7 MPa | Allowable Surge Pressure: 10.5 MPa | Proof Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less (double-rod: 0.5 MPa or less) | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +80 C | Rod Configuration: Single / double rod available (consult) | Design No.: 01 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: KM[var]-[size]x[rod]-[support]-[stroke]-[..]-[..]-01 | ||
| KM-25 | Mini Series KM hydraulic cylinder, 25mm bore, made-to-order (RFQ) | YUKEN | Series: Mini Series KM (compact hydraulic cylinder, made-to-order) | Bore: 25 mm | Max Operating Pressure: 7 MPa | Allowable Surge Pressure: 10.5 MPa | Proof Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less (double-rod: 0.5 MPa or less) | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +80 C | Rod Configuration: Single / double rod available (consult) | Design No.: 01 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: KM[var]-[size]x[rod]-[support]-[stroke]-[..]-[..]-01 | ||
| KM-30 | Mini Series KM hydraulic cylinder, 30mm bore, made-to-order (RFQ) | YUKEN | Series: Mini Series KM (compact hydraulic cylinder, made-to-order) | Bore: 30 mm | Max Operating Pressure: 7 MPa | Allowable Surge Pressure: 10.5 MPa | Proof Pressure: 10.5 MPa | Min Operating Pressure: 0.3 MPa or less (double-rod: 0.5 MPa or less) | Support (selectable): ST, LB, FA, CA, TA, TB | Max Stroke: 300 mm (may be limited lower by buckling strength - consult) | Speed Range: 10-300 mm/s | Ambient/Oil Temp: -10 to +80 C | Rod Configuration: Single / double rod available (consult) | Design No.: 01 | Ordering: Made-to-order - consult Yuken for full configuration | Full Code: KM[var]-[size]x[rod]-[support]-[stroke]-[..]-[..]-01 |
