CKD Slim Parallel Hand HLA Series (Bush Guide, Double Acting)

CKD Slim Parallel Hand HLA Series (Bush Guide, Double Acting)

Slim parallel hand with bush guide, double acting.

Key features

  • Codes are the printed base models (standard type, without switch); options such as single acting, long stroke, finger and cylinder switch are added via the catalog ordering code

Specifications

Operation Double acting
Port M5
Fluid Compressed air
HLA-12CS Size: 12CS | Bore (mm): 12 | Stroke (mm): 15 | Operation: Double acting | Port: M5 | Mass (kg): 0.152 | Fluid: Compressed air
HLA-15CS Size: 15CS | Bore (mm): 15 | Stroke (mm): 20 | Operation: Double acting | Port: M5 | Mass (kg): 0.276 | Fluid: Compressed air
HLA-20CS Size: 20CS | Bore (mm): 20 | Stroke (mm): 25 | Operation: Double acting | Port: M5 | Mass (kg): 0.504 | Fluid: Compressed air
Pneumatic GrippersCKD
3 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

CKD Slim Parallel Hand HLA Series (Bush Guide, Double Acting)

Brand CKD·Pneumatic Grippers

Available part numbers (3)

HLA-12CS, HLA-15CS, HLA-20CS

How to order

Send the CKD part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
HLA-12CSSize: 12CS | Bore (mm): 12 | Stroke (mm): 15 | Operation: Double acting | Port: M5 | Mass (kg): 0.152 | Fluid: Compressed air
HLA-15CSSize: 15CS | Bore (mm): 15 | Stroke (mm): 20 | Operation: Double acting | Port: M5 | Mass (kg): 0.276 | Fluid: Compressed air
HLA-20CSSize: 20CS | Bore (mm): 20 | Stroke (mm): 25 | Operation: Double acting | Port: M5 | Mass (kg): 0.504 | Fluid: Compressed air
