Product codes & specifications
| Product code | Spec | ||
|---|---|---|---|
| PD2-50A | Port: Rc2 | Orifice (mm): 53 | Cv: 62 | Operating pressure diff. (MPa): 0.1-0.7 | Pilot port: Rc1/4 | Mass (kg): 1.9 | Type: air operated | Fluid: air (no corrosive gas) | ||
| PDV2-50A | Port: Rc2 | Orifice (mm): 53 | Cv: 62 | Operating pressure diff. (MPa): 0.1-0.7 | Mass (kg): 2.1 | Type: solenoid valve mounted | Fluid: air (no corrosive gas) | Rated voltage: AC100V, AC200V, DC12V, DC24V, DC48V, DC100V |
Need a different model, or a part not listed here? Send us your parts list →
