CKD MAGD5/MAGD4 Air Operated Valve for Integrated Gas System IAGD

CKD MAGD5/MAGD4 Air Operated Valve for Integrated Gas System IAGD

CKD MAGD5 (IAGD5, 1.125") and MAGD4 (IAGD4, 1.5") surface-mount air operated metal diaphragm valves for SEMI-standard integrated gas systems.

Key features

  • 1-block D (2-port), X/Y (3-port) and 2-block A (3-port) valve shapes
  • NC/NO operation with optional proximity sensor (open or closed signalling) per valve
  • W seal (nominal 6.35) surface-mount interface; Cv 0.1 (-0) or 0.26 (-1)
  • SUS316L body, Ni-Co alloy diaphragm, PCTFE seat
  • Mounting bolts, gaskets and actuator air fittings ordered separately

Specifications

Fluid Inert gas / process gas
Operating pressure 1.3x10^-6 Pa(abs) to 0.99 MPa(G) (-0); to 0.7 MPa(G) (-1)
Fluid / ambient temperature -10 to 80 C
External leakage 2.8x10^-12 Pa.m3/s (He) or less
Operating air pressure NC 0.4-0.6 MPa, NO 0.4-0.5 MPa
Operation port M5
Materials SUS316L body, Ni-Co diaphragm, PCTFE seat
Availability Made to order
Source CKD Korea catalog CB-035K, p. 80-88
MAGD5-R-01D-W-1 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-01D-W-2 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-01D-W-3 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01D-W-4 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01D-W-5 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01D-W-6 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01X-W-1 System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-01X-W-2 System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-01X-W-3 System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01X-W-4 System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01X-W-5 System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01X-W-6 System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01Y-W-1 System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-01Y-W-2 System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-01Y-W-3 System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01Y-W-4 System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01Y-W-5 System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01Y-W-6 System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-02A-W-11 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC
MAGD5-R-02A-W-12 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO
MAGD5-R-02A-W-13 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-14 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-15 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-16 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-21 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC
MAGD5-R-02A-W-22 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO
MAGD5-R-02A-W-23 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-24 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-25 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-26 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-31 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC
MAGD5-R-02A-W-32 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO
MAGD5-R-02A-W-33 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-34 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-35 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-36 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-41 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC
MAGD5-R-02A-W-42 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO
MAGD5-R-02A-W-43 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-44 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-45 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-46 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-51 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC
MAGD5-R-02A-W-52 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO
MAGD5-R-02A-W-53 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-54 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-55 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-56 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-61 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC
MAGD5-R-02A-W-62 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO
MAGD5-R-02A-W-63 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-64 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-65 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-66 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD5-R-11D-W-1 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-11D-W-2 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-11D-W-3 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-11D-W-4 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-11D-W-5 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-11D-W-6 System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-12A-W-11 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NC
MAGD5-R-12A-W-12 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NO
MAGD5-R-12A-W-13 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-14 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-15 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-16 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-21 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NC
MAGD5-R-12A-W-22 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NO
MAGD5-R-12A-W-23 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-24 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-25 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-26 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-31 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NC
MAGD5-R-12A-W-32 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NO
MAGD5-R-12A-W-33 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-34 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-35 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-36 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-41 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NC
MAGD5-R-12A-W-42 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NO
MAGD5-R-12A-W-43 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-44 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-45 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-46 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-51 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NC
MAGD5-R-12A-W-52 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NO
MAGD5-R-12A-W-53 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-54 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-55 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-56 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-61 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NC
MAGD5-R-12A-W-62 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NO
MAGD5-R-12A-W-63 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-64 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-65 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-66 System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD4-R-01D-W-1 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-01D-W-2 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-01D-W-3 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01D-W-4 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01D-W-5 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01D-W-6 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01X-W-1 System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-01X-W-2 System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-01X-W-3 System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01X-W-4 System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01X-W-5 System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01X-W-6 System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01Y-W-1 System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-01Y-W-2 System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-01Y-W-3 System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01Y-W-4 System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01Y-W-5 System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01Y-W-6 System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-02A-W-11 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC
MAGD4-R-02A-W-12 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO
MAGD4-R-02A-W-13 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-14 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-15 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-16 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-21 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC
MAGD4-R-02A-W-22 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO
MAGD4-R-02A-W-23 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-24 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-25 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-26 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-31 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC
MAGD4-R-02A-W-32 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO
MAGD4-R-02A-W-33 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-34 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-35 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-36 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-41 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC
MAGD4-R-02A-W-42 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO
MAGD4-R-02A-W-43 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-44 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-45 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-46 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-51 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC
MAGD4-R-02A-W-52 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO
MAGD4-R-02A-W-53 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-54 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-55 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-56 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-61 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC
MAGD4-R-02A-W-62 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO
MAGD4-R-02A-W-63 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-64 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-65 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-66 System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD4-R-11D-W-1 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-11D-W-2 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-11D-W-3 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-11D-W-4 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-11D-W-5 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-11D-W-6 System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
Process Gas ValvesCKD
156 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD MAGD5/MAGD4 Air Operated Valve for Integrated Gas System IAGD

Brand CKD·Process Gas Valves

Available part numbers (156)

MAGD5-R-01D-W-1, MAGD5-R-01D-W-2, MAGD5-R-01D-W-3, MAGD5-R-01D-W-4, MAGD5-R-01D-W-5, MAGD5-R-01D-W-6, MAGD5-R-01X-W-1, MAGD5-R-01X-W-2, MAGD5-R-01X-W-3, MAGD5-R-01X-W-4 + 146 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MAGD5-R-01D-W-1System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-01D-W-2System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-01D-W-3System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01D-W-4System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01D-W-5System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01D-W-6System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01X-W-1System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-01X-W-2System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-01X-W-3System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01X-W-4System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01X-W-5System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01X-W-6System: IAGD5 (1.125" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01Y-W-1System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-01Y-W-2System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-01Y-W-3System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-01Y-W-4System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01Y-W-5System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-01Y-W-6System: IAGD5 (1.125" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-02A-W-11System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC
MAGD5-R-02A-W-12System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO
MAGD5-R-02A-W-13System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-14System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-15System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-16System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-21System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC
MAGD5-R-02A-W-22System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO
MAGD5-R-02A-W-23System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-24System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-25System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-26System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-31System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC
MAGD5-R-02A-W-32System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO
MAGD5-R-02A-W-33System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-34System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-35System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-36System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-41System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC
MAGD5-R-02A-W-42System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO
MAGD5-R-02A-W-43System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-44System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-45System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-46System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-51System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC
MAGD5-R-02A-W-52System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO
MAGD5-R-02A-W-53System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-54System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-55System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-56System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-02A-W-61System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC
MAGD5-R-02A-W-62System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO
MAGD5-R-02A-W-63System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-02A-W-64System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-02A-W-65System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-02A-W-66System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD5-R-11D-W-1System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC | V2 operation: None (single valve)
MAGD5-R-11D-W-2System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO | V2 operation: None (single valve)
MAGD5-R-11D-W-3System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-11D-W-4System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD5-R-11D-W-5System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD5-R-11D-W-6System: IAGD5 (1.125" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD5-R-12A-W-11System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NC
MAGD5-R-12A-W-12System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NO
MAGD5-R-12A-W-13System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-14System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-15System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-16System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-21System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NC
MAGD5-R-12A-W-22System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NO
MAGD5-R-12A-W-23System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-24System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-25System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-26System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-31System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NC
MAGD5-R-12A-W-32System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NO
MAGD5-R-12A-W-33System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-34System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-35System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-36System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-41System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NC
MAGD5-R-12A-W-42System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NO
MAGD5-R-12A-W-43System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-44System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-45System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-46System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-51System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NC
MAGD5-R-12A-W-52System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NO
MAGD5-R-12A-W-53System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-54System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-55System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-56System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when closed
MAGD5-R-12A-W-61System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NC
MAGD5-R-12A-W-62System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NO
MAGD5-R-12A-W-63System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD5-R-12A-W-64System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when open
MAGD5-R-12A-W-65System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when open
MAGD5-R-12A-W-66System: IAGD5 (1.125" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD4-R-01D-W-1System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-01D-W-2System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-01D-W-3System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01D-W-4System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01D-W-5System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01D-W-6System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01X-W-1System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-01X-W-2System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-01X-W-3System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01X-W-4System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01X-W-5System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01X-W-6System: IAGD4 (1.5" W seal) | Valve shape: 1-block X, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01Y-W-1System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-01Y-W-2System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-01Y-W-3System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-01Y-W-4System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01Y-W-5System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-01Y-W-6System: IAGD4 (1.5" W seal) | Valve shape: 1-block Y, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-02A-W-11System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC
MAGD4-R-02A-W-12System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO
MAGD4-R-02A-W-13System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-14System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-15System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-16System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-21System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC
MAGD4-R-02A-W-22System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO
MAGD4-R-02A-W-23System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-24System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-25System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-26System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-31System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC
MAGD4-R-02A-W-32System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO
MAGD4-R-02A-W-33System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-34System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-35System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-36System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-41System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC
MAGD4-R-02A-W-42System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO
MAGD4-R-02A-W-43System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-44System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-45System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-46System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when open | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-51System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC
MAGD4-R-02A-W-52System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO
MAGD4-R-02A-W-53System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-54System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-55System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-56System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NC, sensor on when open | V2 operation: NO, sensor on when closed
MAGD4-R-02A-W-61System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC
MAGD4-R-02A-W-62System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO
MAGD4-R-02A-W-63System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when closed
MAGD4-R-02A-W-64System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when open
MAGD4-R-02A-W-65System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NC, sensor on when open
MAGD4-R-02A-W-66System: IAGD4 (1.5" W seal) | Valve shape: 2-block A, 3-port | Cv: 0.1 | V1 operation: NO, sensor on when closed | V2 operation: NO, sensor on when closed
MAGD4-R-11D-W-1System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC | V2 operation: None (single valve)
MAGD4-R-11D-W-2System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO | V2 operation: None (single valve)
MAGD4-R-11D-W-3System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when closed | V2 operation: None (single valve)
MAGD4-R-11D-W-4System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when open | V2 operation: None (single valve)
MAGD4-R-11D-W-5System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NC, sensor on when open | V2 operation: None (single valve)
MAGD4-R-11D-W-6System: IAGD4 (1.5" W seal) | Valve shape: 1-block D, 2-port | Cv: 0.26 | V1 operation: NO, sensor on when closed | V2 operation: None (single valve)

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Plumbing & Hoses →
