CKD Linear Guide Parallel Hand LHA Series (Double/Single Acting)

CKD Linear Guide Parallel Hand LHA Series (Double/Single Acting)

Parallel hand with linear guide for high gripping accuracy (repeatability +/-0.01 mm); double acting or single acting.

Key features

  • Codes are the printed base models (standard type, without switch); options such as single acting, long stroke, finger and cylinder switch are added via the catalog ordering code

Specifications

Operation Double acting / single acting
Repeatability (mm) ±0.01
Fluid Compressed air
LHA-006CS Size: 006CS | Bore (mm): 6 | Stroke (mm): 4 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.04 | Fluid: Compressed air
LHA-01CS Size: 01CS | Bore (mm): 12 | Stroke (mm): 5 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.085 | Fluid: Compressed air
LHA-03CS Size: 03CS | Bore (mm): 16 | Stroke (mm): 9 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.15 | Fluid: Compressed air
LHA-04CS Size: 04CS | Bore (mm): 20 | Stroke (mm): 11 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.36 | Fluid: Compressed air
LHA-05CS Size: 05CS | Bore (mm): 25 | Stroke (mm): 15 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.52 | Fluid: Compressed air
LHA-06CS Size: 06CS | Bore (mm): 32 | Stroke (mm): 20 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.82 | Fluid: Compressed air
Pneumatic GrippersCKD
6 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Linear Guide Parallel Hand LHA Series (Double/Single Acting)

Brand CKD·Pneumatic Grippers

Available part numbers (6)

LHA-006CS, LHA-01CS, LHA-03CS, LHA-04CS, LHA-05CS, LHA-06CS

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
LHA-006CSSize: 006CS | Bore (mm): 6 | Stroke (mm): 4 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.04 | Fluid: Compressed air
LHA-01CSSize: 01CS | Bore (mm): 12 | Stroke (mm): 5 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.085 | Fluid: Compressed air
LHA-03CSSize: 03CS | Bore (mm): 16 | Stroke (mm): 9 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.15 | Fluid: Compressed air
LHA-04CSSize: 04CS | Bore (mm): 20 | Stroke (mm): 11 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.36 | Fluid: Compressed air
LHA-05CSSize: 05CS | Bore (mm): 25 | Stroke (mm): 15 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.52 | Fluid: Compressed air
LHA-06CSSize: 06CS | Bore (mm): 32 | Stroke (mm): 20 | Operation: Double acting / single acting | Repeatability (mm): ±0.01 | Mass (kg): 0.82 | Fluid: Compressed air
