DODGE Extreme Duty SCMED Medium Duty 2-Bolt Flange

DODGE Extreme Duty SCMED Medium Duty 2-Bolt Flange

DODGE Extreme Duty SCED/SCMED set screw mounted ball bearings are built for demanding industrial service where equipment uptime is critical.

Key features

  • 65° set screws give maximum locking force without weakening the inner ring
  • Anti-rotation pin prevents insert rotation in the housing
  • QuadGuard sealing system: triple-lip seal with rubberized flinger
  • Maxlife ball cage for extended grease life
  • Suited to agriculture, aggregate, cement, paper, wood products and metals

Specifications

Brand DODGE
Product line Extreme Duty
Housing style 2-bolt flange
Housing material cast iron
Locking Set screw (65°)
Shaft range 25-55 mm, 1-2-1/4 in
Source DODGE Mounted Bearings Catalog (Metric, June 2014), p. 3-22
F2B-SCMED-25M Series: 206 | Shaft: 25 mm | Part no.: 076307
F2B-SCMED-100 Series: 206 | Shaft: 1 in | Part no.: 076141
F2B-SCMED-30M Series: 207 | Shaft: 30 mm | Part no.: 076308
F2B-SCMED-103 Series: 207 | Shaft: 1-3/16 in | Part no.: 076142
F2B-SCMED-35M Series: 208 | Shaft: 35 mm | Part no.: 076309
F2B-SCMED-107 Series: 208 | Shaft: 1-7/16 in | Part no.: 076143
F2B-SCMED-40M Series: 209 | Shaft: 40 mm | Part no.: 076310
F2B-SCMED-108 Series: 209 | Shaft: 1-1/2 in | Part no.: 076144
F2B-SCMED-45M Series: 210 | Shaft: 45 mm | Part no.: 076311
F2B-SCMED-111 Series: 210 | Shaft: 1-11/16 in | Part no.: 076145
F2B-SCMED-112 Series: 210 | Shaft: 1-3/4 in | Part no.: 076146
F2B-SCMED-50M Series: 211 | Shaft: 50 mm | Part no.: 076312
F2B-SCMED-115 Series: 211 | Shaft: 1-15/16 in | Part no.: 076147
F2B-SCMED-55M Series: 212 | Shaft: 55 mm | Part no.: Assembled to order
F2B-SCMED-203 Series: 212 | Shaft: 2-3/16 in | Part no.: 076149
Mounted Bearing UnitsDODGE
15 product codes available in this family
Sourced direct from KoreaExport-ready supplyCompetitive pricing
RFQ List 0 Email about this

Need a different model, or a part not listed here? Send us your parts list →

DODGE Extreme Duty SCMED Medium Duty 2-Bolt Flange

Brand DODGE·Mounted Bearing Units

Available part numbers (15)

F2B-SCMED-25M, F2B-SCMED-100, F2B-SCMED-30M, F2B-SCMED-103, F2B-SCMED-35M, F2B-SCMED-107, F2B-SCMED-40M, F2B-SCMED-108, F2B-SCMED-45M, F2B-SCMED-111 + 5 more — see full table ↓

How to order

Send the DODGE part numbers and quantities through our RFQ form or to info@prosourcemro.com. We confirm price, availability and lead time within 1 business day — no account needed.

RFQ List 0 →
View full details
Product codes & specifications
0 selected
RFQ List (0)
Product codeSpec
F2B-SCMED-25MSeries: 206 | Shaft: 25 mm | Part no.: 076307
F2B-SCMED-100Series: 206 | Shaft: 1 in | Part no.: 076141
F2B-SCMED-30MSeries: 207 | Shaft: 30 mm | Part no.: 076308
F2B-SCMED-103Series: 207 | Shaft: 1-3/16 in | Part no.: 076142
F2B-SCMED-35MSeries: 208 | Shaft: 35 mm | Part no.: 076309
F2B-SCMED-107Series: 208 | Shaft: 1-7/16 in | Part no.: 076143
F2B-SCMED-40MSeries: 209 | Shaft: 40 mm | Part no.: 076310
F2B-SCMED-108Series: 209 | Shaft: 1-1/2 in | Part no.: 076144
F2B-SCMED-45MSeries: 210 | Shaft: 45 mm | Part no.: 076311
F2B-SCMED-111Series: 210 | Shaft: 1-11/16 in | Part no.: 076145
F2B-SCMED-112Series: 210 | Shaft: 1-3/4 in | Part no.: 076146
F2B-SCMED-50MSeries: 211 | Shaft: 50 mm | Part no.: 076312
F2B-SCMED-115Series: 211 | Shaft: 1-15/16 in | Part no.: 076147
F2B-SCMED-55MSeries: 212 | Shaft: 55 mm | Part no.: Assembled to order
F2B-SCMED-203Series: 212 | Shaft: 2-3/16 in | Part no.: 076149
