• DODGE E-Z Kleen PSEZ Polymer Sleeve 3-Bolt Flange Bracket
1 1

DODGE E-Z Kleen PSEZ Polymer Sleeve 3-Bolt Flange Bracket

DODGE E-Z Kleen PSEZ Polymer Sleeve 3-Bolt Flange Bracket

DODGE E-Z Kleen PSEZ mounted bearings combine a polymer sleeve bearing with an engineered polymer housing for washdown areas.

Key features

  • Polymer sleeve bearing insert
  • Engineered polymer housing with anti-microbial agent
  • Solid-base housing design with no cavities to trap bacteria
  • Designed for food and beverage processing environments

Specifications

Brand DODGE
Product line E-Z Kleen
Housing style 3-bolt flange
Housing material polymer
Locking Polymer sleeve bearing
Shaft range 20-35 mm, 3/4-1-7/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 2-61
FB-PSEZ-20M-P Series: 204 | Shaft: 20 mm | Part no.: 034773
FB-PSEZ-012-P Series: 204 | Shaft: 3/4 in | Part no.: 034736
FB-PSEZ-25M-P Series: 205 | Shaft: 25 mm | Part no.: 034774
FB-PSEZ-100-P Series: 205 | Shaft: 1 in | Part no.: 034737
FB-PSEZ-30M-P Series: 206 | Shaft: 30 mm | Part no.: 034775
FB-PSEZ-103-P Series: 206 | Shaft: 1-3/16 in | Part no.: 034738
FB-PSEZ-104S-P Series: 206 | Shaft: 1-1/4 in | Part no.: 034739
FB-PSEZ-35M-P Series: 207 | Shaft: 35 mm | Part no.: 034776
FB-PSEZ-104-P Series: 207 | Shaft: 1-1/4 in | Part no.: 034740
FB-PSEZ-107-P Series: 207 | Shaft: 1-7/16 in | Part no.: 034741
Mounted Bearing UnitsDODGE
10 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE E-Z Kleen PSEZ Polymer Sleeve 3-Bolt Flange Bracket

Brand DODGE·Mounted Bearing Units

Available part numbers (10)

FB-PSEZ-20M-P, FB-PSEZ-012-P, FB-PSEZ-25M-P, FB-PSEZ-100-P, FB-PSEZ-30M-P, FB-PSEZ-103-P, FB-PSEZ-104S-P, FB-PSEZ-35M-P, FB-PSEZ-104-P, FB-PSEZ-107-P

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FB-PSEZ-20M-PSeries: 204 | Shaft: 20 mm | Part no.: 034773
FB-PSEZ-012-PSeries: 204 | Shaft: 3/4 in | Part no.: 034736
FB-PSEZ-25M-PSeries: 205 | Shaft: 25 mm | Part no.: 034774
FB-PSEZ-100-PSeries: 205 | Shaft: 1 in | Part no.: 034737
FB-PSEZ-30M-PSeries: 206 | Shaft: 30 mm | Part no.: 034775
FB-PSEZ-103-PSeries: 206 | Shaft: 1-3/16 in | Part no.: 034738
FB-PSEZ-104S-PSeries: 206 | Shaft: 1-1/4 in | Part no.: 034739
FB-PSEZ-35M-PSeries: 207 | Shaft: 35 mm | Part no.: 034776
FB-PSEZ-104-PSeries: 207 | Shaft: 1-1/4 in | Part no.: 034740
FB-PSEZ-107-PSeries: 207 | Shaft: 1-7/16 in | Part no.: 034741
