CKD MMD*02 Stainless Body Chemical Manual Valve (Rc, SUS Tube)

CKD MMD*02 Stainless Body Chemical Manual Valve (Rc, SUS Tube)

CKD MMD302/402/502 stainless steel body manual diaphragm valves with seal-stable structure, suited to solvents and explosion-proof environments.

Key features

  • SUS316L body with PTFE diaphragm and EPDM O-ring
  • Connections: Rc thread, SUS tube extension or bite fitting, 3/8 to 1 in
  • Actuator material PP (P) or A5056 aluminium (A)
  • Electropolished body (E) for tube and bite fitting types, made to order
  • For full open/close use only, not for flow regulation

Specifications

Valve type Manual diaphragm 2-port valve, stainless body
Body SUS316L
Fluid Chemicals, pure water, air, N2
Fluid temperature 5 to 90 C
Operating pressure 0-0.4 MPa (both directions)
Proof pressure 1.2 MPa
Source CKD Korea catalog CB-031K-15, p. 176-181
MMD302-8-P Model: MMD302 | Connection: Rc1/4 | Orifice: 8 mm | Actuator: PP | Body treatment: None
MMD302-8-A Model: MMD302 | Connection: Rc1/4 | Orifice: 8 mm | Actuator: A5056 | Body treatment: None
MMD302-3BT-P Model: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: PP | Body treatment: None
MMD302-3BT-PE Model: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: PP | Body treatment: Electropolished
MMD302-3BT-A Model: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: A5056 | Body treatment: None
MMD302-3BT-AE Model: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: A5056 | Body treatment: Electropolished
MMD302-6S-P Model: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: PP | Body treatment: None
MMD302-6S-PE Model: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: PP | Body treatment: Electropolished
MMD302-6S-A Model: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: A5056 | Body treatment: None
MMD302-6S-AE Model: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: A5056 | Body treatment: Electropolished
MMD302-10-P Model: MMD302 | Connection: Rc3/8 | Orifice: 10 mm | Actuator: PP | Body treatment: None
MMD302-10-A Model: MMD302 | Connection: Rc3/8 | Orifice: 10 mm | Actuator: A5056 | Body treatment: None
MMD302-4BT-P Model: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: PP | Body treatment: None
MMD302-4BT-PE Model: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: PP | Body treatment: Electropolished
MMD302-4BT-A Model: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: A5056 | Body treatment: None
MMD302-4BT-AE Model: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: A5056 | Body treatment: Electropolished
MMD302-8S-P Model: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: PP | Body treatment: None
MMD302-8S-PE Model: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: PP | Body treatment: Electropolished
MMD302-8S-A Model: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: A5056 | Body treatment: None
MMD302-8S-AE Model: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: A5056 | Body treatment: Electropolished
MMD402-15-P Model: MMD402 | Connection: Rc1/2 | Orifice: 16 mm | Actuator: PP | Body treatment: None
MMD402-15-A Model: MMD402 | Connection: Rc1/2 | Orifice: 16 mm | Actuator: A5056 | Body treatment: None
MMD402-6BT-P Model: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: PP | Body treatment: None
MMD402-6BT-PE Model: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: PP | Body treatment: Electropolished
MMD402-6BT-A Model: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: A5056 | Body treatment: None
MMD402-6BT-AE Model: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: A5056 | Body treatment: Electropolished
MMD402-12S-P Model: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: PP | Body treatment: None
MMD402-12S-PE Model: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: PP | Body treatment: Electropolished
MMD402-12S-A Model: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: A5056 | Body treatment: None
MMD402-12S-AE Model: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: A5056 | Body treatment: Electropolished
MMD502-8BT-P Model: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: PP | Body treatment: None
MMD502-8BT-PE Model: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: PP | Body treatment: Electropolished
MMD502-8BT-A Model: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: A5056 | Body treatment: None
MMD502-8BT-AE Model: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: A5056 | Body treatment: Electropolished
MMD502-16S-P Model: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: PP | Body treatment: None
MMD502-16S-PE Model: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: PP | Body treatment: Electropolished
MMD502-16S-A Model: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: A5056 | Body treatment: None
MMD502-16S-AE Model: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: A5056 | Body treatment: Electropolished
Chemical ValvesCKD
38 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD MMD*02 Stainless Body Chemical Manual Valve (Rc, SUS Tube)

Brand CKD·Chemical Valves

Available part numbers (38)

MMD302-8-P, MMD302-8-A, MMD302-3BT-P, MMD302-3BT-PE, MMD302-3BT-A, MMD302-3BT-AE, MMD302-6S-P, MMD302-6S-PE, MMD302-6S-A, MMD302-6S-AE + 28 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
MMD302-8-PModel: MMD302 | Connection: Rc1/4 | Orifice: 8 mm | Actuator: PP | Body treatment: None
MMD302-8-AModel: MMD302 | Connection: Rc1/4 | Orifice: 8 mm | Actuator: A5056 | Body treatment: None
MMD302-3BT-PModel: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: PP | Body treatment: None
MMD302-3BT-PEModel: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: PP | Body treatment: Electropolished
MMD302-3BT-AModel: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: A5056 | Body treatment: None
MMD302-3BT-AEModel: MMD302 | Connection: 3/8 in SUS tube ext. | Orifice: 8 mm | Actuator: A5056 | Body treatment: Electropolished
MMD302-6S-PModel: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: PP | Body treatment: None
MMD302-6S-PEModel: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: PP | Body treatment: Electropolished
MMD302-6S-AModel: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: A5056 | Body treatment: None
MMD302-6S-AEModel: MMD302 | Connection: 3/8 in bite fitting | Orifice: 8 mm | Actuator: A5056 | Body treatment: Electropolished
MMD302-10-PModel: MMD302 | Connection: Rc3/8 | Orifice: 10 mm | Actuator: PP | Body treatment: None
MMD302-10-AModel: MMD302 | Connection: Rc3/8 | Orifice: 10 mm | Actuator: A5056 | Body treatment: None
MMD302-4BT-PModel: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: PP | Body treatment: None
MMD302-4BT-PEModel: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: PP | Body treatment: Electropolished
MMD302-4BT-AModel: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: A5056 | Body treatment: None
MMD302-4BT-AEModel: MMD302 | Connection: 1/2 in SUS tube ext. | Orifice: 10 mm | Actuator: A5056 | Body treatment: Electropolished
MMD302-8S-PModel: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: PP | Body treatment: None
MMD302-8S-PEModel: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: PP | Body treatment: Electropolished
MMD302-8S-AModel: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: A5056 | Body treatment: None
MMD302-8S-AEModel: MMD302 | Connection: 1/2 in bite fitting | Orifice: 10 mm | Actuator: A5056 | Body treatment: Electropolished
MMD402-15-PModel: MMD402 | Connection: Rc1/2 | Orifice: 16 mm | Actuator: PP | Body treatment: None
MMD402-15-AModel: MMD402 | Connection: Rc1/2 | Orifice: 16 mm | Actuator: A5056 | Body treatment: None
MMD402-6BT-PModel: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: PP | Body treatment: None
MMD402-6BT-PEModel: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: PP | Body treatment: Electropolished
MMD402-6BT-AModel: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: A5056 | Body treatment: None
MMD402-6BT-AEModel: MMD402 | Connection: 3/4 in SUS tube ext. | Orifice: 16 mm | Actuator: A5056 | Body treatment: Electropolished
MMD402-12S-PModel: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: PP | Body treatment: None
MMD402-12S-PEModel: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: PP | Body treatment: Electropolished
MMD402-12S-AModel: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: A5056 | Body treatment: None
MMD402-12S-AEModel: MMD402 | Connection: 3/4 in bite fitting | Orifice: 16 mm | Actuator: A5056 | Body treatment: Electropolished
MMD502-8BT-PModel: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: PP | Body treatment: None
MMD502-8BT-PEModel: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: PP | Body treatment: Electropolished
MMD502-8BT-AModel: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: A5056 | Body treatment: None
MMD502-8BT-AEModel: MMD502 | Connection: 1 in SUS tube ext. | Orifice: 20 mm | Actuator: A5056 | Body treatment: Electropolished
MMD502-16S-PModel: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: PP | Body treatment: None
MMD502-16S-PEModel: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: PP | Body treatment: Electropolished
MMD502-16S-AModel: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: A5056 | Body treatment: None
MMD502-16S-AEModel: MMD502 | Connection: 1 in bite fitting | Orifice: 20 mm | Actuator: A5056 | Body treatment: Electropolished
