CKD Regulator for Process Gas PGM Series

CKD Regulator for Process Gas PGM Series

Ultra-clean regulators for inert and process gases with low particle generation, small pressure drop and stable control even in the micro-flow range.

Key features

  • Available with 1.5" C-seal or W-seal surface-mount interfaces or 1/4" JXR fittings

Specifications

Type Regulator for process gas
Max working pressure (MPa) 1.0
Fluid temp (C) -5 to 40
Fluid Inert gas, process gas
PGM-30-3 Type: Regulator for process gas | Connection: 1.5" C-seal | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-30-4 Type: Regulator for process gas | Connection: 1.5" W-seal | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-30-4R Type: Regulator for process gas | Connection: 1/4" JXR female fitting | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-30-4RM Type: Regulator for process gas | Connection: 1/4" JXR male fitting | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-3 Type: Regulator for process gas | Connection: 1.5" C-seal | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-4 Type: Regulator for process gas | Connection: 1.5" W-seal | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-4R Type: Regulator for process gas | Connection: 1/4" JXR female fitting | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-4RM Type: Regulator for process gas | Connection: 1/4" JXR male fitting | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
RegulatorsCKD
8 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Regulator for Process Gas PGM Series

Brand CKD·Regulators

Available part numbers (8)

PGM-30-3, PGM-30-4, PGM-30-4R, PGM-30-4RM, PGM-50-3, PGM-50-4, PGM-50-4R, PGM-50-4RM

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
PGM-30-3Type: Regulator for process gas | Connection: 1.5" C-seal | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-30-4Type: Regulator for process gas | Connection: 1.5" W-seal | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-30-4RType: Regulator for process gas | Connection: 1/4" JXR female fitting | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-30-4RMType: Regulator for process gas | Connection: 1/4" JXR male fitting | Set pressure (MPa): 0-0.21 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-3Type: Regulator for process gas | Connection: 1.5" C-seal | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-4Type: Regulator for process gas | Connection: 1.5" W-seal | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-4RType: Regulator for process gas | Connection: 1/4" JXR female fitting | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
PGM-50-4RMType: Regulator for process gas | Connection: 1/4" JXR male fitting | Set pressure (MPa): 0-0.35 | Max working pressure (MPa): 1.0 | Fluid temp (C): -5 to 40 | Fluid: Inert gas, process gas
