CBK UCIP3 Pillow Block Units (Medium-Heavy Series, Set Screw)

CBK UCIP3 pillow block units combine a heavy-duty cast iron pillow block (IP) housing with a UC set-screw insert bearing. Shaft sizes and housing designations follow the CBK dimension tables.

Key features

Heavy-duty cast iron pillow block (IP) housing
Fitted with UC set-screw insert bearing
Self-aligning spherical outside diameter compensates for shaft misalignment
Pre-greased, sealed deep groove ball bearing insert
Metric and inch shaft sizes as listed (inch sizes marked with -dash numbers in 1/16 in)

Specifications

Product	Mounted ball bearing unit (pillow block unit)
Unit series	UCIP3
Housing	heavy-duty cast iron pillow block (IP) housing
Insert bearing	UC set-screw insert bearing
Codes	12 sizes
Source	CBK Bearing Housing & Ball Bearing Units catalogue, p. 54

UCIP313		Shaft: 65 mm \| Bearing: UC313 \| Housing: IP313 \| Mass: 13 kg
UCIP314		Shaft: 70 mm \| Bearing: UC314 \| Housing: IP314 \| Mass: 15 kg
UCIP315		Shaft: 75 mm \| Bearing: UC315 \| Housing: IP315 \| Mass: 16 kg
UCIP316		Shaft: 80 mm \| Bearing: UC316 \| Housing: IP316 \| Mass: 21 kg
UCIP317		Shaft: 85 mm \| Bearing: UC317 \| Housing: IP317 \| Mass: 23 kg
UCIP318		Shaft: 90 mm \| Bearing: UC318 \| Housing: IP318 \| Mass: 26 kg
UCIP319		Shaft: 95 mm \| Bearing: UC319 \| Housing: IP319 \| Mass: 30 kg
UCIP320		Shaft: 100 mm \| Bearing: UC320 \| Housing: IP320 \| Mass: 34 kg
UCIP322		Shaft: 110 mm \| Bearing: UC322 \| Housing: IP322 \| Mass: 51 kg
UCIP324		Shaft: 120 mm \| Bearing: UC324 \| Housing: IP324 \| Mass: 57 kg
UCIP326		Shaft: 130 mm \| Bearing: UC326 \| Housing: IP326 \| Mass: 75 kg
UCIP328		Shaft: 140 mm \| Bearing: UC328 \| Housing: IP328 \| Mass: 84 kg

Mounted Bearing UnitsCBK

12 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CBK UCIP3 Pillow Block Units (Medium-Heavy Series, Set Screw)

Brand CBK·Mounted Bearing Units

Available part numbers (12)

UCIP313, UCIP314, UCIP315, UCIP316, UCIP317, UCIP318, UCIP319, UCIP320, UCIP322, UCIP324 + 2 more — see full table ↓
