DODGE E-Z Kleen GTEZ Polymer 2-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE E-Z Kleen GTEZ Polymer 2-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE E-Z Kleen GTEZ mounted ball bearings use the Grip Tight push/pull adapter mount in polymer housings for food and beverage processing.

Key features

  • Grip Tight adapter: full 360° concentric shaft contact, easy on / easy off
  • Stainless steel adapter sleeve and nut
  • Corrosion-resistant insert with nickel alloy Teflon composite coating
  • QuadGuard triple-lip seal with rubberized flinger and Maxlife cage
  • Anti-microbial polymer housing with no cavities to trap bacteria
  • Unit, unit without adapter and adapter assembly listed separately

Specifications

Brand DODGE
Product line E-Z Kleen
Housing style 2-bolt flange
Housing material polymer
Locking Grip Tight adapter mount
Shaft range 20-50 mm, 3/4-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 2-46
F2B-GTEZ-20M-PCR Series: 204 | Shaft: 20 mm | Variant: Complete unit | Part no.: 129340
F2B-GTEZ-04-PCR Series: 204 | Shaft: 20 mm, 3/4 in | Variant: Unit without adapter & nut | Part no.: 129548
F2B-GTEZ-012-PCR Series: 204 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129339
F2B-GTEZ-25M-PCR Series: 205 | Shaft: 25 mm | Variant: Complete unit | Part no.: 129342
F2B-GTEZ-05-PCR Series: 205 | Shaft: 25 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129549
F2B-GTEZ-100-PCR Series: 205 | Shaft: 1 in | Variant: Complete unit | Part no.: 129341
F2B-GTEZ-30M-PCR Series: 206 | Shaft: 30 mm | Variant: Complete unit | Part no.: 129345
F2B-GTEZ-06-PCR Series: 206 | Shaft: 30 mm, 1 in, 1-1/4 in | Variant: Unit without adapter & nut | Part no.: 129550
F2B-GTEZ-102-PCR Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129394
F2B-GTEZ-103-PCR Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129343
F2B-GTEZ-104S-PCR Series: 206 | Shaft: 1-1/4 in | Variant: Complete unit | Part no.: 129344
F2B-GTEZ-35M-PCR Series: 207 | Shaft: 35 mm | Variant: Complete unit | Part no.: 129348
F2B-GTEZ-07-PCR Series: 207 | Shaft: 35 mm, 1-1/4 in, 1 in | Variant: Unit without adapter & nut | Part no.: 129551
F2B-GTEZ-104-PCR Series: 207 | Shaft: 1-1/4 in | Variant: Complete unit | Part no.: 129346
F2B-GTEZ-106-PCR Series: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 073406
F2B-GTEZ-107-PCR Series: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 129347
F2B-GTEZ-40M-PCR Series: 208 | Shaft: 40 mm | Variant: Complete unit | Part no.: 129350
F2B-GTEZ-08-PCR Series: 208 | Shaft: 40 mm, 1-1/2 in | Variant: Unit without adapter & nut | Part no.: 129552
F2B-GTEZ-108-PCR Series: 208 | Shaft: 1-1/2 in | Variant: Complete unit | Part no.: 129349
F2B-GTEZ-45M-PCR Series: 209 | Shaft: 45 mm | Variant: Complete unit | Part no.: 129352
F2B-GTEZ-09-PCR Series: 209 | Shaft: 45 mm, 1-11/16 in, 1-3/4 in | Variant: Unit without adapter & nut | Part no.: 129553
F2B-GTEZ-111-PCR Series: 209 | Shaft: 1-11/16 in | Variant: Complete unit | Part no.: 129351
F2B-GTEZ-112-PCR Series: 209 | Shaft: 1-3/4 in | Variant: Complete unit | Part no.: 064147
F2B-GTEZ-50M-PCR Series: 210 | Shaft: 50 mm | Variant: Complete unit | Part no.: 129354
F2B-GTEZ-10-PCR Series: 210 | Shaft: 50 mm, 1-15/16 in, 2 in | Variant: Unit without adapter & nut | Part no.: 129554
F2B-GTEZ-115-PCR Series: 210 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129353
F2B-GTEZ-200-PCR Series: 210 | Shaft: 2 in | Variant: Complete unit | Part no.: 064503
