• DODGE E-Z Kleen SCEZ Polymer Flange Bracket (20-35 mm, 1/2-1-7/16 in)
1 1

DODGE E-Z Kleen SCEZ Polymer Flange Bracket (20-35 mm, 1/2-1-7/16 in)

DODGE E-Z Kleen SCEZ Polymer Flange Bracket (20-35 mm, 1/2-1-7/16 in)

DODGE E-Z Kleen SCEZ mounted ball bearings pair polymer housings with corrosion-resistant set screw inserts for food and beverage processing.

Key features

  • Corrosion-resistant insert with patented nickel alloy Teflon composite coating
  • 65° stainless set screws and stainless anti-rotation pin
  • QuadGuard triple-lip seal with rubberized flinger
  • Maxlife cage; 100% filled with H1 food-grade grease
  • Anti-microbial polymer housing with no cavities to trap bacteria
  • Temperature range -29 °C to +108 °C

Specifications

Brand DODGE
Product line E-Z Kleen
Housing style Flange bracket
Housing material polymer
Locking Set screw (65°), stainless steel
Shaft range 20-35 mm, 1/2-1-7/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 2-50
FB-SCEZ-20M-PCR Series: 204 | Shaft: 20 mm | Variant: Corrosion resistant insert | Part no.: 127570
FB-SCEZ-20M-P Series: 204 | Shaft: 20 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-008-PCR Series: 204 | Shaft: 1/2 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-008L-P Series: 204 | Shaft: 1/2 in | Variant: Insert with flingers | Part no.: 062317
FB-SCEZ-010-PCR Series: 204 | Shaft: 5/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-010-P Series: 204 | Shaft: 5/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-012-PCR Series: 204 | Shaft: 3/4 in | Variant: Corrosion resistant insert | Part no.: 127533
FB-SCEZ-012-P Series: 204 | Shaft: 3/4 in | Variant: Insert with flingers | Part no.: 058336
FB-SCEZ-25M-PCR Series: 205 | Shaft: 25 mm | Variant: Corrosion resistant insert | Part no.: 127571
FB-SCEZ-25M-P Series: 205 | Shaft: 25 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-014-PCR Series: 205 | Shaft: 7/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-014-P Series: 205 | Shaft: 7/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-015-PCR Series: 205 | Shaft: 15/16 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-015-P Series: 205 | Shaft: 15/16 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-100-PCR Series: 205 | Shaft: 1 in | Variant: Corrosion resistant insert | Part no.: 127534
FB-SCEZ-100-P Series: 205 | Shaft: 1 in | Variant: Insert with flingers | Part no.: 057908
FB-SCEZ-30M-PCR Series: 206 | Shaft: 30 mm | Variant: Corrosion resistant insert | Part no.: 127752
FB-SCEZ-30M-P Series: 206 | Shaft: 30 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-102-PCR Series: 206 | Shaft: 1-1/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-102-P Series: 206 | Shaft: 1-1/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-103-PCR Series: 206 | Shaft: 1-3/16 in | Variant: Corrosion resistant insert | Part no.: 127535
FB-SCEZ-103-P Series: 206 | Shaft: 1-3/16 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-104S-PCR Series: 206 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127536
FB-SCEZ-104S-P Series: 206 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: 058311
FB-SCEZ-35M-PCR Series: 207 | Shaft: 35 mm | Variant: Corrosion resistant insert | Part no.: 127753
FB-SCEZ-35M-P Series: 207 | Shaft: 35 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-104-PCR Series: 207 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127537
FB-SCEZ-104-P Series: 207 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-105-PCR Series: 207 | Shaft: 1-5/16 in | Variant: Corrosion resistant insert | Part no.: 058648
FB-SCEZ-105-P Series: 207 | Shaft: 1-5/16 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-106-PCR Series: 207 | Shaft: 1-3/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-106-P Series: 207 | Shaft: 1-3/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-107-PCR Series: 207 | Shaft: 1-7/16 in | Variant: Corrosion resistant insert | Part no.: 127538
FB-SCEZ-107-P Series: 207 | Shaft: 1-7/16 in | Variant: Insert with flingers | Part no.: Assembled to order
Mounted Bearing UnitsDODGE
34 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE E-Z Kleen SCEZ Polymer Flange Bracket (20-35 mm, 1/2-1-7/16 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (34)

FB-SCEZ-20M-PCR, FB-SCEZ-20M-P, FB-SCEZ-008-PCR, FB-SCEZ-008L-P, FB-SCEZ-010-PCR, FB-SCEZ-010-P, FB-SCEZ-012-PCR, FB-SCEZ-012-P, FB-SCEZ-25M-PCR, FB-SCEZ-25M-P + 24 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FB-SCEZ-20M-PCRSeries: 204 | Shaft: 20 mm | Variant: Corrosion resistant insert | Part no.: 127570
FB-SCEZ-20M-PSeries: 204 | Shaft: 20 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-008-PCRSeries: 204 | Shaft: 1/2 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-008L-PSeries: 204 | Shaft: 1/2 in | Variant: Insert with flingers | Part no.: 062317
FB-SCEZ-010-PCRSeries: 204 | Shaft: 5/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-010-PSeries: 204 | Shaft: 5/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-012-PCRSeries: 204 | Shaft: 3/4 in | Variant: Corrosion resistant insert | Part no.: 127533
FB-SCEZ-012-PSeries: 204 | Shaft: 3/4 in | Variant: Insert with flingers | Part no.: 058336
FB-SCEZ-25M-PCRSeries: 205 | Shaft: 25 mm | Variant: Corrosion resistant insert | Part no.: 127571
FB-SCEZ-25M-PSeries: 205 | Shaft: 25 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-014-PCRSeries: 205 | Shaft: 7/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-014-PSeries: 205 | Shaft: 7/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-015-PCRSeries: 205 | Shaft: 15/16 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-015-PSeries: 205 | Shaft: 15/16 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-100-PCRSeries: 205 | Shaft: 1 in | Variant: Corrosion resistant insert | Part no.: 127534
FB-SCEZ-100-PSeries: 205 | Shaft: 1 in | Variant: Insert with flingers | Part no.: 057908
FB-SCEZ-30M-PCRSeries: 206 | Shaft: 30 mm | Variant: Corrosion resistant insert | Part no.: 127752
FB-SCEZ-30M-PSeries: 206 | Shaft: 30 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-102-PCRSeries: 206 | Shaft: 1-1/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-102-PSeries: 206 | Shaft: 1-1/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-103-PCRSeries: 206 | Shaft: 1-3/16 in | Variant: Corrosion resistant insert | Part no.: 127535
FB-SCEZ-103-PSeries: 206 | Shaft: 1-3/16 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-104S-PCRSeries: 206 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127536
FB-SCEZ-104S-PSeries: 206 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: 058311
FB-SCEZ-35M-PCRSeries: 207 | Shaft: 35 mm | Variant: Corrosion resistant insert | Part no.: 127753
FB-SCEZ-35M-PSeries: 207 | Shaft: 35 mm | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-104-PCRSeries: 207 | Shaft: 1-1/4 in | Variant: Corrosion resistant insert | Part no.: 127537
FB-SCEZ-104-PSeries: 207 | Shaft: 1-1/4 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-105-PCRSeries: 207 | Shaft: 1-5/16 in | Variant: Corrosion resistant insert | Part no.: 058648
FB-SCEZ-105-PSeries: 207 | Shaft: 1-5/16 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-106-PCRSeries: 207 | Shaft: 1-3/8 in | Variant: Corrosion resistant insert | Part no.: Assembled to order
FB-SCEZ-106-PSeries: 207 | Shaft: 1-3/8 in | Variant: Insert with flingers | Part no.: Assembled to order
FB-SCEZ-107-PCRSeries: 207 | Shaft: 1-7/16 in | Variant: Corrosion resistant insert | Part no.: 127538
FB-SCEZ-107-PSeries: 207 | Shaft: 1-7/16 in | Variant: Insert with flingers | Part no.: Assembled to order
