CBK UCIP2 Pillow Block Units (Light Series, Set Screw)

CBK UCIP2 pillow block units combine a heavy-duty cast iron pillow block (IP) housing with a UC set-screw insert bearing. Shaft sizes and housing designations follow the CBK dimension tables.

Key features

Heavy-duty cast iron pillow block (IP) housing
Fitted with UC set-screw insert bearing
Self-aligning spherical outside diameter compensates for shaft misalignment
Pre-greased, sealed deep groove ball bearing insert
Metric and inch shaft sizes as listed (inch sizes marked with -dash numbers in 1/16 in)

Specifications

Product	Mounted ball bearing unit (pillow block unit)
Unit series	UCIP2
Housing	heavy-duty cast iron pillow block (IP) housing
Insert bearing	UC set-screw insert bearing
Codes	6 sizes
Source	CBK Bearing Housing & Ball Bearing Units catalogue, p. 52

UCIP208		Shaft: 40 mm \| Bearing: UC208 \| Housing: IP208 \| Mass: 3.5 kg
UCIP209		Shaft: 45 mm \| Bearing: UC209 \| Housing: IP209 \| Mass: 3.8 kg
UCIP210		Shaft: 50 mm \| Bearing: UC210 \| Housing: IP210 \| Mass: 4.4 kg
UCIP211		Shaft: 55 mm \| Bearing: UC211 \| Housing: IP211 \| Mass: 5.5 kg
UCIP212		Shaft: 60 mm \| Bearing: UC212 \| Housing: IP212 \| Mass: 6 kg
UCIP213		Shaft: 65 mm \| Bearing: UC213 \| Housing: IP213 \| Mass: 7.6 kg

Mounted Bearing UnitsCBK

6 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CBK UCIP2 Pillow Block Units (Light Series, Set Screw)

Brand CBK·Mounted Bearing Units

Available part numbers (6)

UCIP208, UCIP209, UCIP210, UCIP211, UCIP212, UCIP213

How to order

Send the CBK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	UCIP208	Shaft: 40 mm \| Bearing: UC208 \| Housing: IP208 \| Mass: 3.5 kg
	UCIP209	Shaft: 45 mm \| Bearing: UC209 \| Housing: IP209 \| Mass: 3.8 kg
	UCIP210	Shaft: 50 mm \| Bearing: UC210 \| Housing: IP210 \| Mass: 4.4 kg
	UCIP211	Shaft: 55 mm \| Bearing: UC211 \| Housing: IP211 \| Mass: 5.5 kg
	UCIP212	Shaft: 60 mm \| Bearing: UC212 \| Housing: IP212 \| Mass: 6 kg
	UCIP213	Shaft: 65 mm \| Bearing: UC213 \| Housing: IP213 \| Mass: 7.6 kg

Need a different model, or a part not listed here? Send us your parts list →
