CKD Air Operated Ball Valve 2-Port for Steam (Compact Rotary Valve) CSB, CSBF Series, Double Acting

CKD Air Operated Ball Valve 2-Port for Steam (Compact Rotary Valve) CSB, CSBF Series, Double Acting

Compact air-operated 2-port ball valve for steam and water up to 164 C, driven by a double-acting rotary actuator.

Key features

  • CSB standard bore, CSBF full bore; Rc3/8 to Rc2 ports, operating pressure 0 to 0.6 MPa
  • Codes are the double-acting base models

Specifications

Fluid steam, water
Operating pressure (MPa) 0-0.6
Fluid temperature (C) 0-164
Rotary actuator double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-10 Port: Rc3/8 | Orifice (mm): 10 | Cv: 10 | Bore: full | Mass (kg): 1.0 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-15 Port: Rc1/2 | Orifice (mm): 10 | Cv: 6 | Bore: standard | Mass (kg): 1.0 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-20 Port: Rc3/4 | Orifice (mm): 15 | Cv: 16 | Bore: standard | Mass (kg): 1.2 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-25 Port: Rc1 | Orifice (mm): 20 | Cv: 29 | Bore: standard | Mass (kg): 1.3 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-32 Port: Rc1-1/4 | Orifice (mm): 25 | Cv: 50 | Bore: standard | Mass (kg): 2.2 (stainless 2.3) | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-40 Port: Rc1-1/2 | Orifice (mm): 32 | Cv: 98 | Bore: standard | Mass (kg): 2.6 (stainless 2.7) | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-50 Port: Rc2 | Orifice (mm): 40 | Cv: 125 | Bore: standard | Mass (kg): 3.4 (stainless 3.5) | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-15 Port: Rc1/2 | Orifice (mm): 15 | Cv: 23 | Bore: full | Mass (kg): 1.2 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-20 Port: Rc3/4 | Orifice (mm): 20 | Cv: 51 | Bore: full | Mass (kg): 1.3 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-25 Port: Rc1 | Orifice (mm): 25 | Cv: 66 | Bore: full | Mass (kg): 2.2 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-32 Port: Rc1-1/4 | Orifice (mm): 32 | Cv: 114 | Bore: full | Mass (kg): 2.6 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-40 Port: Rc1-1/2 | Orifice (mm): 40 | Cv: 176 | Bore: full | Mass (kg): 3.4 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
Ball ValvesCKD
12 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Air Operated Ball Valve 2-Port for Steam (Compact Rotary Valve) CSB, CSBF Series, Double Acting

Brand CKD·Ball Valves

Available part numbers (12)

CSB-10, CSB-15, CSB-20, CSB-25, CSB-32, CSB-40, CSB-50, CSBF-15, CSBF-20, CSBF-25 + 2 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
CSB-10Port: Rc3/8 | Orifice (mm): 10 | Cv: 10 | Bore: full | Mass (kg): 1.0 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-15Port: Rc1/2 | Orifice (mm): 10 | Cv: 6 | Bore: standard | Mass (kg): 1.0 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-20Port: Rc3/4 | Orifice (mm): 15 | Cv: 16 | Bore: standard | Mass (kg): 1.2 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-25Port: Rc1 | Orifice (mm): 20 | Cv: 29 | Bore: standard | Mass (kg): 1.3 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-32Port: Rc1-1/4 | Orifice (mm): 25 | Cv: 50 | Bore: standard | Mass (kg): 2.2 (stainless 2.3) | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-40Port: Rc1-1/2 | Orifice (mm): 32 | Cv: 98 | Bore: standard | Mass (kg): 2.6 (stainless 2.7) | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSB-50Port: Rc2 | Orifice (mm): 40 | Cv: 125 | Bore: standard | Mass (kg): 3.4 (stainless 3.5) | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-15Port: Rc1/2 | Orifice (mm): 15 | Cv: 23 | Bore: full | Mass (kg): 1.2 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-20Port: Rc3/4 | Orifice (mm): 20 | Cv: 51 | Bore: full | Mass (kg): 1.3 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-25Port: Rc1 | Orifice (mm): 25 | Cv: 66 | Bore: full | Mass (kg): 2.2 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-32Port: Rc1-1/4 | Orifice (mm): 32 | Cv: 114 | Bore: full | Mass (kg): 2.6 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
CSBF-40Port: Rc1-1/2 | Orifice (mm): 40 | Cv: 176 | Bore: full | Mass (kg): 3.4 | Fluid: steam, water | Operating pressure (MPa): 0-0.6 | Fluid temperature (C): 0-164 | Rotary actuator: double acting, pilot pressure 0.35-0.7 MPa, pilot port Rc1/8
