DODGE Extreme Duty SCED Piloted Flange (30-70 mm, 1-1/16-2-11/16 in)

DODGE Extreme Duty SCED Piloted Flange (30-70 mm, 1-1/16-2-11/16 in)

DODGE Extreme Duty SCED/SCMED set screw mounted ball bearings are built for demanding industrial service where equipment uptime is critical.

Key features

  • 65° set screws give maximum locking force without weakening the inner ring
  • Anti-rotation pin prevents insert rotation in the housing
  • QuadGuard sealing system: triple-lip seal with rubberized flinger
  • Maxlife ball cage for extended grease life
  • Suited to agriculture, aggregate, cement, paper, wood products and metals

Specifications

Brand DODGE
Product line Extreme Duty
Housing style Piloted flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 30-70 mm, 1-1/16-2-11/16 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 3-26
FC-SCED-30M Series: 206 | Shaft: 30 mm | Part no.: 076257
FC-SCED-101 Series: 206 | Shaft: 1-1/16 in | Part no.: Assembled to order
FC-SCED-102 Series: 206 | Shaft: 1-1/8 in | Part no.: Assembled to order
FC-SCED-103 Series: 206 | Shaft: 1-3/16 in | Part no.: 076063
FC-SCED-104S Series: 206 | Shaft: 1-1/4 in | Part no.: 076064
FC-SCED-35M Series: 207 | Shaft: 35 mm | Part no.: 076258
FC-SCED-104 Series: 207 | Shaft: 1-1/4 in | Part no.: 076065
FC-SCED-105 Series: 207 | Shaft: 1-5/16 in | Part no.: Assembled to order
FC-SCED-106 Series: 207 | Shaft: 1-3/8 in | Part no.: 076066
FC-SCED-107 Series: 207 | Shaft: 1-7/16 in | Part no.: 076067
FC-SCED-40M Series: 208 | Shaft: 40 mm | Part no.: 076259
FC-SCED-108 Series: 208 | Shaft: 1-1/2 in | Part no.: 076068
FC-SCED-110 Series: 208 | Shaft: 1-5/8 in | Part no.: Assembled to order
FC-SCED-45M Series: 209 | Shaft: 45 mm | Part no.: 076260
FC-SCED-110L Series: 209 | Shaft: 1-5/8 in | Part no.: Assembled to order
FC-SCED-111 Series: 209 | Shaft: 1-11/16 in | Part no.: 076069
FC-SCED-112 Series: 209 | Shaft: 1-3/4 in | Part no.: 076070
FC-SCED-50M Series: 210 | Shaft: 50 mm | Part no.: 076261
FC-SCED-115 Series: 210 | Shaft: 1-15/16 in | Part no.: 076071
FC-SCED-200 Series: 210 | Shaft: 2 in | Part no.: 076072
FC-SCED-55M Series: 211 | Shaft: 55 mm | Part no.: 076262
FC-SCMED-200 Series: 211 | Shaft: 2 in | Part no.: 076163
FC-SCED-203 Series: 211 | Shaft: 2-3/16 in | Part no.: 076073
FC-SCED-204 Series: 211 | Shaft: 2-1/4 in | Part no.: Assembled to order
FC-SCED-60M Series: 212 | Shaft: 60 mm | Part no.: 076263
FC-SCMED-204 Series: 212 | Shaft: 2-1/4 in | Part no.: Assembled to order
FC-SCED-207 Series: 212 | Shaft: 2-7/16 in | Part no.: 076074
FC-SCED-70M Series: 214 | Shaft: 70 mm | Part no.: 076264
FC-SCMED-208 Series: 214 | Shaft: 2-1/2 in | Part no.: 076176
FC-SCED-211 Series: 214 | Shaft: 2-11/16 in | Part no.: 076075
Mounted Bearing UnitsDODGE
30 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Extreme Duty SCED Piloted Flange (30-70 mm, 1-1/16-2-11/16 in)

Brand DODGE·Mounted Bearing Units

Available part numbers (30)

FC-SCED-30M, FC-SCED-101, FC-SCED-102, FC-SCED-103, FC-SCED-104S, FC-SCED-35M, FC-SCED-104, FC-SCED-105, FC-SCED-106, FC-SCED-107 + 20 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
FC-SCED-30MSeries: 206 | Shaft: 30 mm | Part no.: 076257
FC-SCED-101Series: 206 | Shaft: 1-1/16 in | Part no.: Assembled to order
FC-SCED-102Series: 206 | Shaft: 1-1/8 in | Part no.: Assembled to order
FC-SCED-103Series: 206 | Shaft: 1-3/16 in | Part no.: 076063
FC-SCED-104SSeries: 206 | Shaft: 1-1/4 in | Part no.: 076064
FC-SCED-35MSeries: 207 | Shaft: 35 mm | Part no.: 076258
FC-SCED-104Series: 207 | Shaft: 1-1/4 in | Part no.: 076065
FC-SCED-105Series: 207 | Shaft: 1-5/16 in | Part no.: Assembled to order
FC-SCED-106Series: 207 | Shaft: 1-3/8 in | Part no.: 076066
FC-SCED-107Series: 207 | Shaft: 1-7/16 in | Part no.: 076067
FC-SCED-40MSeries: 208 | Shaft: 40 mm | Part no.: 076259
FC-SCED-108Series: 208 | Shaft: 1-1/2 in | Part no.: 076068
FC-SCED-110Series: 208 | Shaft: 1-5/8 in | Part no.: Assembled to order
FC-SCED-45MSeries: 209 | Shaft: 45 mm | Part no.: 076260
FC-SCED-110LSeries: 209 | Shaft: 1-5/8 in | Part no.: Assembled to order
FC-SCED-111Series: 209 | Shaft: 1-11/16 in | Part no.: 076069
FC-SCED-112Series: 209 | Shaft: 1-3/4 in | Part no.: 076070
FC-SCED-50MSeries: 210 | Shaft: 50 mm | Part no.: 076261
FC-SCED-115Series: 210 | Shaft: 1-15/16 in | Part no.: 076071
FC-SCED-200Series: 210 | Shaft: 2 in | Part no.: 076072
FC-SCED-55MSeries: 211 | Shaft: 55 mm | Part no.: 076262
FC-SCMED-200Series: 211 | Shaft: 2 in | Part no.: 076163
FC-SCED-203Series: 211 | Shaft: 2-3/16 in | Part no.: 076073
FC-SCED-204Series: 211 | Shaft: 2-1/4 in | Part no.: Assembled to order
FC-SCED-60MSeries: 212 | Shaft: 60 mm | Part no.: 076263
FC-SCMED-204Series: 212 | Shaft: 2-1/4 in | Part no.: Assembled to order
FC-SCED-207Series: 212 | Shaft: 2-7/16 in | Part no.: 076074
FC-SCED-70MSeries: 214 | Shaft: 70 mm | Part no.: 076264
FC-SCMED-208Series: 214 | Shaft: 2-1/2 in | Part no.: 076176
FC-SCED-211Series: 214 | Shaft: 2-11/16 in | Part no.: 076075
