CBK UCPE2 Pillow Block Units (Light Series, Set Screw)

CBK UCPE2 pillow block units combine a pillow block (PE) housing with a UC set-screw insert bearing. Shaft sizes and housing designations follow the CBK dimension tables.

Key features

Pillow block (PE) housing
Fitted with UC set-screw insert bearing
Self-aligning spherical outside diameter compensates for shaft misalignment
Pre-greased, sealed deep groove ball bearing insert
Metric and inch shaft sizes as listed (inch sizes marked with -dash numbers in 1/16 in)

Specifications

Product	Mounted ball bearing unit (pillow block unit)
Unit series	UCPE2
Housing	pillow block (PE) housing
Insert bearing	UC set-screw insert bearing
Codes	37 sizes
Source	CBK Bearing Housing & Ball Bearing Units catalogue, p. 88

UCPE201		Shaft: 12 mm \| Bearing: UC201 \| Housing: PE204 \| Mass: 0.92 kg
UCPE201-8		Shaft: 1/2 in \| Bearing: UC201-8 \| Housing: PE204 \| Mass: 0.92 kg
UCPE202		Shaft: 15 mm \| Bearing: UC202 \| Housing: PE204 \| Mass: 0.92 kg
UCPE202-10		Shaft: 5/8 in \| Bearing: UC202-10 \| Housing: PE204 \| Mass: 0.92 kg
UCPE203		Shaft: 17 mm \| Bearing: UC203 \| Housing: PE204 \| Mass: 0.92 kg
UCPE204-12		Shaft: 3/4 in \| Bearing: UC204-12 \| Housing: PE204 \| Mass: 0.92 kg
UCPE204		Shaft: 20 mm \| Bearing: UC204 \| Housing: PE204 \| Mass: 0.92 kg
UCPE205-14		Shaft: 7/8 in \| Bearing: UC205-14 \| Housing: PE205 \| Mass: 1.5 kg
UCPE205-15		Shaft: 15/16 in \| Bearing: UC205-15 \| Housing: PE205 \| Mass: 1.5 kg
UCPE205		Shaft: 25 mm \| Bearing: UC205 \| Housing: PE205 \| Mass: 1.5 kg
UCPE205-16		Shaft: 1 in \| Bearing: UC205-16 \| Housing: PE205 \| Mass: 1.5 kg
UCPE206-18		Shaft: 1-1/8 in \| Bearing: UC206-18 \| Housing: PE206 \| Mass: 2 kg
UCPE206		Shaft: 30 mm \| Bearing: UC206 \| Housing: PE206 \| Mass: 2 kg
UCPE206-19		Shaft: 1-3/16 in \| Bearing: UC206-19 \| Housing: PE206 \| Mass: 2 kg
UCPE207-20		Shaft: 1-1/4 in \| Bearing: UC207-20 \| Housing: PE207 \| Mass: 2.7 kg
UCPE207-21		Shaft: 1-5/16 in \| Bearing: UC207-21 \| Housing: PE207 \| Mass: 2.7 kg
UCPE207-22		Shaft: 1-3/8 in \| Bearing: UC207-22 \| Housing: PE207 \| Mass: 2.7 kg
UCPE207		Shaft: 35 mm \| Bearing: UC207 \| Housing: PE207 \| Mass: 2.7 kg
UCPE207-23		Shaft: 1-7/16 in \| Bearing: UC207-23 \| Housing: PE207 \| Mass: 2.7 kg
UCPE208-24		Shaft: 1-1/2 in \| Bearing: UC208-24 \| Housing: PE208 \| Mass: 3.3 kg
UCPE208-25		Shaft: 1-9/16 in \| Bearing: UC208-25 \| Housing: PE208 \| Mass: 3.3 kg
UCPE208		Shaft: 40 mm \| Bearing: UC208 \| Housing: PE208 \| Mass: 3.3 kg
UCPE209-26		Shaft: 1-5/8 in \| Bearing: UC209-26 \| Housing: PE209 \| Mass: 3.4 kg
UCPE209-27		Shaft: 1-11/16 in \| Bearing: UC209-27 \| Housing: PE209 \| Mass: 3.4 kg
UCPE209-28		Shaft: 1-3/4 in \| Bearing: UC209-28 \| Housing: PE209 \| Mass: 3.4 kg
UCPE209		Shaft: 45 mm \| Bearing: UC209 \| Housing: PE209 \| Mass: 3.4 kg
UCPE210-30		Shaft: 1-7/8 in \| Bearing: UC210-30 \| Housing: PE210 \| Mass: 4.3 kg
UCPE210-31		Shaft: 1-15/16 in \| Bearing: UC210-31 \| Housing: PE210 \| Mass: 4.3 kg
UCPE210		Shaft: 50 mm \| Bearing: UC210 \| Housing: PE210 \| Mass: 4.3 kg
UCPE211-32		Shaft: 2 in \| Bearing: UC211-32 \| Housing: PE211 \| Mass: 6.2 kg
UCPE211-34		Shaft: 2-1/8 in \| Bearing: UC211-34 \| Housing: PE211 \| Mass: 6.2 kg
UCPE211		Shaft: 55 mm \| Bearing: UC211 \| Housing: PE211 \| Mass: 6.2 kg
UCPE211-35		Shaft: 2-3/16 in \| Bearing: UC211-35 \| Housing: PE211 \| Mass: 6.2 kg
UCPE212-36		Shaft: 2-1/4 in \| Bearing: UC212-36 \| Housing: PE212 \| Mass: 7.6 kg
UCPE212		Shaft: 60 mm \| Bearing: UC212 \| Housing: PE212 \| Mass: 7.6 kg
UCPE212-38		Shaft: 2-3/8 in \| Bearing: UC212-38 \| Housing: PE212 \| Mass: 7.6 kg
UCPE212-39		Shaft: 2-7/16 in \| Bearing: UC212-39 \| Housing: PE212 \| Mass: 7.6 kg

Mounted Bearing UnitsCBK

37 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CBK UCPE2 Pillow Block Units (Light Series, Set Screw)

Brand CBK·Mounted Bearing Units

Available part numbers (37)

UCPE201, UCPE201-8, UCPE202, UCPE202-10, UCPE203, UCPE204-12, UCPE204, UCPE205-14, UCPE205-15, UCPE205 + 27 more — see full table ↓

How to order

Send the CBK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →

View full details

Product codes & specifications

0 selected

RFQ List (0)

	Product code	Spec
	UCPE201	Shaft: 12 mm \| Bearing: UC201 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE201-8	Shaft: 1/2 in \| Bearing: UC201-8 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE202	Shaft: 15 mm \| Bearing: UC202 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE202-10	Shaft: 5/8 in \| Bearing: UC202-10 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE203	Shaft: 17 mm \| Bearing: UC203 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE204-12	Shaft: 3/4 in \| Bearing: UC204-12 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE204	Shaft: 20 mm \| Bearing: UC204 \| Housing: PE204 \| Mass: 0.92 kg
	UCPE205-14	Shaft: 7/8 in \| Bearing: UC205-14 \| Housing: PE205 \| Mass: 1.5 kg
	UCPE205-15	Shaft: 15/16 in \| Bearing: UC205-15 \| Housing: PE205 \| Mass: 1.5 kg
	UCPE205	Shaft: 25 mm \| Bearing: UC205 \| Housing: PE205 \| Mass: 1.5 kg
	UCPE205-16	Shaft: 1 in \| Bearing: UC205-16 \| Housing: PE205 \| Mass: 1.5 kg
	UCPE206-18	Shaft: 1-1/8 in \| Bearing: UC206-18 \| Housing: PE206 \| Mass: 2 kg
	UCPE206	Shaft: 30 mm \| Bearing: UC206 \| Housing: PE206 \| Mass: 2 kg
	UCPE206-19	Shaft: 1-3/16 in \| Bearing: UC206-19 \| Housing: PE206 \| Mass: 2 kg
	UCPE207-20	Shaft: 1-1/4 in \| Bearing: UC207-20 \| Housing: PE207 \| Mass: 2.7 kg
	UCPE207-21	Shaft: 1-5/16 in \| Bearing: UC207-21 \| Housing: PE207 \| Mass: 2.7 kg
	UCPE207-22	Shaft: 1-3/8 in \| Bearing: UC207-22 \| Housing: PE207 \| Mass: 2.7 kg
	UCPE207	Shaft: 35 mm \| Bearing: UC207 \| Housing: PE207 \| Mass: 2.7 kg
	UCPE207-23	Shaft: 1-7/16 in \| Bearing: UC207-23 \| Housing: PE207 \| Mass: 2.7 kg
	UCPE208-24	Shaft: 1-1/2 in \| Bearing: UC208-24 \| Housing: PE208 \| Mass: 3.3 kg
	UCPE208-25	Shaft: 1-9/16 in \| Bearing: UC208-25 \| Housing: PE208 \| Mass: 3.3 kg
	UCPE208	Shaft: 40 mm \| Bearing: UC208 \| Housing: PE208 \| Mass: 3.3 kg
	UCPE209-26	Shaft: 1-5/8 in \| Bearing: UC209-26 \| Housing: PE209 \| Mass: 3.4 kg
	UCPE209-27	Shaft: 1-11/16 in \| Bearing: UC209-27 \| Housing: PE209 \| Mass: 3.4 kg
	UCPE209-28	Shaft: 1-3/4 in \| Bearing: UC209-28 \| Housing: PE209 \| Mass: 3.4 kg
	UCPE209	Shaft: 45 mm \| Bearing: UC209 \| Housing: PE209 \| Mass: 3.4 kg
	UCPE210-30	Shaft: 1-7/8 in \| Bearing: UC210-30 \| Housing: PE210 \| Mass: 4.3 kg
	UCPE210-31	Shaft: 1-15/16 in \| Bearing: UC210-31 \| Housing: PE210 \| Mass: 4.3 kg
	UCPE210	Shaft: 50 mm \| Bearing: UC210 \| Housing: PE210 \| Mass: 4.3 kg
	UCPE211-32	Shaft: 2 in \| Bearing: UC211-32 \| Housing: PE211 \| Mass: 6.2 kg
	UCPE211-34	Shaft: 2-1/8 in \| Bearing: UC211-34 \| Housing: PE211 \| Mass: 6.2 kg
	UCPE211	Shaft: 55 mm \| Bearing: UC211 \| Housing: PE211 \| Mass: 6.2 kg
	UCPE211-35	Shaft: 2-3/16 in \| Bearing: UC211-35 \| Housing: PE211 \| Mass: 6.2 kg
	UCPE212-36	Shaft: 2-1/4 in \| Bearing: UC212-36 \| Housing: PE212 \| Mass: 7.6 kg
	UCPE212	Shaft: 60 mm \| Bearing: UC212 \| Housing: PE212 \| Mass: 7.6 kg
	UCPE212-38	Shaft: 2-3/8 in \| Bearing: UC212-38 \| Housing: PE212 \| Mass: 7.6 kg
	UCPE212-39	Shaft: 2-7/16 in \| Bearing: UC212-39 \| Housing: PE212 \| Mass: 7.6 kg
