CKD MULTILEX Direct Acting 2-Port Solenoid Valve AB21 Series (NC)

CKD MULTILEX Direct Acting 2-Port Solenoid Valve AB21 Series (NC)

Direct-acting poppet 2-port solenoid valve from the MULTILEX multi-fluid range.

Key features

  • Normally closed, Rc1/8 or Rc1/4 ports, for air, water, kerosene and oil
  • Codes give port and orifice; coil option and voltage are added when ordering

Specifications

Type NC
Fluid air, water, kerosene, oil
Coil voltage AC100V, AC200V, DC24V
AB21-01-1 Port: Rc1/8 | Orifice (mm): 1.5 | Max op. pressure diff. air AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. oil AC/DC (MPa): 0.9/1.0 | C (dm3/(s·bar)): 0.29 | b: 0.51 | Cv: 0.1 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-01-2 Port: Rc1/8 | Orifice (mm): 2.0 | Max op. pressure diff. air AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. oil AC/DC (MPa): 0.5/0.6 | C (dm3/(s·bar)): 0.53 | b: 0.55 | Cv: 0.15 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-01-3 Port: Rc1/8 | Orifice (mm): 3.0 | Max op. pressure diff. air AC/DC (MPa): 0.7/0.2 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.4/0.2 | Max op. pressure diff. oil AC/DC (MPa): 0.25/0.2 | C (dm3/(s·bar)): 1.1 | b: 0.52 | Cv: 0.3 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-01-5 Port: Rc1/8 | Orifice (mm): 4.0 | Max op. pressure diff. air AC/DC (MPa): 0.4/0.1 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.2/0.1 | Max op. pressure diff. oil AC/DC (MPa): 0.1/0.1 | C (dm3/(s·bar)): 1.8 | b: 0.35 | Cv: 0.4 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-1 Port: Rc1/4 | Orifice (mm): 1.5 | Max op. pressure diff. air AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. oil AC/DC (MPa): 0.9/1.0 | C (dm3/(s·bar)): 0.29 | b: 0.51 | Cv: 0.1 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-2 Port: Rc1/4 | Orifice (mm): 2.0 | Max op. pressure diff. air AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. oil AC/DC (MPa): 0.5/0.6 | C (dm3/(s·bar)): 0.53 | b: 0.55 | Cv: 0.15 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-3 Port: Rc1/4 | Orifice (mm): 3.0 | Max op. pressure diff. air AC/DC (MPa): 0.7/0.2 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.4/0.2 | Max op. pressure diff. oil AC/DC (MPa): 0.25/0.2 | C (dm3/(s·bar)): 1.1 | b: 0.52 | Cv: 0.3 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-5 Port: Rc1/4 | Orifice (mm): 4.0 | Max op. pressure diff. air AC/DC (MPa): 0.4/0.1 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.2/0.1 | Max op. pressure diff. oil AC/DC (MPa): 0.1/0.1 | C (dm3/(s·bar)): 1.8 | b: 0.35 | Cv: 0.4 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
Solenoid ValvesCKD
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD MULTILEX Direct Acting 2-Port Solenoid Valve AB21 Series (NC)

Brand CKD·Solenoid Valves

Available part numbers (8)

AB21-01-1, AB21-01-2, AB21-01-3, AB21-01-5, AB21-02-1, AB21-02-2, AB21-02-3, AB21-02-5

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
AB21-01-1Port: Rc1/8 | Orifice (mm): 1.5 | Max op. pressure diff. air AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. oil AC/DC (MPa): 0.9/1.0 | C (dm3/(s·bar)): 0.29 | b: 0.51 | Cv: 0.1 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-01-2Port: Rc1/8 | Orifice (mm): 2.0 | Max op. pressure diff. air AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. oil AC/DC (MPa): 0.5/0.6 | C (dm3/(s·bar)): 0.53 | b: 0.55 | Cv: 0.15 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-01-3Port: Rc1/8 | Orifice (mm): 3.0 | Max op. pressure diff. air AC/DC (MPa): 0.7/0.2 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.4/0.2 | Max op. pressure diff. oil AC/DC (MPa): 0.25/0.2 | C (dm3/(s·bar)): 1.1 | b: 0.52 | Cv: 0.3 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-01-5Port: Rc1/8 | Orifice (mm): 4.0 | Max op. pressure diff. air AC/DC (MPa): 0.4/0.1 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.2/0.1 | Max op. pressure diff. oil AC/DC (MPa): 0.1/0.1 | C (dm3/(s·bar)): 1.8 | b: 0.35 | Cv: 0.4 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-1Port: Rc1/4 | Orifice (mm): 1.5 | Max op. pressure diff. air AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.5/1.0 | Max op. pressure diff. oil AC/DC (MPa): 0.9/1.0 | C (dm3/(s·bar)): 0.29 | b: 0.51 | Cv: 0.1 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-2Port: Rc1/4 | Orifice (mm): 2.0 | Max op. pressure diff. air AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. water/kerosene AC/DC (MPa): 1.0/0.6 | Max op. pressure diff. oil AC/DC (MPa): 0.5/0.6 | C (dm3/(s·bar)): 0.53 | b: 0.55 | Cv: 0.15 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-3Port: Rc1/4 | Orifice (mm): 3.0 | Max op. pressure diff. air AC/DC (MPa): 0.7/0.2 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.4/0.2 | Max op. pressure diff. oil AC/DC (MPa): 0.25/0.2 | C (dm3/(s·bar)): 1.1 | b: 0.52 | Cv: 0.3 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
AB21-02-5Port: Rc1/4 | Orifice (mm): 4.0 | Max op. pressure diff. air AC/DC (MPa): 0.4/0.1 | Max op. pressure diff. water/kerosene AC/DC (MPa): 0.2/0.1 | Max op. pressure diff. oil AC/DC (MPa): 0.1/0.1 | C (dm3/(s·bar)): 1.8 | b: 0.35 | Cv: 0.4 | Type: NC | Fluid: air, water, kerosene, oil | Coil voltage: AC100V, AC200V, DC24V
