DODGE Extreme Duty SCED 4-Bolt Flange (20-75 mm, 1/2-2-15/16 in)

DODGE Extreme Duty SCED 4-Bolt Flange (20-75 mm, 1/2-2-15/16 in)

DODGE Extreme Duty SCED/SCMED set screw mounted ball bearings are built for demanding industrial service where equipment uptime is critical.

Key features

  • 65° set screws give maximum locking force without weakening the inner ring
  • Anti-rotation pin prevents insert rotation in the housing
  • QuadGuard sealing system: triple-lip seal with rubberized flinger
  • Maxlife ball cage for extended grease life
  • Suited to agriculture, aggregate, cement, paper, wood products and metals

Specifications

Brand DODGE
Product line Extreme Duty
Housing style 4-bolt flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 20-75 mm, 1/2-2-15/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 3-23 to 3-24
F4B-SCED-20M Series: 204 | Shaft: 20 mm | Part no.: 076246
F4B-SCED-008L Series: 204 | Shaft: 1/2 in | Part no.: Assembled to order
F4B-SCED-010L Series: 204 | Shaft: 5/8 in | Part no.: Assembled to order
F4B-SCED-012 Series: 204 | Shaft: 3/4 in | Part no.: 076046
F4B-SCED-013 Series: 204 | Shaft: 13/16 in | Part no.: Assembled to order
F4B-SCED-25M Series: 205 | Shaft: 25 mm | Part no.: 076247
F4B-SCED-014 Series: 205 | Shaft: 7/8 in | Part no.: Assembled to order
F4B-SCED-015 Series: 205 | Shaft: 15/16 in | Part no.: Assembled to order
F4B-SCED-100 Series: 205 | Shaft: 1 in | Part no.: 076047
F4B-SCED-30M Series: 206 | Shaft: 30 mm | Part no.: 076248
F4B-SCED-101 Series: 206 | Shaft: 1-1/16 in | Part no.: Assembled to order
F4B-SCED-102 Series: 206 | Shaft: 1-1/8 in | Part no.: 076048
F4B-SCED-103 Series: 206 | Shaft: 1-3/16 in | Part no.: 076049
F4B-SCED-104S Series: 206 | Shaft: 1-1/4 in | Part no.: 076050
F4B-SCED-35M Series: 207 | Shaft: 35 mm | Part no.: 076249
F4B-SCED-104 Series: 207 | Shaft: 1-1/4 in | Part no.: 076051
F4B-SCED-105 Series: 207 | Shaft: 1-5/16 in | Part no.: Assembled to order
F4B-SCED-106 Series: 207 | Shaft: 1-3/8 in | Part no.: 076052
F4B-SCED-107 Series: 207 | Shaft: 1-7/16 in | Part no.: 076053
F4B-SCED-40M Series: 208 | Shaft: 40 mm | Part no.: 076250
F4B-SCED-108 Series: 208 | Shaft: 1-1/2 in | Part no.: 076054
F4B-SCED-110 Series: 208 | Shaft: 1-5/8 in | Part no.: Assembled to order
F4B-SCED-45M Series: 209 | Shaft: 45 mm | Part no.: 076251
F4B-SCED-110L Series: 209 | Shaft: 1-5/8 in | Part no.: 075775
F4B-SCED-111 Series: 209 | Shaft: 1-11/16 in | Part no.: 076055
F4B-SCED-112 Series: 209 | Shaft: 1-3/4 in | Part no.: 076056
F4B-SCED-50M Series: 210 | Shaft: 50 mm | Part no.: 076252
F4B-SCED-115 Series: 210 | Shaft: 1-15/16 in | Part no.: 076057
F4B-SCED-200 Series: 210 | Shaft: 2 in | Part no.: 076058
F4B-SCED-55M Series: 211 | Shaft: 55 mm | Part no.: 076253
F4B-SCMED-200 Series: 211 | Shaft: 2 in | Part no.: 076157
F4B-SCED-203 Series: 211 | Shaft: 2-3/16 in | Part no.: 076059
F4B-SCED-204 Series: 211 | Shaft: 2-1/4 in | Part no.: Assembled to order
F4B-SCED-60M Series: 212 | Shaft: 60 mm | Part no.: 076254
F4B-SCMED-204 Series: 212 | Shaft: 2-1/4 in | Part no.: 076649
F4B-SCED-207 Series: 212 | Shaft: 2-7/16 in | Part no.: 076060
F4B-SCED-70M Series: 214 | Shaft: 70 mm | Part no.: 076255
F4B-SCMED-208 Series: 214 | Shaft: 2-1/2 in | Part no.: 076160
F4B-SCED-211 Series: 214 | Shaft: 2-11/16 in | Part no.: 076061
F4B-SCED-75M Series: 215 | Shaft: 75 mm | Part no.: 076256
F4B-SCED-215 Series: 215 | Shaft: 2-15/16 in | Part no.: 076062
