CKD CHG-W/CHG-WR Air Operated 3-Port Ball Valve (Outdoor)

CKD CHG-W/CHG-WR Air Operated 3-Port Ball Valve (Outdoor)

CKD CHG-W outdoor air-operated 3-port mixing/diverting ball valve (compact rotary valve), Rc1/2 to Rc2.

Key features

  • Outdoor WEATHER PROOF series rated for indoor and outdoor use
  • Compact rack-and-pinion rotary actuator, pilot port Rc1/8, non-lube
  • 3-port L-flow with 90 deg switching; pressurize from C port only
  • Double acting or single acting with B-C (R1) or A-C (R2) normally open
  • Stainless steel body; FKM (E) or special FKM (F) seals
  • WG warranty option not multiplied

Specifications

Fluid Water, air, oil
Operating pressure 0 to 1.0 MPa
Proof pressure 2.0 MPa (hydraulic)
Fluid temperature Water/oil 0 to 80 C; air -20 to 80 C
Pilot pressure 0.35-0.7 (DA), 0.4-0.7 MPa (SA)
Flow path Mixing/diverting, 90 deg
Source CKD Korea catalog CC-1276K, p. 72-75
CHG-W-15-F Actuator: Double acting | Port: Rc1/2 | Body/rubber: SUS / Special FKM
CHG-W-20-F Actuator: Double acting | Port: Rc3/4 | Body/rubber: SUS / Special FKM
CHG-W-25-F Actuator: Double acting | Port: Rc1 | Body/rubber: SUS / Special FKM
CHG-W-32-F Actuator: Double acting | Port: Rc1 1/4 | Body/rubber: SUS / Special FKM
CHG-W-40-F Actuator: Double acting | Port: Rc1 1/2 | Body/rubber: SUS / Special FKM
CHG-W-50-F Actuator: Double acting | Port: Rc2 | Body/rubber: SUS / Special FKM
CHG-WR1-15-F Actuator: Single acting, B-C open | Port: Rc1/2 | Body/rubber: SUS / Special FKM
CHG-WR1-20-F Actuator: Single acting, B-C open | Port: Rc3/4 | Body/rubber: SUS / Special FKM
CHG-WR1-25-F Actuator: Single acting, B-C open | Port: Rc1 | Body/rubber: SUS / Special FKM
CHG-WR1-32-F Actuator: Single acting, B-C open | Port: Rc1 1/4 | Body/rubber: SUS / Special FKM
CHG-WR1-40-F Actuator: Single acting, B-C open | Port: Rc1 1/2 | Body/rubber: SUS / Special FKM
CHG-WR1-50-F Actuator: Single acting, B-C open | Port: Rc2 | Body/rubber: SUS / Special FKM
CHG-WR2-15-F Actuator: Single acting, A-C open | Port: Rc1/2 | Body/rubber: SUS / Special FKM
CHG-WR2-20-F Actuator: Single acting, A-C open | Port: Rc3/4 | Body/rubber: SUS / Special FKM
CHG-WR2-25-F Actuator: Single acting, A-C open | Port: Rc1 | Body/rubber: SUS / Special FKM
CHG-WR2-32-F Actuator: Single acting, A-C open | Port: Rc1 1/4 | Body/rubber: SUS / Special FKM
CHG-WR2-40-F Actuator: Single acting, A-C open | Port: Rc1 1/2 | Body/rubber: SUS / Special FKM
CHG-WR2-50-F Actuator: Single acting, A-C open | Port: Rc2 | Body/rubber: SUS / Special FKM
