CBK UKIP3 Pillow Block Units (Medium-Heavy Series, Adapter Mount)

CBK UKIP3 Pillow Block Units (Medium-Heavy Series, Adapter Mount)

CBK UKIP3 pillow block units combine a heavy-duty cast iron pillow block (IP) housing with a UK tapered-bore insert bearing on adapter sleeve. Shaft sizes and housing designations follow the CBK dimension tables.

Key features

  • Heavy-duty cast iron pillow block (IP) housing with adapter-mounted insert
  • Fitted with UK tapered-bore insert bearing on adapter sleeve
  • Self-aligning spherical outside diameter compensates for shaft misalignment
  • Pre-greased, sealed deep groove ball bearing insert
  • Adapter sleeve mounting locks the bearing on plain shafts without set screws

Specifications

Product Mounted ball bearing unit (pillow block unit)
Unit series UKIP3
Housing heavy-duty cast iron pillow block (IP) housing
Insert bearing UK tapered-bore insert bearing on adapter sleeve
Codes 11 sizes
Adapter sleeve H23 series (ordered separately or as set)
Source CBK Bearing Housing & Ball Bearing Units catalogue, p. 55
UKIP313 Shaft: 60 mm (adapter) | Bearing: UK313 | Housing: IP313 | Mass: 12 kg
UKIP315 Shaft: 65 mm (adapter) | Bearing: UK315 | Housing: IP315 | Mass: 15 kg
UKIP316 Shaft: 70 mm (adapter) | Bearing: UK316 | Housing: IP316 | Mass: 20 kg
UKIP317 Shaft: 75 mm (adapter) | Bearing: UK317 | Housing: IP317 | Mass: 22 kg
UKIP318 Shaft: 80 mm (adapter) | Bearing: UK318 | Housing: IP318 | Mass: 24 kg
UKIP319 Shaft: 85 mm (adapter) | Bearing: UK319 | Housing: IP319 | Mass: 28 kg
UKIP320 Shaft: 90 mm (adapter) | Bearing: UK320 | Housing: IP320 | Mass: 32 kg
UKIP322 Shaft: 100 mm (adapter) | Bearing: UK322 | Housing: IP322 | Mass: 48 kg
UKIP324 Shaft: 110 mm (adapter) | Bearing: UK324 | Housing: IP324 | Mass: 54 kg
UKIP326 Shaft: 115 mm (adapter) | Bearing: UK326 | Housing: IP326 | Mass: 70 kg
UKIP328 Shaft: 125 mm (adapter) | Bearing: UK328 | Housing: IP328 | Mass: 78 kg
Mounted Bearing UnitsCBK
11 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CBK UKIP3 Pillow Block Units (Medium-Heavy Series, Adapter Mount)

Brand CBK·Mounted Bearing Units

Available part numbers (11)

UKIP313, UKIP315, UKIP316, UKIP317, UKIP318, UKIP319, UKIP320, UKIP322, UKIP324, UKIP326 + 1 more — see full table ↓

How to order

Send the CBK part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
UKIP313Shaft: 60 mm (adapter) | Bearing: UK313 | Housing: IP313 | Mass: 12 kg
UKIP315Shaft: 65 mm (adapter) | Bearing: UK315 | Housing: IP315 | Mass: 15 kg
UKIP316Shaft: 70 mm (adapter) | Bearing: UK316 | Housing: IP316 | Mass: 20 kg
UKIP317Shaft: 75 mm (adapter) | Bearing: UK317 | Housing: IP317 | Mass: 22 kg
UKIP318Shaft: 80 mm (adapter) | Bearing: UK318 | Housing: IP318 | Mass: 24 kg
UKIP319Shaft: 85 mm (adapter) | Bearing: UK319 | Housing: IP319 | Mass: 28 kg
UKIP320Shaft: 90 mm (adapter) | Bearing: UK320 | Housing: IP320 | Mass: 32 kg
UKIP322Shaft: 100 mm (adapter) | Bearing: UK322 | Housing: IP322 | Mass: 48 kg
UKIP324Shaft: 110 mm (adapter) | Bearing: UK324 | Housing: IP324 | Mass: 54 kg
UKIP326Shaft: 115 mm (adapter) | Bearing: UK326 | Housing: IP326 | Mass: 70 kg
UKIP328Shaft: 125 mm (adapter) | Bearing: UK328 | Housing: IP328 | Mass: 78 kg
