CKD Powerful Chuck CKL2 Series

Powerful two-jaw chuck with high gripping force, bore 16 to 100 mm; long stroke option (L1).

Key features

Codes are the printed base models (standard type, without switch); options such as single acting, long stroke, finger and cylinder switch are added via the catalog ordering code

Specifications

Fluid	Compressed air

CKL2-16CS		Size: 16CS \| Bore (mm): 16 \| Mass (kg): 0.07 \| Fluid: Compressed air
CKL2-20CS		Size: 20CS \| Bore (mm): 20 \| Mass (kg): 0.12 \| Fluid: Compressed air
CKL2-25CS		Size: 25CS \| Bore (mm): 25 \| Mass (kg): 0.19 \| Fluid: Compressed air
CKL2-32CS		Size: 32CS \| Bore (mm): 32 \| Mass (kg): 0.26 \| Fluid: Compressed air
CKL2-40CS		Size: 40CS \| Bore (mm): 40 \| Mass (kg): 0.38 \| Fluid: Compressed air
CKL2-50CS		Size: 50CS \| Bore (mm): 50 \| Mass (kg): 0.59 \| Fluid: Compressed air
CKL2-63CS		Size: 63CS \| Bore (mm): 63 \| Mass (kg): 1.02 \| Fluid: Compressed air
CKL2-80CS		Size: 80CS \| Bore (mm): 80 \| Mass (kg): 2.02 \| Fluid: Compressed air
CKL2-100CS		Size: 100CS \| Bore (mm): 100 \| Mass (kg): 3.45 \| Fluid: Compressed air

Pneumatic ChucksCKD

9 product codes available in this family

Sourced direct from KoreaExport-ready supplyCompetitive pricing

RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Powerful Chuck CKL2 Series

Brand CKD·Pneumatic Chucks

Available part numbers (9)

CKL2-16CS, CKL2-20CS, CKL2-25CS, CKL2-32CS, CKL2-40CS, CKL2-50CS, CKL2-63CS, CKL2-80CS, CKL2-100CS

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.
