DODGE E-Z Kleen GTEZ Stainless 4-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE E-Z Kleen GTEZ Stainless 4-Bolt Flange (20-50 mm, 3/4-2 in)

DODGE E-Z Kleen GTEZ mounted ball bearings use the Grip Tight push/pull adapter mount in stainless steel housings for food and beverage processing.

Key features

  • Grip Tight adapter: full 360° concentric shaft contact, easy on / easy off
  • Stainless steel adapter sleeve and nut
  • Corrosion-resistant insert with nickel alloy Teflon composite coating
  • QuadGuard triple-lip seal with rubberized flinger and Maxlife cage
  • 300 series stainless steel housing
  • Unit, unit without adapter and adapter assembly listed separately

Specifications

Brand DODGE
Product line E-Z Kleen
Housing style 4-bolt flange
Housing material stainless steel
Locking Grip Tight adapter mount
Shaft range 20-50 mm, 3/4-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 2-33
F4B-GTEZ-20M-SHCR Series: 204 | Shaft: 20 mm | Variant: Complete unit | Part no.: 129722
F4B-GTEZ-04-SHCR Series: 204 | Shaft: 20 mm, 3/4 in | Variant: Unit without adapter & nut | Part no.: 129567
F4B-GTEZ-012-SHCR Series: 204 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129721
F4B-GTEZ-25M-SHCR Series: 205 | Shaft: 25 mm | Variant: Complete unit | Part no.: 129724
F4B-GTEZ-05-SHCR Series: 205 | Shaft: 25 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129568
F4B-GTEZ-100-SHCR Series: 205 | Shaft: 1 in | Variant: Complete unit | Part no.: 129723
F4B-GTEZ-30M-SHCR Series: 206 | Shaft: 30 mm | Variant: Complete unit | Part no.: 129727
F4B-GTEZ-06-SHCR Series: 206 | Shaft: 30 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129569
F4B-GTEZ-102-SHCR Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 075913
F4B-GTEZ-103-SHCR Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129725
F4B-GTEZ-104S-SHCR Series: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129726
F4B-GTEZ-35M-SHCR Series: 207 | Shaft: 35 mm | Variant: Complete unit | Part no.: 129730
F4B-GTEZ-07-SHCR Series: 207 | Shaft: 35 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129570
F4B-GTEZ-104-SHCR Series: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 129728
F4B-GTEZ-106-SHCR Series: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 064993
F4B-GTEZ-107-SHCR Series: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 129729
F4B-GTEZ-40M-SHCR Series: 208 | Shaft: 40 mm | Variant: Complete unit | Part no.: 129732
F4B-GTEZ-08-SHCR Series: 208 | Shaft: 40 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129571
F4B-GTEZ-108-SHCR Series: 208 | Shaft: 1 in | Variant: Complete unit | Part no.: 129731
F4B-GTEZ-50M-SHCR Series: 210 | Shaft: 50 mm | Variant: Complete unit | Part no.: 129734
F4B-GTEZ-10-SHCR Series: 210 | Shaft: 50 mm, 1-15/16 in, 2 in | Variant: Unit without adapter & nut | Part no.: 129572
F4B-GTEZ-115-SHCR Series: 210 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129733
F4B-GTEZ-200-SHCR Series: 210 | Shaft: 2 in | Variant: Complete unit | Part no.: 062901
Mounted Bearing UnitsDODGE
23 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE E-Z Kleen GTEZ Stainless 4-Bolt Flange (20-50 mm, 3/4-2 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (23)

F4B-GTEZ-20M-SHCR, F4B-GTEZ-04-SHCR, F4B-GTEZ-012-SHCR, F4B-GTEZ-25M-SHCR, F4B-GTEZ-05-SHCR, F4B-GTEZ-100-SHCR, F4B-GTEZ-30M-SHCR, F4B-GTEZ-06-SHCR, F4B-GTEZ-102-SHCR, F4B-GTEZ-103-SHCR + 13 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F4B-GTEZ-20M-SHCRSeries: 204 | Shaft: 20 mm | Variant: Complete unit | Part no.: 129722
F4B-GTEZ-04-SHCRSeries: 204 | Shaft: 20 mm, 3/4 in | Variant: Unit without adapter & nut | Part no.: 129567
F4B-GTEZ-012-SHCRSeries: 204 | Shaft: 3/4 in | Variant: Complete unit | Part no.: 129721
F4B-GTEZ-25M-SHCRSeries: 205 | Shaft: 25 mm | Variant: Complete unit | Part no.: 129724
F4B-GTEZ-05-SHCRSeries: 205 | Shaft: 25 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129568
F4B-GTEZ-100-SHCRSeries: 205 | Shaft: 1 in | Variant: Complete unit | Part no.: 129723
F4B-GTEZ-30M-SHCRSeries: 206 | Shaft: 30 mm | Variant: Complete unit | Part no.: 129727
F4B-GTEZ-06-SHCRSeries: 206 | Shaft: 30 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129569
F4B-GTEZ-102-SHCRSeries: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 075913
F4B-GTEZ-103-SHCRSeries: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129725
F4B-GTEZ-104S-SHCRSeries: 206 | Shaft: 1 in | Variant: Complete unit | Part no.: 129726
F4B-GTEZ-35M-SHCRSeries: 207 | Shaft: 35 mm | Variant: Complete unit | Part no.: 129730
F4B-GTEZ-07-SHCRSeries: 207 | Shaft: 35 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129570
F4B-GTEZ-104-SHCRSeries: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 129728
F4B-GTEZ-106-SHCRSeries: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 064993
F4B-GTEZ-107-SHCRSeries: 207 | Shaft: 1 in | Variant: Complete unit | Part no.: 129729
F4B-GTEZ-40M-SHCRSeries: 208 | Shaft: 40 mm | Variant: Complete unit | Part no.: 129732
F4B-GTEZ-08-SHCRSeries: 208 | Shaft: 40 mm, 1 in | Variant: Unit without adapter & nut | Part no.: 129571
F4B-GTEZ-108-SHCRSeries: 208 | Shaft: 1 in | Variant: Complete unit | Part no.: 129731
F4B-GTEZ-50M-SHCRSeries: 210 | Shaft: 50 mm | Variant: Complete unit | Part no.: 129734
F4B-GTEZ-10-SHCRSeries: 210 | Shaft: 50 mm, 1-15/16 in, 2 in | Variant: Unit without adapter & nut | Part no.: 129572
F4B-GTEZ-115-SHCRSeries: 210 | Shaft: 1-15/16 in | Variant: Complete unit | Part no.: 129733
F4B-GTEZ-200-SHCRSeries: 210 | Shaft: 2 in | Variant: Complete unit | Part no.: 062901
