Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| GASB-2 | Port: 50A JIS flange | Working pressure (MPa): 0-1.0 | Cv: 460 | Mass (kg): 46 | Ambient temperature (C): -10-60 | Fluid: city gas, natural gas, LPG | ||
| GASB-3 | Port: 80A JIS flange | Working pressure (MPa): 0-1.0 | Cv: 1200 | Mass (kg): 56 | Ambient temperature (C): -10-60 | Fluid: city gas, natural gas, LPG | ||
| GASB-4 | Port: 100A JIS flange (reducer port) | Working pressure (MPa): 0-1.0 | Cv: 860 | Mass (kg): 59 | Ambient temperature (C): -10-60 | Fluid: city gas, natural gas, LPG |
Need a different model, or a part not listed here? Send us your parts list →
