• DODGE E-Z Kleen SCEZ Polymer 2-Bolt Flange (20-50 mm, 1/2-2 in)
1 1

DODGE E-Z Kleen SCEZ Polymer 2-Bolt Flange (20-50 mm, 1/2-2 in)

DODGE E-Z Kleen SCEZ Polymer 2-Bolt Flange (20-50 mm, 1/2-2 in)

DODGE E-Z Kleen SCEZ mounted ball bearings pair polymer housings with corrosion-resistant set screw inserts for food and beverage processing.

Key features

  • Corrosion-resistant insert with patented nickel alloy Teflon composite coating
  • 65° stainless set screws and stainless anti-rotation pin
  • QuadGuard triple-lip seal with rubberized flinger
  • Maxlife cage; 100% filled with H1 food-grade grease
  • Anti-microbial polymer housing with no cavities to trap bacteria
  • Temperature range -29 °C to +108 °C

Specifications

Brand DODGE
Product line E-Z Kleen
Housing style 2-bolt flange
Housing material polymer
Locking Set screw (65°), stainless steel
Shaft range 20-50 mm, 1/2-2 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 2-48
F2B-SCEZ-20M-PCR Series: 204 | Shaft: 20 mm | Variant: Corrosion resistant insert | Part no.: 127563
F2B-SCEZ-20M-P Series: 204 | Shaft: 20 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-008L-PCR Series: 204 | Shaft: 1/2 in | Variant: Corrosion resistant insert | Part no.: 059823
F2B-SCEZ-008L-P Series: 204 | Shaft: 1/2 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-010L-PCR Series: 204 | Shaft: 5/8 in | Variant: Corrosion resistant insert | Part no.: 058792
F2B-SCEZ-010L-P Series: 204 | Shaft: 5/8 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-012-PCR Series: 204 | Shaft: 3/4 in | Variant: Corrosion resistant insert | Part no.: 127524
F2B-SCEZ-012-P Series: 204 | Shaft: 3/4 in | Variant: Insert with flingers | Part no.: 058404
F2B-SCEZ-25M-PCR Series: 205 | Shaft: 25 mm | Variant: Corrosion resistant insert | Part no.: 127564
F2B-SCEZ-25M-P Series: 205 | Shaft: 25 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-014-PCR Series: 205 | Shaft: 7/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
F2B-SCEZ-014-P Series: 205 | Shaft: 7/8 in | Variant: Insert with flingers | Part no.: 062837
F2B-SCEZ-015-PCR Series: 205 | Shaft: 15/16 in | Variant: Corrosion resistant insert | Part no.: 076841
F2B-SCEZ-015-P Series: 205 | Shaft: 15/16 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-100-PCR Series: 205 | Shaft: 1 in | Variant: Corrosion resistant insert | Part no.: 127525
F2B-SCEZ-100-P Series: 205 | Shaft: 1 in | Variant: Insert with flingers | Part no.: 057524
F2B-SCEZ-30M-PCR Series: 206 | Shaft: 30 mm | Variant: Corrosion resistant insert | Part no.: 127565
F2B-SCEZ-30M-P Series: 206 | Shaft: 30 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-102-PCR Series: 206 | Shaft: 1-1/8 in | Variant: Corrosion resistant insert | Part no.: 058470
F2B-SCEZ-102-P Series: 206 | Shaft: 1-1/8 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-103-PCR Series: 206 | Shaft: 1-3/16 in | Variant: Corrosion resistant insert | Part no.: 127526
F2B-SCEZ-103-P Series: 206 | Shaft: 1-3/16 in | Variant: Insert with flingers | Part no.: 056449
F2B-SCEZ-104S-PCR Series: 206 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127527
F2B-SCEZ-104S-P Series: 206 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: 057594
F2B-SCEZ-35M-PCR Series: 207 | Shaft: 35 mm | Variant: Corrosion resistant insert | Part no.: 127566
F2B-SCEZ-35M-P Series: 207 | Shaft: 35 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-104-PCR Series: 207 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127528
F2B-SCEZ-104-P Series: 207 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: 057687
F2B-SCEZ-105-PCR Series: 207 | Shaft: 1-5/16 in | Variant: Corrosion resistant insert | Part no.: 049380
F2B-SCEZ-105-P Series: 207 | Shaft: 1-5/16 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-106-PCR Series: 207 | Shaft: 1-3/8 in | Variant: Corrosion resistant insert | Part no.: 056893
F2B-SCEZ-106-P Series: 207 | Shaft: 1-3/8 in | Variant: Insert with flingers | Part no.: 056526
F2B-SCEZ-107-PCR Series: 207 | Shaft: 1-7/16 in | Variant: Corrosion resistant insert | Part no.: 127529
F2B-SCEZ-107-P Series: 207 | Shaft: 1-7/16 in | Variant: Insert with flingers | Part no.: 058941
F2B-SCEZ-40M-PCR Series: 208 | Shaft: 40 mm | Variant: Corrosion resistant insert | Part no.: 127567
F2B-SCEZ-40M-P Series: 208 | Shaft: 40 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-108-PCR Series: 208 | Shaft: 1-1/2 in | Variant: Corrosion resistant insert | Part no.: 127530
F2B-SCEZ-108-P Series: 208 | Shaft: 1-1/2 in | Variant: Insert with flingers | Part no.: 056580
F2B-SCEZ-110-PCR Series: 208 | Shaft: 1-5/8 in | Variant: Corrosion resistant insert | Part no.: 073651
F2B-SCEZ-110-P Series: 208 | Shaft: 1-5/8 in | Variant: Insert with flingers | Part no.: 073638
F2B-SCEZ-45M-PCR Series: 209 | Shaft: 45 mm | Variant: Corrosion resistant insert | Part no.: 127568
F2B-SCEZ-45M-P Series: 209 | Shaft: 45 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-110L-PCR Series: 209 | Shaft: 1-5/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
F2B-SCEZ-110L-P Series: 209 | Shaft: 1-5/8 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-111-PCR Series: 209 | Shaft: 1-11/16 in | Variant: Corrosion resistant insert | Part no.: 127531
F2B-SCEZ-111-P Series: 209 | Shaft: 1-11/16 in | Variant: Insert with flingers | Part no.: 067986
F2B-SCEZ-112-PCR Series: 209 | Shaft: 1-3/4 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
F2B-SCEZ-112-P Series: 209 | Shaft: 1-3/4 in | Variant: Insert with flingers | Part no.: 065786
F2B-SCEZ-50M-PCR Series: 210 | Shaft: 50 mm | Variant: Corrosion resistant insert | Part no.: 127569
F2B-SCEZ-50M-P Series: 210 | Shaft: 50 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-115-PCR Series: 210 | Shaft: 1-15/16 in | Variant: Corrosion resistant insert | Part no.: 127532
F2B-SCEZ-115-P Series: 210 | Shaft: 1-15/16 in | Variant: Insert with flingers | Part no.: 058593
F2B-SCEZ-200-PCR Series: 210 | Shaft: 2 in | Variant: Corrosion resistant insert | Part no.: 049835
F2B-SCEZ-200-P Series: 210 | Shaft: 2 in | Variant: Insert with flingers | Part no.: Assembled to order
Mounted Bearing UnitsDODGE
54 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE E-Z Kleen SCEZ Polymer 2-Bolt Flange (20-50 mm, 1/2-2 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (54)

F2B-SCEZ-20M-PCR, F2B-SCEZ-20M-P, F2B-SCEZ-008L-PCR, F2B-SCEZ-008L-P, F2B-SCEZ-010L-PCR, F2B-SCEZ-010L-P, F2B-SCEZ-012-PCR, F2B-SCEZ-012-P, F2B-SCEZ-25M-PCR, F2B-SCEZ-25M-P + 44 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F2B-SCEZ-20M-PCRSeries: 204 | Shaft: 20 mm | Variant: Corrosion resistant insert | Part no.: 127563
F2B-SCEZ-20M-PSeries: 204 | Shaft: 20 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-008L-PCRSeries: 204 | Shaft: 1/2 in | Variant: Corrosion resistant insert | Part no.: 059823
F2B-SCEZ-008L-PSeries: 204 | Shaft: 1/2 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-010L-PCRSeries: 204 | Shaft: 5/8 in | Variant: Corrosion resistant insert | Part no.: 058792
F2B-SCEZ-010L-PSeries: 204 | Shaft: 5/8 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-012-PCRSeries: 204 | Shaft: 3/4 in | Variant: Corrosion resistant insert | Part no.: 127524
F2B-SCEZ-012-PSeries: 204 | Shaft: 3/4 in | Variant: Insert with flingers | Part no.: 058404
F2B-SCEZ-25M-PCRSeries: 205 | Shaft: 25 mm | Variant: Corrosion resistant insert | Part no.: 127564
F2B-SCEZ-25M-PSeries: 205 | Shaft: 25 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-014-PCRSeries: 205 | Shaft: 7/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
F2B-SCEZ-014-PSeries: 205 | Shaft: 7/8 in | Variant: Insert with flingers | Part no.: 062837
F2B-SCEZ-015-PCRSeries: 205 | Shaft: 15/16 in | Variant: Corrosion resistant insert | Part no.: 076841
F2B-SCEZ-015-PSeries: 205 | Shaft: 15/16 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-100-PCRSeries: 205 | Shaft: 1 in | Variant: Corrosion resistant insert | Part no.: 127525
F2B-SCEZ-100-PSeries: 205 | Shaft: 1 in | Variant: Insert with flingers | Part no.: 057524
F2B-SCEZ-30M-PCRSeries: 206 | Shaft: 30 mm | Variant: Corrosion resistant insert | Part no.: 127565
F2B-SCEZ-30M-PSeries: 206 | Shaft: 30 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-102-PCRSeries: 206 | Shaft: 1-1/8 in | Variant: Corrosion resistant insert | Part no.: 058470
F2B-SCEZ-102-PSeries: 206 | Shaft: 1-1/8 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-103-PCRSeries: 206 | Shaft: 1-3/16 in | Variant: Corrosion resistant insert | Part no.: 127526
F2B-SCEZ-103-PSeries: 206 | Shaft: 1-3/16 in | Variant: Insert with flingers | Part no.: 056449
F2B-SCEZ-104S-PCRSeries: 206 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127527
F2B-SCEZ-104S-PSeries: 206 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: 057594
F2B-SCEZ-35M-PCRSeries: 207 | Shaft: 35 mm | Variant: Corrosion resistant insert | Part no.: 127566
F2B-SCEZ-35M-PSeries: 207 | Shaft: 35 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-104-PCRSeries: 207 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127528
F2B-SCEZ-104-PSeries: 207 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: 057687
F2B-SCEZ-105-PCRSeries: 207 | Shaft: 1-5/16 in | Variant: Corrosion resistant insert | Part no.: 049380
F2B-SCEZ-105-PSeries: 207 | Shaft: 1-5/16 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-106-PCRSeries: 207 | Shaft: 1-3/8 in | Variant: Corrosion resistant insert | Part no.: 056893
F2B-SCEZ-106-PSeries: 207 | Shaft: 1-3/8 in | Variant: Insert with flingers | Part no.: 056526
F2B-SCEZ-107-PCRSeries: 207 | Shaft: 1-7/16 in | Variant: Corrosion resistant insert | Part no.: 127529
F2B-SCEZ-107-PSeries: 207 | Shaft: 1-7/16 in | Variant: Insert with flingers | Part no.: 058941
F2B-SCEZ-40M-PCRSeries: 208 | Shaft: 40 mm | Variant: Corrosion resistant insert | Part no.: 127567
F2B-SCEZ-40M-PSeries: 208 | Shaft: 40 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-108-PCRSeries: 208 | Shaft: 1-1/2 in | Variant: Corrosion resistant insert | Part no.: 127530
F2B-SCEZ-108-PSeries: 208 | Shaft: 1-1/2 in | Variant: Insert with flingers | Part no.: 056580
F2B-SCEZ-110-PCRSeries: 208 | Shaft: 1-5/8 in | Variant: Corrosion resistant insert | Part no.: 073651
F2B-SCEZ-110-PSeries: 208 | Shaft: 1-5/8 in | Variant: Insert with flingers | Part no.: 073638
F2B-SCEZ-45M-PCRSeries: 209 | Shaft: 45 mm | Variant: Corrosion resistant insert | Part no.: 127568
F2B-SCEZ-45M-PSeries: 209 | Shaft: 45 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-110L-PCRSeries: 209 | Shaft: 1-5/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
F2B-SCEZ-110L-PSeries: 209 | Shaft: 1-5/8 in | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-111-PCRSeries: 209 | Shaft: 1-11/16 in | Variant: Corrosion resistant insert | Part no.: 127531
F2B-SCEZ-111-PSeries: 209 | Shaft: 1-11/16 in | Variant: Insert with flingers | Part no.: 067986
F2B-SCEZ-112-PCRSeries: 209 | Shaft: 1-3/4 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
F2B-SCEZ-112-PSeries: 209 | Shaft: 1-3/4 in | Variant: Insert with flingers | Part no.: 065786
F2B-SCEZ-50M-PCRSeries: 210 | Shaft: 50 mm | Variant: Corrosion resistant insert | Part no.: 127569
F2B-SCEZ-50M-PSeries: 210 | Shaft: 50 mm | Variant: Insert with flingers | Part no.: Assembled to order
F2B-SCEZ-115-PCRSeries: 210 | Shaft: 1-15/16 in | Variant: Corrosion resistant insert | Part no.: 127532
F2B-SCEZ-115-PSeries: 210 | Shaft: 1-15/16 in | Variant: Insert with flingers | Part no.: 058593
F2B-SCEZ-200-PCRSeries: 210 | Shaft: 2 in | Variant: Corrosion resistant insert | Part no.: 049835
F2B-SCEZ-200-PSeries: 210 | Shaft: 2 in | Variant: Insert with flingers | Part no.: Assembled to order

Need a different model, or a part not listed here? Send us your parts list →
