CKD Centering Hand BHE Series

CKD Centering Hand BHE Series

Centering hand that grips the workpiece on its center line.

Key features

  • Codes are the printed base models (standard type, without switch); options such as single acting, long stroke, finger and cylinder switch are added via the catalog ordering code

Specifications

Fluid Compressed air
BHE-01CS Size: 01CS | Bore (mm): 12 | Stroke (mm): 7 | Mass (kg): 0.108 | Fluid: Compressed air
BHE-03CS Size: 03CS | Bore (mm): 16 | Stroke (mm): 10 | Mass (kg): 0.154 | Fluid: Compressed air
BHE-04CS Size: 04CS | Bore (mm): 20 | Stroke (mm): 14 | Mass (kg): 0.260 | Fluid: Compressed air
BHE-05CS Size: 05CS | Bore (mm): 25 | Stroke (mm): 16 | Mass (kg): 0.438 | Fluid: Compressed air
BHE-06CS Size: 06CS | Bore (mm): 32 | Stroke (mm): 22 | Mass (kg): 1.040 | Fluid: Compressed air
Pneumatic GrippersCKD
5 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Centering Hand BHE Series

Brand CKD·Pneumatic Grippers

Available part numbers (5)

BHE-01CS, BHE-03CS, BHE-04CS, BHE-05CS, BHE-06CS

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
BHE-01CSSize: 01CS | Bore (mm): 12 | Stroke (mm): 7 | Mass (kg): 0.108 | Fluid: Compressed air
BHE-03CSSize: 03CS | Bore (mm): 16 | Stroke (mm): 10 | Mass (kg): 0.154 | Fluid: Compressed air
BHE-04CSSize: 04CS | Bore (mm): 20 | Stroke (mm): 14 | Mass (kg): 0.260 | Fluid: Compressed air
BHE-05CSSize: 05CS | Bore (mm): 25 | Stroke (mm): 16 | Mass (kg): 0.438 | Fluid: Compressed air
BHE-06CSSize: 06CS | Bore (mm): 32 | Stroke (mm): 22 | Mass (kg): 1.040 | Fluid: Compressed air
