CKD One-touch Fitting, Stainless Steel, for Food Processing ZW-FP1 Series

CKD One-touch Fitting, Stainless Steel, for Food Processing ZW-FP1 Series

Stainless steel one-touch (push-in) fitting for food manufacturing processes (FP1 specification, NSF H1 lubricant).

Key features

  • Body and nipple in SUS303, chuck in stainless steel, packing in nitrile rubber
  • Shapes include straight, elbow, tee, Y, tetra, FY, double Y, cap, manifold and plug-in types for tubes φ4 to φ12, threads M5 to R1/2
  • Usable with soft nylon and urethane tubing for compressed air up to 1.0 MPa and vacuum to -100 kPa

Specifications

Body material Stainless steel SUS303
Max. pressure (MPa) 1.0
Vacuum (kPa) -100
ZW-S4-M5-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-6-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-8-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-M5-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-6-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-8-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-10-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-6-FP1 Shape: Straight | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-8-FP1 Shape: Straight | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-10-FP1 Shape: Straight | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-6-FP1 Shape: Straight | Tube O.D.: φ10 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-8-FP1 Shape: Straight | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-10-FP1 Shape: Straight | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-0-X-FP1 Shape: Straight (bulkhead) | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-15-FP1 Shape: Straight | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-0-X-FP1 Shape: Straight (bulkhead) | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-8-FP1 Shape: Straight | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-0-X-FP1 Shape: Straight (bulkhead) | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-10-FP1 Shape: Straight | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-0-X-FP1 Shape: Straight (bulkhead) | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-15-FP1 Shape: Straight | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-0-X-FP1 Shape: Straight (bulkhead) | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-0-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-0-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S46-0-FP1 Shape: Straight | Tube O.D.: φ4 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-0-FP1 Shape: Straight | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S68-0-FP1 Shape: Straight | Tube O.D.: φ6 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-0-FP1 Shape: Straight | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S810-0-FP1 Shape: Straight | Tube O.D.: φ8 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-0-FP1 Shape: Straight | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S1012-0-FP1 Shape: Straight | Tube O.D.: φ10 / φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-M5-FP1 Shape: Elbow | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-6-FP1 Shape: Elbow | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-8-FP1 Shape: Elbow | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-M5-FP1 Shape: Elbow | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-6-FP1 Shape: Elbow | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-8-FP1 Shape: Elbow | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-10-FP1 Shape: Elbow | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-6-FP1 Shape: Elbow | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-8-FP1 Shape: Elbow | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-10-FP1 Shape: Elbow | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-6-FP1 Shape: Elbow | Tube O.D.: φ10 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-8-FP1 Shape: Elbow | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-10-FP1 Shape: Elbow | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-0-FP1 Shape: Elbow | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-15-FP1 Shape: Elbow | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-0-FP1 Shape: Elbow | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-8-FP1 Shape: Elbow | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-0-FP1 Shape: Elbow | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-10-FP1 Shape: Elbow | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-0-FP1 Shape: Elbow | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-15-FP1 Shape: Elbow | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-0-FP1 Shape: Elbow | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-M5-FP1 Shape: Tee | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-M5-D-FP1 Shape: Tee (D type) | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-6-FP1 Shape: Tee | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-6-D-FP1 Shape: Tee (D type) | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-8-FP1 Shape: Tee | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-8-D-FP1 Shape: Tee (D type) | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-M5-FP1 Shape: Tee | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-M5-D-FP1 Shape: Tee (D type) | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-6-FP1 Shape: Tee | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-6-D-FP1 Shape: Tee (D type) | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-8-FP1 Shape: Tee | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-8-D-FP1 Shape: Tee (D type) | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-10-FP1 Shape: Tee | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-10-D-FP1 Shape: Tee (D type) | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-6-FP1 Shape: Tee | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-6-D-FP1 Shape: Tee (D type) | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-8-FP1 Shape: Tee | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-8-D-FP1 Shape: Tee (D type) | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-10-FP1 Shape: Tee | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-10-D-FP1 Shape: Tee (D type) | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-8-FP1 Shape: Tee | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-8-D-FP1 Shape: Tee (D type) | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-10-FP1 Shape: Tee | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-10-D-FP1 Shape: Tee (D type) | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-15-FP1 Shape: Tee | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-15-D-FP1 Shape: Tee (D type) | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-8-FP1 Shape: Tee | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-8-D-FP1 Shape: Tee (D type) | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-10-FP1 Shape: Tee | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-10-D-FP1 Shape: Tee (D type) | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-15-FP1 Shape: Tee | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-15-D-FP1 Shape: Tee (D type) | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-0-FP1 Shape: Tee | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-0-FP1 Shape: Tee | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T46-0-FP1 Shape: Tee | Tube O.D.: φ4 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-0-FP1 Shape: Tee | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T68-0-FP1 Shape: Tee | Tube O.D.: φ6 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-0-FP1 Shape: Tee | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T810-0-FP1 Shape: Tee | Tube O.D.: φ8 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-0-FP1 Shape: Tee | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T1012-0-FP1 Shape: Tee | Tube O.D.: φ10 / φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y4-M5-FP1 Shape: Y tee | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y4-6-FP1 Shape: Y tee | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y4-8-FP1 Shape: Y tee | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-M5-FP1 Shape: Y tee | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-6-FP1 Shape: Y tee | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-8-FP1 Shape: Y tee | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-10-FP1 Shape: Y tee | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y44-0-FP1 Shape: Y tee | Tube O.D.: φ4 / φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y8-6-FP1 Shape: Y tee | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y66-0-FP1 Shape: Y tee | Tube O.D.: φ6 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y8-8-FP1 Shape: Y tee | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y88-0-FP1 Shape: Y tee | Tube O.D.: φ8 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y8-10-FP1 Shape: Y tee | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y1010-0-FP1 Shape: Y tee | Tube O.D.: φ10 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y10-8-FP1 Shape: Y tee | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y1212-0-FP1 Shape: Y tee | Tube O.D.: φ12 / φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y10-10-FP1 Shape: Y tee | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y64-0-FP1 Shape: Y tee | Tube O.D.: φ6 / φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y10-15-FP1 Shape: Y tee | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y86-0-FP1 Shape: Y tee | Tube O.D.: φ8 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y12-8-FP1 Shape: Y tee | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y108-0-FP1 Shape: Y tee | Tube O.D.: φ10 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y12-10-FP1 Shape: Y tee | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y1210-0-FP1 Shape: Y tee | Tube O.D.: φ12 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y12-15-FP1 Shape: Y tee | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-M5-FP1 Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-M5-FP1 Shape: FY type | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-6-FP1 Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-6-FP1 Shape: FY type | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-8-FP1 Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-8-FP1 Shape: FY type | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-M5-FP1 Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-M5-FP1 Shape: FY type | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-6-FP1 Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-6-FP1 Shape: FY type | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-8-FP1 Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-8-FP1 Shape: FY type | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-10-FP1 Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-10-FP1 Shape: FY type | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-6-FP1 Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-6-FP1 Shape: FY type | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-8-FP1 Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-8-FP1 Shape: FY type | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-10-FP1 Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-10-FP1 Shape: FY type | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-8-FP1 Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-8-FP1 Shape: FY type | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-10-FP1 Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-10-FP1 Shape: FY type | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-15-FP1 Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-15-FP1 Shape: FY type | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-8-FP1 Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-8-FP1 Shape: FY type | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-10-FP1 Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-10-FP1 Shape: FY type | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-15-FP1 Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-15-FP1 Shape: FY type | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-0-FP1 Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-0-FP1 Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY4-6-FP1 Shape: Double Y | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-0-FP1 Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY4-8-FP1 Shape: Double Y | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-0-FP1 Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY6-6-FP1 Shape: Double Y | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-0-FP1 Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-0-FP1 Shape: FY type | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-0-FP1 Shape: FY type | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-0-FP1 Shape: FY type | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-0-FP1 Shape: FY type | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY64-0-FP1 Shape: Double Y | Tube O.D.: φ6 / φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-0-FP1 Shape: FY type | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY86-0-FP1 Shape: Double Y | Tube O.D.: φ8 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C4-FP1 Shape: Cap | Tube O.D.: φ4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C6-FP1 Shape: Cap | Tube O.D.: φ6 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF46-6-FP1 Shape: Manifold | Tube O.D.: φ4 / φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C8-FP1 Shape: Cap | Tube O.D.: φ8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF48-8-FP1 Shape: Manifold | Tube O.D.: φ4 / φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C10-FP1 Shape: Cap | Tube O.D.: φ10 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF68-8-FP1 Shape: Manifold | Tube O.D.: φ6 / φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C12-FP1 Shape: Cap | Tube O.D.: φ12 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF810-10-FP1 Shape: Manifold | Tube O.D.: φ8 / φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-6P-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: φ6 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-8P-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: φ8 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-10P-FP1 Shape: Straight | Tube O.D.: φ4 | Connection: φ10 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-4P-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: φ4 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-8P-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: φ8 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-10P-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: φ10 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF46-0-FP1 Shape: Manifold | Tube O.D.: φ4 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-12P-FP1 Shape: Straight | Tube O.D.: φ6 | Connection: φ12 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF48-0-FP1 Shape: Manifold | Tube O.D.: φ4 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-10P-FP1 Shape: Straight | Tube O.D.: φ8 | Connection: φ10 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF68-0-FP1 Shape: Manifold | Tube O.D.: φ6 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-12P-FP1 Shape: Straight | Tube O.D.: φ8 | Connection: φ12 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF610-0-FP1 Shape: Manifold | Tube O.D.: φ6 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-12P-FP1 Shape: Straight | Tube O.D.: φ10 | Connection: φ12 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF810-0-FP1 Shape: Manifold | Tube O.D.: φ8 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
Pneumatic FittingsCKD
190 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD One-touch Fitting, Stainless Steel, for Food Processing ZW-FP1 Series

Brand CKD·Pneumatic Fittings

Available part numbers (190)

ZW-S4-M5-FP1, ZW-S4-6-FP1, ZW-S4-8-FP1, ZW-S6-M5-FP1, ZW-S6-6-FP1, ZW-S6-8-FP1, ZW-S6-10-FP1, ZW-S8-6-FP1, ZW-S8-8-FP1, ZW-S8-10-FP1 + 180 more — see full table ↓

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
ZW-S4-M5-FP1Shape: Straight | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-6-FP1Shape: Straight | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-8-FP1Shape: Straight | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-M5-FP1Shape: Straight | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-6-FP1Shape: Straight | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-8-FP1Shape: Straight | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-10-FP1Shape: Straight | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-6-FP1Shape: Straight | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-8-FP1Shape: Straight | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-10-FP1Shape: Straight | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-6-FP1Shape: Straight | Tube O.D.: φ10 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-8-FP1Shape: Straight | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-10-FP1Shape: Straight | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-0-X-FP1Shape: Straight (bulkhead) | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-15-FP1Shape: Straight | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-0-X-FP1Shape: Straight (bulkhead) | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-8-FP1Shape: Straight | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-0-X-FP1Shape: Straight (bulkhead) | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-10-FP1Shape: Straight | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-0-X-FP1Shape: Straight (bulkhead) | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-15-FP1Shape: Straight | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-0-X-FP1Shape: Straight (bulkhead) | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-0-FP1Shape: Straight | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-0-FP1Shape: Straight | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S46-0-FP1Shape: Straight | Tube O.D.: φ4 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-0-FP1Shape: Straight | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S68-0-FP1Shape: Straight | Tube O.D.: φ6 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-0-FP1Shape: Straight | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S810-0-FP1Shape: Straight | Tube O.D.: φ8 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S12-0-FP1Shape: Straight | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S1012-0-FP1Shape: Straight | Tube O.D.: φ10 / φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-M5-FP1Shape: Elbow | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-6-FP1Shape: Elbow | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-8-FP1Shape: Elbow | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-M5-FP1Shape: Elbow | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-6-FP1Shape: Elbow | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-8-FP1Shape: Elbow | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-10-FP1Shape: Elbow | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-6-FP1Shape: Elbow | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-8-FP1Shape: Elbow | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-10-FP1Shape: Elbow | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-6-FP1Shape: Elbow | Tube O.D.: φ10 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-8-FP1Shape: Elbow | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-10-FP1Shape: Elbow | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L4-0-FP1Shape: Elbow | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-15-FP1Shape: Elbow | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L6-0-FP1Shape: Elbow | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-8-FP1Shape: Elbow | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L8-0-FP1Shape: Elbow | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-10-FP1Shape: Elbow | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L10-0-FP1Shape: Elbow | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-15-FP1Shape: Elbow | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-L12-0-FP1Shape: Elbow | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-M5-FP1Shape: Tee | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-M5-D-FP1Shape: Tee (D type) | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-6-FP1Shape: Tee | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-6-D-FP1Shape: Tee (D type) | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-8-FP1Shape: Tee | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-8-D-FP1Shape: Tee (D type) | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-M5-FP1Shape: Tee | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-M5-D-FP1Shape: Tee (D type) | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-6-FP1Shape: Tee | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-6-D-FP1Shape: Tee (D type) | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-8-FP1Shape: Tee | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-8-D-FP1Shape: Tee (D type) | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-10-FP1Shape: Tee | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-10-D-FP1Shape: Tee (D type) | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-6-FP1Shape: Tee | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-6-D-FP1Shape: Tee (D type) | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-8-FP1Shape: Tee | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-8-D-FP1Shape: Tee (D type) | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-10-FP1Shape: Tee | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-10-D-FP1Shape: Tee (D type) | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-8-FP1Shape: Tee | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-8-D-FP1Shape: Tee (D type) | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-10-FP1Shape: Tee | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-10-D-FP1Shape: Tee (D type) | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-15-FP1Shape: Tee | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-15-D-FP1Shape: Tee (D type) | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-8-FP1Shape: Tee | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-8-D-FP1Shape: Tee (D type) | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-10-FP1Shape: Tee | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-10-D-FP1Shape: Tee (D type) | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-15-FP1Shape: Tee | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-15-D-FP1Shape: Tee (D type) | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T4-0-FP1Shape: Tee | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T6-0-FP1Shape: Tee | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T46-0-FP1Shape: Tee | Tube O.D.: φ4 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T8-0-FP1Shape: Tee | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T68-0-FP1Shape: Tee | Tube O.D.: φ6 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T10-0-FP1Shape: Tee | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T810-0-FP1Shape: Tee | Tube O.D.: φ8 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T12-0-FP1Shape: Tee | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-T1012-0-FP1Shape: Tee | Tube O.D.: φ10 / φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y4-M5-FP1Shape: Y tee | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y4-6-FP1Shape: Y tee | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y4-8-FP1Shape: Y tee | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-M5-FP1Shape: Y tee | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-6-FP1Shape: Y tee | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-8-FP1Shape: Y tee | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y6-10-FP1Shape: Y tee | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y44-0-FP1Shape: Y tee | Tube O.D.: φ4 / φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y8-6-FP1Shape: Y tee | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y66-0-FP1Shape: Y tee | Tube O.D.: φ6 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y8-8-FP1Shape: Y tee | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y88-0-FP1Shape: Y tee | Tube O.D.: φ8 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y8-10-FP1Shape: Y tee | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y1010-0-FP1Shape: Y tee | Tube O.D.: φ10 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y10-8-FP1Shape: Y tee | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y1212-0-FP1Shape: Y tee | Tube O.D.: φ12 / φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y10-10-FP1Shape: Y tee | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y64-0-FP1Shape: Y tee | Tube O.D.: φ6 / φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y10-15-FP1Shape: Y tee | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y86-0-FP1Shape: Y tee | Tube O.D.: φ8 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y12-8-FP1Shape: Y tee | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y108-0-FP1Shape: Y tee | Tube O.D.: φ10 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y12-10-FP1Shape: Y tee | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y1210-0-FP1Shape: Y tee | Tube O.D.: φ12 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-Y12-15-FP1Shape: Y tee | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-M5-FP1Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-M5-FP1Shape: FY type | Tube O.D.: φ4 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-6-FP1Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-6-FP1Shape: FY type | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-8-FP1Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-8-FP1Shape: FY type | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-M5-FP1Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-M5-FP1Shape: FY type | Tube O.D.: φ6 | Connection: M5x0.8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-6-FP1Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-6-FP1Shape: FY type | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-8-FP1Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-8-FP1Shape: FY type | Tube O.D.: φ6 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-10-FP1Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-10-FP1Shape: FY type | Tube O.D.: φ6 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-6-FP1Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-6-FP1Shape: FY type | Tube O.D.: φ8 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-8-FP1Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-8-FP1Shape: FY type | Tube O.D.: φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-10-FP1Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-10-FP1Shape: FY type | Tube O.D.: φ8 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-8-FP1Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-8-FP1Shape: FY type | Tube O.D.: φ10 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-10-FP1Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-10-FP1Shape: FY type | Tube O.D.: φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-15-FP1Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-15-FP1Shape: FY type | Tube O.D.: φ10 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-8-FP1Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-8-FP1Shape: FY type | Tube O.D.: φ12 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-10-FP1Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-10-FP1Shape: FY type | Tube O.D.: φ12 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-15-FP1Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-15-FP1Shape: FY type | Tube O.D.: φ12 | Connection: R1/2 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR4-0-FP1Shape: Tetra (4-way) | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR6-0-FP1Shape: Tetra (4-way) | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY4-6-FP1Shape: Double Y | Tube O.D.: φ4 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR8-0-FP1Shape: Tetra (4-way) | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY4-8-FP1Shape: Double Y | Tube O.D.: φ4 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR10-0-FP1Shape: Tetra (4-way) | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY6-6-FP1Shape: Double Y | Tube O.D.: φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-TR12-0-FP1Shape: Tetra (4-way) | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY4-0-FP1Shape: FY type | Tube O.D.: φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY6-0-FP1Shape: FY type | Tube O.D.: φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY8-0-FP1Shape: FY type | Tube O.D.: φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY10-0-FP1Shape: FY type | Tube O.D.: φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY64-0-FP1Shape: Double Y | Tube O.D.: φ6 / φ4 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-FY12-0-FP1Shape: FY type | Tube O.D.: φ12 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-WY86-0-FP1Shape: Double Y | Tube O.D.: φ8 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C4-FP1Shape: Cap | Tube O.D.: φ4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C6-FP1Shape: Cap | Tube O.D.: φ6 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF46-6-FP1Shape: Manifold | Tube O.D.: φ4 / φ6 | Connection: R1/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C8-FP1Shape: Cap | Tube O.D.: φ8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF48-8-FP1Shape: Manifold | Tube O.D.: φ4 / φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C10-FP1Shape: Cap | Tube O.D.: φ10 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF68-8-FP1Shape: Manifold | Tube O.D.: φ6 / φ8 | Connection: R1/4 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-C12-FP1Shape: Cap | Tube O.D.: φ12 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF810-10-FP1Shape: Manifold | Tube O.D.: φ8 / φ10 | Connection: R3/8 | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-6P-FP1Shape: Straight | Tube O.D.: φ4 | Connection: φ6 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-8P-FP1Shape: Straight | Tube O.D.: φ4 | Connection: φ8 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S4-10P-FP1Shape: Straight | Tube O.D.: φ4 | Connection: φ10 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-4P-FP1Shape: Straight | Tube O.D.: φ6 | Connection: φ4 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-8P-FP1Shape: Straight | Tube O.D.: φ6 | Connection: φ8 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-10P-FP1Shape: Straight | Tube O.D.: φ6 | Connection: φ10 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF46-0-FP1Shape: Manifold | Tube O.D.: φ4 / φ6 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S6-12P-FP1Shape: Straight | Tube O.D.: φ6 | Connection: φ12 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF48-0-FP1Shape: Manifold | Tube O.D.: φ4 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-10P-FP1Shape: Straight | Tube O.D.: φ8 | Connection: φ10 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF68-0-FP1Shape: Manifold | Tube O.D.: φ6 / φ8 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S8-12P-FP1Shape: Straight | Tube O.D.: φ8 | Connection: φ12 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF610-0-FP1Shape: Manifold | Tube O.D.: φ6 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-S10-12P-FP1Shape: Straight | Tube O.D.: φ10 | Connection: φ12 plug-in | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100
ZW-MF810-0-FP1Shape: Manifold | Tube O.D.: φ8 / φ10 | Connection: None (tube to tube) | Body material: Stainless steel SUS303 | Max. pressure (MPa): 1.0 | Vacuum (kPa): -100

Need a different model, or a part not listed here? Send us your parts list →

Related products

All Pneumatics →
