Autonics L2RR Series 22 / 25 mm Pilot Lights

Ø 22/25 mm pilot/indicator lights.

Key features

LED illumination
Multiple colors (Red, Green, Yellow, Blue, White). 24 VDC, 110 VAC, and 220 VAC variants

L2RR-2R-L24		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Red 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Red
L2RR-2R-L110		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Red 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Red
L2RR-2R-L220		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Red 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Red
L2RR-2G-L24		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Green 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Green
L2RR-2G-L110		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Green 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Green
L2RR-2G-L220		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Green 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Green
L2RR-2Y-L24		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Yellow 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Yellow
L2RR-2Y-L110		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Yellow 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Yellow
L2RR-2Y-L220		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Yellow 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Yellow
L2RR-2B-L24		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Blue 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Blue
L2RR-2B-L110		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Blue 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Blue
L2RR-2B-L220		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Blue 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Blue
L2RR-2W-L24		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| White 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator White
L2RR-2W-L110		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| White 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator White
L2RR-2W-L220		Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| White 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator White
L2RR-5R-L24		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Red 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Red
L2RR-5R-L110		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Red 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Red
L2RR-5R-L220		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Red 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Red
L2RR-5G-L24		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Green 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Green
L2RR-5G-L110		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Green 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Green
L2RR-5G-L220		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Green 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Green
L2RR-5Y-L24		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Yellow 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Yellow
L2RR-5Y-L110		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Yellow 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Yellow
L2RR-5Y-L220		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Yellow 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Yellow
L2RR-5B-L24		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Blue 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Blue
L2RR-5B-L110		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Blue 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Blue
L2RR-5B-L220		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Blue 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Blue
L2RR-5W-L24		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| White 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator White
L2RR-5W-L110		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| White 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator White
L2RR-5W-L220		Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| White 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator White

Pilot LightAutonics

30 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

Autonics L2RR Series 22 / 25 mm Pilot Lights

Brand Autonics·Pilot Light

Available part numbers (30)

L2RR-2R-L24, L2RR-2R-L110, L2RR-2R-L220, L2RR-2G-L24, L2RR-2G-L110, L2RR-2G-L220, L2RR-2Y-L24, L2RR-2Y-L110, L2RR-2Y-L220, L2RR-2B-L24 + 20 more — see full table ↓

How to order

Send the Autonics part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	L2RR-2R-L24	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Red 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Red
	L2RR-2R-L110	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Red 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Red
	L2RR-2R-L220	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Red 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Red
	L2RR-2G-L24	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Green 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Green
	L2RR-2G-L110	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Green 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Green
	L2RR-2G-L220	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Green 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Green
	L2RR-2Y-L24	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Yellow 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Yellow
	L2RR-2Y-L110	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Yellow 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Yellow
	L2RR-2Y-L220	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Yellow 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Yellow
	L2RR-2B-L24	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Blue 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator Blue
	L2RR-2B-L110	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Blue 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Blue
	L2RR-2B-L220	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| Blue 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator Blue
	L2RR-2W-L24	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| White 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 22 mm indicator White
	L2RR-2W-L110	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| White 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator White
	L2RR-2W-L220	Pilot light \| L2RR Series \| Ø 22 mm pilot lamp \| White 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 22 mm indicator White
	L2RR-5R-L24	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Red 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Red
	L2RR-5R-L110	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Red 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Red
	L2RR-5R-L220	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Red 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Red
	L2RR-5G-L24	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Green 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Green
	L2RR-5G-L110	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Green 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Green
	L2RR-5G-L220	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Green 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Green
	L2RR-5Y-L24	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Yellow 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Yellow
	L2RR-5Y-L110	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Yellow 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Yellow
	L2RR-5Y-L220	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Yellow 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Yellow
	L2RR-5B-L24	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Blue 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator Blue
	L2RR-5B-L110	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Blue 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Blue
	L2RR-5B-L220	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| Blue 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator Blue
	L2RR-5W-L24	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| White 24 VDC \| LED \| 24 VDC \| Screw terminal \| IP65 \| Ø 25 mm indicator White
	L2RR-5W-L110	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| White 110 VAC \| LED \| 110 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator White
	L2RR-5W-L220	Pilot light \| L2RR Series \| Ø 25 mm pilot lamp \| White 220 VAC \| LED \| 220 VAC \| Screw terminal \| IP65 \| Ø 25 mm indicator White
