CKD Speed Controller SC1 Series (Medium Bore Type, Clean Spec)

CKD Speed Controller SC1 Series (Medium Bore Type, Clean Spec)

Medium-bore in-line speed controllers with Rc1/8-Rc1/2 ports for cylinder bores phi20-phi160, in clean-room specification.

Key features

  • Lightweight and can be disassembled while still piped

Specifications

Tube OD (mm) -
Max pressure (MPa) 1.0
Clean suffix P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-6-P7※ Port: Rc1/8 | Tube OD (mm): - | Free flow eff. area (mm2): 11 | Controlled flow eff. area (mm2): 8 | Free flow (L/min ANR @0.5MPa): 730 | Controlled flow (L/min ANR @0.5MPa): 530 | Applicable cylinder bore: phi20-50 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-8-P7※ Port: Rc1/4 | Tube OD (mm): - | Free flow eff. area (mm2): 14 | Controlled flow eff. area (mm2): 13 | Free flow (L/min ANR @0.5MPa): 930 | Controlled flow (L/min ANR @0.5MPa): 870 | Applicable cylinder bore: phi32-75 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-10-P7※ Port: Rc3/8 | Tube OD (mm): - | Free flow eff. area (mm2): 39 | Controlled flow eff. area (mm2): 22 | Free flow (L/min ANR @0.5MPa): 2600 | Controlled flow (L/min ANR @0.5MPa): 1500 | Applicable cylinder bore: phi50-140 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-15-P7※ Port: Rc1/2 | Tube OD (mm): - | Free flow eff. area (mm2): 43 | Controlled flow eff. area (mm2): 36 | Free flow (L/min ANR @0.5MPa): 2900 | Controlled flow (L/min ANR @0.5MPa): 2400 | Applicable cylinder bore: phi80-160 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
Speed ControllersCKD
4 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Speed Controller SC1 Series (Medium Bore Type, Clean Spec)

Brand CKD·Speed Controllers

Available part numbers (4)

SC1-6-P7※, SC1-8-P7※, SC1-10-P7※, SC1-15-P7※

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
SC1-6-P7※Port: Rc1/8 | Tube OD (mm): - | Free flow eff. area (mm2): 11 | Controlled flow eff. area (mm2): 8 | Free flow (L/min ANR @0.5MPa): 730 | Controlled flow (L/min ANR @0.5MPa): 530 | Applicable cylinder bore: phi20-50 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-8-P7※Port: Rc1/4 | Tube OD (mm): - | Free flow eff. area (mm2): 14 | Controlled flow eff. area (mm2): 13 | Free flow (L/min ANR @0.5MPa): 930 | Controlled flow (L/min ANR @0.5MPa): 870 | Applicable cylinder bore: phi32-75 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-10-P7※Port: Rc3/8 | Tube OD (mm): - | Free flow eff. area (mm2): 39 | Controlled flow eff. area (mm2): 22 | Free flow (L/min ANR @0.5MPa): 2600 | Controlled flow (L/min ANR @0.5MPa): 1500 | Applicable cylinder bore: phi50-140 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
SC1-15-P7※Port: Rc1/2 | Tube OD (mm): - | Free flow eff. area (mm2): 43 | Controlled flow eff. area (mm2): 36 | Free flow (L/min ANR @0.5MPa): 2900 | Controlled flow (L/min ANR @0.5MPa): 2400 | Applicable cylinder bore: phi80-160 | Max pressure (MPa): 1.0 | Clean suffix: P7※ (P70 dust-generation prevention / P74 Cu-Si-halogen free)
