[YUKEN] — CJT210C 21MPa Compact Hydraulic Cylinder (TC Intermediate fixed trunnion, Bore 40-160mm, Rod A/B)
Family ID: YK-CJT210C-TC
YUKEN's 21 MPa Series compact type hydraulic cylinders realize a high working pressure of 21 MPa for wide use across machine tools and general industrial machinery. Compared with conventional 21 MPa standard hydraulic cylinders, the external dimensions are smaller, enabling compact equipment design. A proximity-switch-equipped version, which mounts a slide-type proximity switch on the cylinder body for position detection, is also available as a series (see catalog page J-69). Nominal pressure 21 MPa; bore 40-160 mm; mounting styles SD/LA/FA/FB/CA/TC; rod series A/B. This listing is the TC mounting type (Intermediate fixed trunnion / 중간 고정 트라니온형); rod A/B selectable.
16 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| CJT210C-TC-40-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod A (dia 28mm), max stroke 1600mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 40 mm | Rod: A — A series (high-strength), dia 28 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-40-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 40mm, rod B (dia 22mm), max stroke 1600mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 40 mm | Rod: B — B series (standard), dia 22 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 1600 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-50-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod A (dia 36mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 50 mm | Rod: A — A series (high-strength), dia 36 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-50-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 50mm, rod B (dia 28mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 50 mm | Rod: B — B series (standard), dia 28 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-63-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod A (dia 45mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 63 mm | Rod: A — A series (high-strength), dia 45 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-63-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 63mm, rod B (dia 36mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 63 mm | Rod: B — B series (standard), dia 36 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-400 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-80-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod A (dia 56mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 80 mm | Rod: A — A series (high-strength), dia 56 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 28 mm / rod-B 14 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-80-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 80mm, rod B (dia 45mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 80 mm | Rod: B — B series (standard), dia 45 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 28 mm / rod-B 14 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-100-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod A (dia 70mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 100 mm | Rod: A — A series (high-strength), dia 70 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 33 mm / rod-B 21 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-100-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 100mm, rod B (dia 56mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 100 mm | Rod: B — B series (standard), dia 56 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 33 mm / rod-B 21 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-125-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod A (dia 90mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 125 mm | Rod: A — A series (high-strength), dia 90 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 48 mm / rod-B 34 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-125-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 125mm, rod B (dia 70mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 125 mm | Rod: B — B series (standard), dia 70 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-300 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 48 mm / rod-B 34 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-140-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod A (dia 100mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 140 mm | Rod: A — A series (high-strength), dia 100 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 52 mm / rod-B 38 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-140-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 140mm, rod B (dia 80mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 140 mm | Rod: B — B series (standard), dia 80 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 52 mm / rod-B 38 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-160-A | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod A (dia 110mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 160 mm | Rod: A — A series (high-strength), dia 110 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 26.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.6 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 55 mm / rod-B 41 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 | ||
| CJT210C-TC-160-B | CJT210C 21MPa compact hydraulic cylinder, Intermediate fixed trunnion (TC), bore 160mm, rod B (dia 90mm), max stroke 2000mm | YUKEN | Series: CJT210C (21MPa Compact Hydraulic Cylinder) | Mounting: TC — Intermediate fixed trunnion / 중간 고정 트라니온형 | Bore: 160 mm | Rod: B — B series (standard), dia 90 mm | Nominal Pressure: 21 MPa | Proof Pressure (cap side): 26.5 MPa | Proof Pressure (rod side): 24.5 MPa | Internal/Burst Pressure: 31.5 MPa | Min Operating Pressure: rod side 0.45 MPa or less, cap side 0.3 MPa or less | Operating Speed: 8-200 mm/s | Max Stroke: 2000 mm | Stroke: specify at order (made-to-order, within max) | Min Stroke (TC mount): rod-A 55 mm / rod-B 41 mm | Cushion: B both ends / R rod side / H cap side / N none (specify) | Port direction: A up(std) / B right / C down / D left | Cushion-valve direction: B right(std) / A up / C down / D left | Air-bleed direction: D left(std) / A up / B right / C down / N none | Options: E rod-end long thread, F/G/H dust cover, K fixing nut, L/M rod-end fitting (rod-B only) | Packing: Nitrile(std) / F fluoro / 6 H-NBR | Rod Thread: JIS B0211-6g (class 2) | Ambient Temp: -10 to +80 C | Standard: former JIS B8354 | Design No.: 20 | Full Code: F-CJT210C-[mount]-[bore]-[rod]-[stroke]-[cushion]-[dir3]-[option]-20 |
