CBK SN5F Plummer Block Housings (Without Bolt Holes)

CBK SN5F Plummer Block Housings (Without Bolt Holes)

CBK SN5F split plummer block housings in cast iron; shaft 20-140 mm; for adapter-sleeve bearings.

Key features

  • Two-piece (split) cast housing for easy bearing installation and inspection
  • Accepts self-aligning ball and spherical roller bearings
  • Seals and locating rings ordered according to arrangement
  • Dimensions and mass per size as listed in the catalogue

Specifications

Product Split plummer block housing
Series SN5F
Material Cast iron
Application shaft 20-140 mm; for adapter-sleeve bearings
Brand CBK
Source CBK Bearing Housing & Ball Bearing Units catalogue, p. 155
SN505F Shaft: 20 mm | Bearing OD: 52 mm | H: 40 mm | L: 165 mm | Mass: 1.8 kg
SN506F Shaft: 25 mm | Bearing OD: 62 mm | H: 50 mm | L: 185 mm | Mass: 2.6 kg
SN507F Shaft: 30 mm | Bearing OD: 72 mm | H: 50 mm | L: 185 mm | Mass: 3 kg
SN508F Shaft: 35 mm | Bearing OD: 80 mm | H: 60 mm | L: 205 mm | Mass: 3.9 kg
SN509F Shaft: 40 mm | Bearing OD: 85 mm | H: 60 mm | L: 205 mm | Mass: 4 kg
SN510F Shaft: 45 mm | Bearing OD: 90 mm | H: 60 mm | L: 205 mm | Mass: 5 kg
SN511F Shaft: 50 mm | Bearing OD: 100 mm | H: 70 mm | L: 255 mm | Mass: 6 kg
SN512F Shaft: 55 mm | Bearing OD: 110 mm | H: 70 mm | L: 255 mm | Mass: 5.8 kg
SN513F Shaft: 60 mm | Bearing OD: 120 mm | H: 80 mm | L: 275 mm | Mass: 7.8 kg
SN515F Shaft: 65 mm | Bearing OD: 130 mm | H: 80 mm | L: 280 mm | Mass: 8 kg
SN516F Shaft: 70 mm | Bearing OD: 140 mm | H: 95 mm | L: 315 mm | Mass: 12 kg
SN517F Shaft: 75 mm | Bearing OD: 150 mm | H: 95 mm | L: 320 mm | Mass: 13 kg
SN518F Shaft: 80 mm | Bearing OD: 160 mm | H: 100 mm | L: 345 mm | Mass: 18 kg
SN519F Shaft: 85 mm | Bearing OD: 170 mm | H: 112 mm | L: 345 mm | Mass: 20 kg
SN520F Shaft: 90 mm | Bearing OD: 180 mm | H: 112 mm | L: 380 mm | Mass: 22 kg
SN522F Shaft: 100 mm | Bearing OD: 200 mm | H: 125 mm | L: 410 mm | Mass: 28 kg
SN524F Shaft: 110 mm | Bearing OD: 215 mm | H: 140 mm | L: 410 mm | Mass: 31 kg
SN526F Shaft: 115 mm | Bearing OD: 230 mm | H: 150 mm | L: 445 mm | Mass: 42 kg
SN528F Shaft: 125 mm | Bearing OD: 250 mm | H: 150 mm | L: 500 mm | Mass: 56 kg
SN530F Shaft: 135 mm | Bearing OD: 270 mm | H: 160 mm | L: 530 mm | Mass: 61 kg
SN532F Shaft: 140 mm | Bearing OD: 290 mm | H: 170 mm | L: 550 mm | Mass: 68 kg
