CBK UKCX Cartridge Units (Medium Series, Adapter Mount)

CBK UKCX Cartridge Units (Medium Series, Adapter Mount)

CBK UKCX cartridge units combine a cylindrical cartridge (C) housing with a UK tapered-bore insert bearing on adapter sleeve. Shaft sizes and housing designations follow the CBK dimension tables.

Key features

  • Cylindrical cartridge (C) housing with adapter-mounted insert
  • Fitted with UK tapered-bore insert bearing on adapter sleeve
  • Self-aligning spherical outside diameter compensates for shaft misalignment
  • Pre-greased, sealed deep groove ball bearing insert
  • Adapter sleeve mounting locks the bearing on plain shafts without set screws

Specifications

Product Mounted ball bearing unit (cartridge unit)
Unit series UKCX
Housing cylindrical cartridge (C) housing
Insert bearing UK tapered-bore insert bearing on adapter sleeve
Codes 8 sizes
Adapter sleeve H23 series (ordered separately or as set)
Source CBK Bearing Housing & Ball Bearing Units catalogue, p. 83
UKCX05 Shaft: 20 mm (adapter) | Bearing: UKX05 | Housing: CX05 | Mass: 0.99 kg
UKCX06 Shaft: 25 mm (adapter) | Bearing: UKX06 | Housing: CX06 | Mass: 1.3 kg
UKCX07 Shaft: 30 mm (adapter) | Bearing: UKX07 | Housing: CX07 | Mass: 1.7 kg
UKCX08 Shaft: 35 mm (adapter) | Bearing: UKX08 | Housing: CX08 | Mass: 2.3 kg
UKCX09 Shaft: 40 mm (adapter) | Bearing: UKX09 | Housing: CX09 | Mass: 2.3 kg
UKCX10 Shaft: 45 mm (adapter) | Bearing: UKX10 | Housing: CX10 | Mass: 2.8 kg
UKCX11 Shaft: 50 mm (adapter) | Bearing: UKX11 | Housing: CX11 | Mass: 3.8 kg
UKCX12 Shaft: 55 mm (adapter) | Bearing: UKX12 | Housing: CX12 | Mass: 4.4 kg
Mounted Bearing UnitsCBK
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CBK UKCX Cartridge Units (Medium Series, Adapter Mount)

Brand CBK·Mounted Bearing Units

Available part numbers (8)

UKCX05, UKCX06, UKCX07, UKCX08, UKCX09, UKCX10, UKCX11, UKCX12

How to order

Send the CBK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
