![[Yuken] — EDFG-01 Shockless Proportional Directional & Flow Control Valve (E series, 25 MPa, rated 30 L/min)](https://img.prosourcemro.com/2026/05/002-134-1024x674.png)
[Yuken] — EDFG-01 Shockless Proportional Directional & Flow Control Valve (E series, 25 MPa, rated 30 L/min)
Family ID: YK-EDFG-01
Shockless Type Proportional Electro-Hydraulic Directional and Flow Control Valves. Inherits the shockless concept of the variable-shockless 'G-series solenoid valve' to enable high-speed speed setting; speed, acceleration/deceleration and direction of an actuator can all be handled in a single valve, simplifying the hydraulic circuit and cutting cost. Use with a dedicated Yuken power amplifier (pattern control AMN-G-10 / analog control AMN-W-10). Sub-plate mounting, valve size 01. Max operating pressure 25 MPa, rated flow 30 L/min, tank port pressure 14 MPa, rated current 1100 mA, coil 10.8Ω. Spool forms 3C2 and 3C40; meter-in/meter-out (XY) control. Step response ≤100 ms.
2 product codes available in this family
Product Codes & Specifications
| Product Code | Description | Brand | Spec | ||
|---|---|---|---|---|---|
| EDFG-01-30-3C2-XY-50 | EDFG-01 Shockless Dir&Flow (E), 3C2, XY, rated 30 L/min | Yuken | Type: Shockless Proportional Directional & Flow Control Valve (E series) | Series: EDFG | Mounting: Sub-plate | Valve Size: 01 | Rated Flow: 30 L/min | Max Pressure: 25 MPa | Tank Port Pressure: 14 MPa | Spool Form: 3C2 | Control Direction: XY (meter-in/meter-out) | Rated Current: 1100 mA | Coil: 10.8Ω | Step Response: ≤100 ms | Drive: Current input (use with dedicated power amplifier) | Design No.: 50 | ||
| EDFG-01-30-3C40-XY-50 | EDFG-01 Shockless Dir&Flow (E), 3C40, XY, rated 30 L/min | Yuken | Type: Shockless Proportional Directional & Flow Control Valve (E series) | Series: EDFG | Mounting: Sub-plate | Valve Size: 01 | Rated Flow: 30 L/min | Max Pressure: 25 MPa | Tank Port Pressure: 14 MPa | Spool Form: 3C40 | Control Direction: XY (meter-in/meter-out) | Rated Current: 1100 mA | Coil: 10.8Ω | Step Response: ≤100 ms | Drive: Current input (use with dedicated power amplifier) | Design No.: 50 |
